HOTHOUSE 8
FREESTANDING
BOILER
STOVE
Please fix label with serial number and stove
type here before putting manual into stove
Installation and Operating
Instructions
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
Hothouse Inspired Products Ltd
Imperial Point
Express Trading Estate
Stonehill road
Farnworth
Bolton BL4 9TN
technical@hothouseproducts.co.uk
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Hothouse cannot
accept responsibility for any fault or consequential problems arising through incorrect installation or
operation.
Advertisement
Table of Contents
Related Manuals for HotHouse 8
Summary of Contents for HotHouse 8
- Page 1 Bolton BL4 9TN technical@hothouseproducts.co.uk PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Hothouse cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
-
Page 2: Table Of Contents
6. Technical Data 7. Operating Instructions Air controls Cleaning Fuels Notes on Wood Burning Lighting the stove Re-fuelling Shutting down Maintenance Seasonal Use 8. Safety Notes for your Guidance 9. Stove Dimensions 10. Frequently Asked Questions 11. Spares HD01 09/11... -
Page 3: List Of Components
Fig 2 – Hothouse Stove Assembly and controls 2. Component Identification and Assembly Your Hothouse Stove comes packed in a cardboard box. Carefully remove any straps and remove all cardboard and any plastic packaging, open the door and remove all the contents. See List of Components section and check contents carefully. -
Page 4: Installation Instructions
Keep all ventilation clear and free of blockage. Health And Safety Precautions Handling Adequate facilities must be available for unloading and site handling. Hothouse Cassette Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 5: Installation Information
The surface should be finished using 1:1:8 mix of cement, lime and sand. The connecting pipe is fitted with the spigot pushed up from inside the stove and rotated onto its keyhole slots to join to the pipe. Ensure that the pipe end is no closer than 76mm to the side or rear chimney walls. -
Page 6: Hearths
Hearths: Hothouse stoves require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. The superimposed hearth must not be less than 12mm thick and must have a clearly defined edge (change of level) to discourage placing of any combustible materials on or partially over it. -
Page 7: Boiler Connection
5.0 Boiler Connection HD01 09/11... - Page 8 150mm above the top of the stove. The gravity circuit must not contain any shut off valves and should be fully lagged to minimise heat loss. The pipes should not exceed 7.8 meters (25ft) in length to/from the cylinder. In general, the shorter the run of pipework the less heat loss and the more efficient the water heating.
-
Page 9: Link Up
Link Up: On heating and hot water installations, a semi-pumped system should be used to the central heating system with gravity circulation to the hot water cylinder. For optimum performance of the boiler we recommend that all 4 tappings are used when using separate gravity and pumped heating loops. The flow and return pipes should be taken from diagonally opposite sides of boiler. -
Page 10: Technical Data
6.0 Technical Data Hothouse 8B Technical Specifications (Wood) Total Heat Output Output to Water Output to Room Efficiency 77.7 CO Emission (@13% O2) 0.38 Flue Gas Temp (avg. at nominal output) °C *270 Flue Gas Mass Flow Refuel Period Flue Outlet Size Inch 6”... -
Page 11: Cleaning
Multifuel Grate Your Hothouse Stove is fitted with a rotary style grate, which is operated from the front of the stove via a riddle rod. Use the “Hook” end of tool to operate the riddling system. This rotary grate is located in the centre of a cast iron flat bed with suitable air slots that assist the burning of most fuels. -
Page 12: Lighting The Stove
50% to keep the appliance ventilated and stop the build-up of any moisture inside. 8.0 Safety Notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children, the elderly or the infirm. -
Page 13: Stove Dimensions
9.0 Stove Dimensions Fig. 3 – Hothouse 8B Stove All dimensions in mm unless otherwise stated. Dimensions are approximate and are subject to change without prior notice. -
Page 14: Frequently Asked Questions
7 Can the doors be left open while burning? For safety and heat efficiency the doors should remain closed. 8 Why is the stove smoking when lit? A flue with back draught problems is almost certainly the cause of a smoking stove. - Page 15 HD01 09/11...
- Page 16 Hothouse Inspired Products Ltd Imperial Point Express Trading Estate Stonehill road Farnworth Bolton BL4 9TN Tel: 01204 - 862286 Fax: 01204 - 868569 HD01 09/11...
