Atma-Sphere S-30 Mk.II.3 amplifier quick setup and operation instructions
Installation: Place the amps in your system. Connect the preamp cables to the
appropriate input connectors on the front of the amp. If you use the RCA input connectors,
make sure shorting jumpers are installed between pins 1 & 3 on the XLR connectors else a
buzz may result. Verify that both power switches are OFF and connect AC power to the AC
input connector on the rear of the amp. Connect the negative speaker cables to the negative
output terminals and the positive speaker cables to the positive output terminals.
Setup: Install the tubes in their sockets. The front 6 sockets (no cooling holes) take the
6SN7GT driver tubes. All other sockets take the 6AS7G output tube. A total compliment of
six driver and ten output tubes are required. Engage the main power switch (left of center of
front chassis) and verify that the amber indicator lights. In about 15 seconds, the filaments of
all tubes should be visibly glowing orange. Wait at least one minute, then engage the standby
switch (right side of center of chassis) and verify that the red indicator lights. The amplifier
is now fully powered up.
DC Offset adjustment: Set the large toggle switch below the meter to the left.
Examine the reading on the meter. If it is NOT zero, adjust the left control to bring the meter
to a zero reading. Perform the same operation for the right channel, using the right hand
control. Return the switch to the center position. The amplifier is now ready to operate.
Operation: The amplifier can be left in either standby or operational mode
indefinitely. Avoid 4 ohm speakers; the amp will give its best performance on 16 ohm
speakers. If using an 8 ohm speaker, it is very important the speaker exhibit at least an 8 ohm
impedance at all frequencies. In any event, the speaker load should be one known to be easy
to drive. Speaker cables can have a rather dramatic effect and you are invited to experiment.
Fuses: All Atma-Sphere Music Amplifiers are fitted with a group of three (3) AC mains fuses on
the rear panel by the AC input connector. The closest to the AC connector supplies power to
the amplifier's output section, and is 5 Amp on 117 Volt models, 2.5 amps on 235V. If the amp
lights up but otherwise appears to be dead, check this fuse.
The middle fuse supplies power to the output tube filaments, and is 5 Amp on 117 Volt models,
2.5 amps on 235V. The third fuse supplies power to the driver supply and is 0.5 Amp on 117
Volt models, .25 amps on 235V. Failure of this fuse indicates service of the amplifier chassis is
required.
