MA1 Mk.III amplifier setup and operation instructions
Installation: Place the amps in your system. Connect the preamp cable to the appropriate input connector on the rear of
the amp. If you use the RCA input connection, make sure a shorting jumper is installed between pins 1 & 3 on the XLR
connector else a buzz is possible. Verify that both power switches are OFF (down). Connect AC power to the AC input
connector on the rear of the amp. Connect the negative speaker cable to the negative output terminal and the positive
speaker cable to the positive output terminal. The amplifier is noninverting from the RCA input or pin 2 of the XLR.
Setup: Install the tubes in their sockets. The middle group of five sockets (no cooling holes) take the 6SN7GT driver
tube. All others are the 6AS7G output tubes. A total compliment of five driver and fourteen output tubes are required per
each chassis. Engage the Main Power switch (amber lamp, left side of chassis) and verify that the amber indicator
lights. In about 15 seconds, the filaments of all tubes should be visibly glowing orange. After at least one minute, engage
the Standby switch (red lamp, right side of chassis). The amplifier is now fully powered up.
DC Offset adjustment/Meter Switch: The middle switch controls the meter. Up is full power for full scale into 8 ohms,
Down is 1 watt for full scale. In the Down position, if the meter has a reading with no input signal, adjust the control for
no reading. This will be a null or dip in the meter setting. During normal operation, the Low position may only be useful
for high efficiency speakers. Use the High position if the meter is pegged to the right In the Low position.
Operation: The amplifier is now completely operational. Standby can be used at any time without loss of the warmup
character of the amplifier.
The MA1 will handle a four ohm speaker rather well. But, as for any tube amplifier, a speaker of 8 ohms is
recommended. Speakers of less then 8 ohms or speakers that are four ohms or less in the bass will not demonstrate all
the capabilities of any tube amplifier. If you must use a four ohm speaker, be careful to keep the length of the speaker
cables as short as possible, and in any event the speaker connections should be as tight as possible. Note that with a
tool to tighten the speaker connections on the rear of the amplifier care should be taken not to damage the connectors
by overtightening. Speakers of 4 ohms or less can also be used by use of the ZERO product; see
http://www.zeroimpedance.com for details.
New tubes may exhibit arcovers directly after shipment. If a tube arcs, put the amp in Standby, let it sit for a minute,
then tap the tube gently and try the amp again. Often the arcing will clear. If not, replace the tube. Sudden changes in
the meter null setting may indicate a damaged tube. If you are unable to adjust the DC Offset this may also be an
indication of a bad tube or tubes. If the meter pegs a short is in one of the tubes. Do not allow this condition to
persist! The meter will settle out when the offending tube is removed and replaced.
Fuses: The fuse by the power cord entry is the Output section B+ and is 5 Amp Slow (2.5A slow for
235V). Check this fuse if the amp lights up but does not play. The middle fuse is the filament fuse and is 5 Amp Slow
(2.5A for 235). The last fuse controls the driver circuit and is .5 Amp slow (.25A Slow for 235 Volt). WARNING! To avoid
fire hazard, always replace fuses with same type and rating.
