- Page 1 DS4 / DSP DMX512 1x4 Splitter Users Guide ELM Video Technology, Inc. “Innovative DMX and MIDI Products” DS4-DSP-Users-Guide.lwp ELM Video Technology © copyright 2011-2016 ELM Video Technology, Inc. “Innovative DMX and MIDI Products”...
-
Page 2: Operation
DS4 OVERVIEW The DS4 is a DMX512 1 in 4 out splitter that takes a DMX512 output of a lighting console or any device that transmits a DMX512 signal and actively splits the signal providing 4 separate DMX512 outputs, and offers electronic protection by separating the input device and output devices using a Transient Voltage Suppression chip. -
Page 3: Configuration Example
Terminate DMX512 Lighting DMX512 Devices Console Terminate 1 x 4 DMX512 Devices splitter Terminate House Adds 4 Dimmer additional outputs 1 x 4 splitter DS4-DSP-Users-Guide.lwp ELM Video Technology © copyright 2011-2016 ELM Video Technology, Inc. “Innovative DMX and MIDI Products”... - Page 4 IC’s are TVS (Transient Voltage Suppression) IC’s that provide isolation for each of the outputs. Pins 1 of each of the output connectors are tied to the power supply common. ELM Video DS4-DSP-Users-Guide.lwp Technology © copyright 2011-2016 ELM Video Technology, Inc. “Innovative DMX and MIDI Products”...
-
Page 5: Troubleshooting
LED, if not check the internal fuse. check if the input has a DMX512 signal by bypassing the DS4, if not check the DMX512 console or source. If the data and power are o.k. replace the input IC and possibly the output IC’s. -
Page 6: Specifications
100 ~ 132 (or 240) VAC Current Output: 1 Amps Typical Power: 5 Watts Typical Polarization: Positive Center Output Connector: Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm ELM Video DS4-DSP-Users-Guide.lwp Technology © copyright 2011-2016 ELM Video Technology, Inc. “Innovative DMX and MIDI Products”...
