- Page 1 ELM Video Technology, Inc. DMX512 1x4 Splitter User Guide DS4r3 User Guide.lwp © copyright 2011-2013 ELM Video Technology, Inc.
- Page 2 Technology, Inc. DS4 OVERVIEW The DS4 is a DMX512 1 in 4 out splitter that takes a DMX512 output of a lighting console or any device that transmits a DMX512 signal and actively splits the signal providing 4 separate DMX512 outputs, and offers electronic protection by separating the input device and output devices using a Transient Voltage Suppression chip.
- Page 3 ELM Video Technology, Inc. CONFIGURATION EXAMPLE Terminate DMX512 Lighting DMX512 Devices Console Terminate 1 x 4 DMX512 Devices splitter Terminate House Adds 4 Dimmer additional outputs 1 x 4 splitter DS4r3 User Guide.lwp © copyright 2011-2013 ELM Video Technology, Inc.
- Page 4 IC’s are TVS (Transient Voltage Suppression) IC’s that provide isolation for each of the outputs. Pins 1 of each of the output connectors are tied to the power supply common. DS4r3 User Guide.lwp © copyright 2011-2013 ELM Video Technology, Inc.
-
Page 5: Troubleshooting
LED, if not check the internal fuse. Ÿ check if the input has a DMX512 signal by bypassing the DS4, if not check the DMX 512 console or source. Ÿ If the data and power are o.k. replace the input IC and possibly the output IC’s. -
Page 6: Specifications
4 separate DMX512 outputs - 5 (or 3) pin female XLR's, Pin 1 - Power supply common, Pin 2 Data -, Pin 3 Data + Dimensions: 3.7 x 6.7 x 2.1 inches Weight: 1.5 pounds DS4r3 User Guide.lwp © copyright 2011-2013 ELM Video Technology, Inc.
