ELECTRIC CHAINSAW
2300W
CS2300
Important
- Please read these instructions fully before operating or maintaining your electric chainsaw
These instructions contain important information that will help you get the best
from your electric chainsaw, protecting your power tool investment.
INSTRUCTION
MANUAL
AFTERSALES SERVICE
01904 727505
MON-FRI 9am-5pm SAT/SUN 11am-4pm
www.spearandjackson-power.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS2300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spear & Jackson CS2300

  • Page 1 ELECTRIC CHAINSAW AFTERSALES SERVICE 01904 727505 2300W MON-FRI 9am-5pm SAT/SUN 11am-4pm CS2300 www.spearandjackson-power.com Important - Please read these instructions fully before operating or maintaining your electric chainsaw These instructions contain important information that will help you get the best from your electric chainsaw, protecting your power tool investment.
  • Page 2 THANK YOU! Dear Customer, Thank you for choosing a Spear and Jackson electric chainsaw. Spear and Jackson was founded in 1760 in the city of Sheffield, which is world famous for the production of steel, cutlery and garden and hand tools. Through continuous innovation and the use of new technologies and materials, Spear and Jackson has gained an enviable reputation as a supplier of reliable, high performance and high quality products designed to make your work in the...
  • Page 3: Table Of Contents

    CONTENTS Safety Information Description of symbols General safety Personal safety Electrical safety Operational safety Maintenance Intended use Box Content / Parts Preparation Tensioning the saw chain Chain lubrication Check the power supply Switching on/off Checking the chain brake Operation Overcutting Undercutting Cutting logs Limbing...
  • Page 4: Safety Information

    SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the electric chainsaw. WARNING! Brake is engaged and This is a warning symbol.
  • Page 5: General Safety

    SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine GENERAL SAFETY PERSONAL SAFETY IMPORTANT! WARNING! The chain is designed exclusively for Use appropriate tool. This device is only sawing wood. You may only fell trees if intended for sawing wood for domestic you have received the appropriate training.
  • Page 6: Electrical Safety

    SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine cutting saw chain. Make sure the switch current device (RCD with a tripping current is off when clearing jammed material. A of 30mA or less) protected supply. Use momentary lapse of concentration while of an RCD reduces the risk of electric operating the chainsaw may result in...
  • Page 7 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine Check for alignment of moving parts, throw the chainsaw out of control. binding of moving parts, breakage of parts, Use extreme caution when cutting brush mounting and any other condition that may and saplings.
  • Page 8: Maintenance

    SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine Carry the chainsaw by the front handle with maintenance instructions for the saw chain. the chainsaw switched off and away from Decreasing the depth gauge height can your body.
  • Page 9: Box Content / Parts

    BOX CONTENT PARTS Rear handle Motor and air slots Safety lock-off button Plug and cord Trigger Chain brake trigger Oil Filler cap SDS tension knob Chain bar Chain cover Chain Clamp knob Front handle PLEASE NOTE: THIS PRODUCTS REQUIRES CHAIN LUBRICATION OIL, AVAILABLE IN MOST DIY STORES.
  • Page 10: Preparation

    PREPARATION WARNING! Always wear protective gloves and clothing when working with the chainsaw and employ only original parts. Pull out the power plug before doing any work on the chainsaw itself-injury hazards! Remove the electric chainsaw from the box and carefully remove all packaging.
  • Page 11: Chain Lubrication

    PREPARATION Tighten the SDS knob (11) and lock in place with the clamp knob (13). Ensure the chain rotates smoothly on the bar. The chain is correctly tensioned if it does not sag underneath the rail and can be rotated completely around with a gloved hand. v.
  • Page 12: Check The Power Supply

    PREPARATION i. Unscrew the oil fill cap (4) and fill up with chain oil. ii. Wipe off any spilled oil and close the cap again. iii. Switch on the chainsaw pointing it at the ground without touching! Chain oil iv. If an oil trace can be seen, the chainsaw is lubricating. NOTE! Never saw when a sufficient chain lubrication is not guaranteed.
  • Page 13 PREPARATION NOTE! For extension cables up to 15metres, use a wire cross section of 2.5 mm . Use only extension cords suitable for outdoor use, preferably with a high visibility cable colour. Always unwind all extension cables fully, coiled cables can overheat and reduce the efficiency of your product.
  • Page 14: Switching On/Off

