Page 1: User Manual
™ 1(20) Soneco CC3 USER MANUAL SONECO Oy Tuotekuja 5 FIN-90410 Oulu Finland Tel. +358 10 77 88 300 Fax. +385 8 311 4486 e-mail: info@soneco.fi www.soneco.fi © Soneco Oy July 2013 © Soneco Oy. V 23.7.2013 Staus: Contents schecked... -
Page 2: Warranty
In consumer trade Soneco is liable for the warranty defined by EU regulations. The authorized seller of Soneco products will either repair or replace the defective device that fall under warranty. The warranty does not apply to wear due to use or accessories. The warranty does not apply if the device has been in wrong or inappropriate use, opened, altered, connected to other equipment, used with other charger than Soneco P4300. -
Page 3: Table Of Contents
17. The life-time, capacity and maintenance of the battery........15 18. The use in challenging environments ..............15 19. Data security, privacy, reliability and prevention of abuse.......16 20. Unrecognized fault situations ................16 Annex A: Tone and light indications of CC3............18 Important to observe .....................20 Technical specifications: ..................20 Declaration of conformity:..................20 ©... -
Page 4: Purpose Of Cc3
Soneco CC3 is a small radio device for voice calls and text messages. With a single press of its only button, CC3 makes a voice call to one of set telephone numbers and can send a text message to one or several numbers simultaneously. -
Page 5: Quick Procedure For Using Mc3 For The First Time
2 seconds interval. 7. In order to switch the power OFF, press the button (for over 5 seconds) until all lights turn on. Then release the button. CC3 switches OFF. If switch-off by the user is blocked, see Chapter 12. -
Page 6: Charging Of The Battery
If you wish to change the existing settings start up the device as explained above, but press the button shortly during the start-up while the GREEN light is on for 5 seconds. The device enters the programming mode. © Soneco Oy. V 23.7.2013 Staus: Contents schecked... -
Page 7: The Programming Mode
The X-umber (eXtra number) can be used as an emergency number for situations when the numbers 1 to 3 can not be reached. In CC3, the X number is for voice calls. The U-number (Unlocking number) is only for the management ©... -
Page 8: Setting The Alarm Message
The message is set in programming mode with a message to the device. The message has to contain between command brackets “<<<” and “>>>” a command "sms:" and the message with a maximum length of 150 characters as below <<<sms:Own_message>>> E.g.<<<sms:Contact reception>>> © Soneco Oy. V 23.7.2013 Staus: Contents schecked Author: JR... -
Page 9: Basic Settings
(value = 0). The character “a” defines if the message is to be sent to number 1, “b” means the same for number 2 and “c” for number 3. E.g. a command “<<<CC1110>>>” defines CC3 to call only number 1 and to send message to numbers 1 and 2. -
Page 10: Options For Voice Calls
For text messages, only x1 is relevant. The default setting for CC3 is that all tones 1 to 4 are ON. In elder devices this setting is fixed and tone 5 does not exist. -
Page 11: Security And General Settings
CC3 and values x apply to alarm mode call from MC3. For CC3, the following instructions apply if there is no answer from the called numbers: = 1 causes a text message to be sent to the X-number (see chapter 5) if there is no reply from numbers 1 to 3. -
Page 12: Standby Mode
RED blinks. If the reason for failed transmission is lost network connection, the device enters LIMITED state. Wait until the device returns to standby mode and re-start the calling by pressing the button. © Soneco Oy. V 23.7.2013 Staus: Contents schecked... -
Page 13: Receiving And Terminating Of The Calls
V-command during the call. 11. Special features during alarm mode CC3 is in alarm mode only when it is trying to make a call. During this mode the call can be directed to the stored number that sends a message to the device. -
Page 14: Shutting The Device Off
14. Voice call features in alarm state This applies only to MC3. If CC3 is re-programmed in to MC3, please refer to User's Guide for MC3. 15. Emergency call 112 The MC3 device can be set to allow emergency 112 calls in standby mode. -
Page 15: Remote Controlled Voice Call "Call" And Termination Of A Call "End Call" And Queuing Of A Call
16. Remote controlled voice call "CALL" and termination of a call "END CALL" and queuing of a call With proper settings, the telephone numbers stored in CC3 can command the device to make calls and to terminate ongoing calls. A call to the number-x is triggered with a command <<<CALL:number-x>>> if the dialing indications x2 and x4 are active. -
Page 16: Data Security, Privacy, Reliability And Prevention Of Abuse
If an entry to the programming mode by the user has been prevented and the users have lost the information for sending and acceptable PRG-command, the GSM phone number of Soneco's service can command the device in to programming mode and read the technical information. This number can not control the calls or the messages nor can it be used as a calling number. - Page 17 - uncontrolled removal of SIM or shut-down of equipment Unrecognized errors should be very rare. The reason should always be cleared even if the device may return later to normal operation. © Soneco Oy. V 23.7.2013 Staus: Contents schecked Author: JR...
-
Page 18: Annex A: Tone And Light Indications Of Cc3
™ 18(20) Annex A: Tone and light indications of CC3 A1. When the device is OFF (OFF mode) The OFF is nt indicated. Upon pressing the button, the device gives and audible signal and the YELLOW light is on. If there is no indication from the button, the battery is empty and needs charging. - Page 19 In the absence of SIM or network coverage, the emergency call will be tried with the best available network. During an emergency call a shut-off due to low battery is blocked. The call remains on as long there is any charge in the battery. © Soneco Oy. V 23.7.2013 Staus: Contents schecked...
-
Page 20: Important To Observe
Operating temperature: -10 ... + 55 C (when charging, 0 ... + 45 C) SIM card: 3,0 V SAR: < 0,5 W/Kg Operating voltage: 3.7 V 0523 Declaration of conformity: The product complies with the requirements of the European Council directive 1999/5/EY. © Soneco Oy. V 23.7.2013 Staus: Contents schecked Author: JR...