    PREPARATION Switching on/off Disengage i. Disengage the chain brake, where you shift the chain brake Engage trigger (10) back against the front grip (7). ii. Hold the electric chainsaw firmly with both hands, with the right hand on the rear grip and the left hand on the front handle.
  • Page 15 PREPARATION Disengage i. Engage the chain brake by shifting the chain brake trigger Engage (10) forward, away from the front handle (7). ii. Place the electric chainsaw onto a solid, flat surface. It must not be in contact with any objects. Connect the tool to the mains supply.
  • Page 16: Operation

    OPERATION WARNING! Always keep a firm grip on the tool with both hands and watch your feet. The saw chain must not contact either the ground or another object during sawing through or after sawing completion. Make sure that the saw chain does not become jammed in the wood.
  • Page 17: Undercutting

    OPERATION Undercutting WARNING! Never turn saw upside down to undercut. The saw cannot be controlled in this position Undercutting involves cutting on the underside of the log with top of saw against the log. When undercutting use light upward pressure. Hold the saw firmly and maintain control. The saw will tend to push back towards you.
  • Page 18: Limbing

    OPERATION iv. Sawing on a support stand : First cut 1/3 of a diameter from the blow, next cut from the top by using the bottom of the bar. See below figure. Limbing Limb cut Limbing is removing branches from a fallen tree. i.
  • Page 19: Felling Trees

    OPERATION iii. Do not cut above chest height as a saw held higher is difficult to control against kickback. iv. When pruning trees it is important not to make the finishing cut next to the main limb or trunk until you have cut off the limb further out to reduce the weight.
  • Page 20 OPERATION Before felling is started, consider the force and direction of the wind, the lean and balance of the tree, and the location of large limbs. These things influence the direction in which the tree will fall. Do not try to fell a tree along a line different from its natural line of fall.
  • Page 21: Maintenance

    MAINTENANCE WARNING! Always switch the product off and let the product cool down before performing inspection, maintenance and cleaning work! This chainsaw meets all current legislation requirements, in order to avoid injuries while repairing; every repair has to be carried out by a qualified member of staff in an authorized service centre.
  • Page 22: Chain Sharpening

    MAINTENANCE i. Remove the clamp knob (13) and the chain cover ii. Fit the chain around the bar ensuring that the direction of the chain is as depicted in the picture on the bar. Fit the chain on the sprocket. Adjust the position of chain tensioner so the tensioner pin locates in the hole (A) on the bar.
  • Page 23: Cleaning The Guide Bar And Lubricating The Sprocket Nose

    MAINTENANCE iv. Engage the chain brake (10) to lock the chain on the bar (“Engage”position) when sharpening. v. Uses a round file for chain sharpening. Diameter equivalent to 1.1times the cutting tooth depth. vi. File at a horizontal angle 35°to the bar. vii.
  • Page 24: Uk Plug

    MAINTENANCE UK plug If you need to replace the fitted plug, then this must be replaced using a BS1363/A Mains plug fitted with a BS1362 approved fuse of identical value to the original fuse. Proceed as follows: IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue –...
  • Page 25: Disposal

    MAINTENANCE Disposal Disposing of the machine Machines which are labeled with this symbol must not bedisposed of in household rubbish. You must dispose of such oldelectrical and electronic appliances separately. Please check with your local authority about the possibilities forcorrect disposal. You will thus help to avoid that damaging into the environment.
  • Page 26: Technical Data

    TECHNICAL DATA Model CS2300 Motor Voltage 230-240V ~/50Hz Power Input 2300W Electric motor no load speed 5600/min Chain speed 13m/s Insulation class class II Net weight 4.7Kg Type of saw chain Oregon 91PJ051X(14 oa Type of guide bar Oregon 140SDEA074(14 ba Measured sound pressure level 94.5dB (A), k=3 dB (A)
  • Page 27: Troubleshooting

    TROUBLESHOOTING No power Check the plug socket, cable, line and plug, where appropriate, have it repaired by a a certified electrician. If any of the parts are defective, such as On/Off switch / motor etc, call after sales support. Hand guard chain break might be engaged Please contact after sales support at 01904 727505.
  • Page 28: Guarantee

    GUARANTEE If your device develops a fault, please don’t hesitate to contact our customer service department on 01904 727505, we can usually solve 80% of problems via telephone. 1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights.
  • Page 29: Ec Declaration Of Conformity

    And our branch office SUMECUK Co.,Ltd. Unit A&B Escrick Business Park Escrick,York YO19 6FD Declare that the product Electric chain saw Factory No: SCS723A Model No: CS2300 Function: Saw Wood Serial number: CS2300-150001-150288 Complies with the following directives: EMC Directive: 2004/108/EC Machinery Directive:...
