Page 1: Digital Video Recorder
INSTALLATION & OPERATING MANUAL Digital Video Recorder DVR-3016 & DVR-3016D Before trying to connect or operate this product, please read this manual complete... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS All the following safety and operation instructions for the prevention of harm or damage to the operator or other persons should be read before the unit is operated. WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Do not block ventilation openings. -
Page 4: Table Of Contents
1. PRODUCT FEATURES ... 4 1.1 Product Introduction ...4 ...4 1.2 Product Features 2. DESCRIPTION OF THE FRONT/REAR VIEW... 6 2.1 Front View ...6 2.2 Rear View ...9 2.3 ALARM In/Out ...10 3. INSTALLATION ... 11 3.1 Basic Connection ... 11 3.2 Hard-Disk Drive Installation ...12 3.3 HDD Information and channel selection ...13 3.4 Updating System Software ...14... - Page 5 5.2 DISPLAY OPTION...35 5.3 SEQUENCE SETTING ...38 5.4 PICTURE ADJUST ...39 5.5 OPERATION LOG...39 5.6 AVANCED SETTING...40 5.6.1 ALARM SETTING... 40 5.6.2 RECORD SETTING ... 41 5.6.3 MOTION SETTING ... 42 5.6.4 COVERT CAMERA... 43 5.6.5 OPERATION LOCK ... 43 5.6.6 COMMUNICATION ...
-
Page 6: Product Features
1. PRODUCT FEATURES 1.1 Product Introduction This 16CH DVR is a triplex digital recorder with a 16ch multiplexer, capable of Triplex simultaneous recording, playback and live multi-screen viewing; it uses two hard disks and a CD-RW drive instead of VCR tapes to store video (FOR CD-ROM MODEL ONLY). It enables you to enjoy the extreme flexibility of digital image archiving instead of clumsy tape management. - Page 7 each camera). ＊ Selectable display position and color of title/time/date OSD text in both MAIN and CALL monitors. ＊ Covert camera recording. ＊ Schedule setting: total 8 schedules. Individual record and alarm condition setting can be assigned by designated schedule. ＊...
-
Page 8: Description Of The Front/Rear View
2. DESCRIPTION OF THE FRONT/REAR VIEW 2.1 Front View FOR CD-ROM MODEL CD-RW device compartment The compartment allows you to burn the data mostly for backup purposes. This tray is for loading the CD disc. It will accept 120 mm and 80 mm discs. Please place the discs in the exact center of the tray. - Page 9 Jog Dial: This dial can act in both a forward and a backward direction, as well as step by step. Turn this left to play a recorded video in the reverse direction. Turn this right to play a recorded video in the forward direction.
-
Page 10: Lock Indicator
call button: If you connect to the call monitor, the "Call" button enables you to select channels on this monitor. Press the "Call" button and any particular channel button on the front panel simultaneously to display that channel. menu button: Press this to enter the setup menu. -
Page 11: Rear View
2.2 Rear View 29 30 75Ω/Hi-Z Individual termination: These 16 switches are used to set the impedance of each loop through output connectors (31) between 75Ω and Hi-Z. Toggle the corresponding impedance termination to the Hi-Z position, if another device is connected to the video loop through connector. -
Page 12: Alarm In/Out
2.3 ALARM In/Out The pin assignment of the female DB-25 alarm I/O connector is listed as follows. Pin# Pin Assignment GROUND DISK FULL (OUTPUT) ALARM2 OUT (OUTPUT) RECORD IN (INPUT) ALARM1 IN (INPUT) ALARM3 IN (INPUT) ALARM5 IN (INPUT) ALARM7 IN (INPUT) ALARM9 IN (INPUT) ALARM11 IN (INPUT) ALARM13 IN (INPUT) -
Page 13: Installation
3. INSTALLATION Please follow the instructions and the diagram below to set up the system. 3.1 Basic Connection CONNECTING WITH 1 to 16 CAMERAS ATTACHING AN EXTERNAL DEVICE TO DVR Connect an alarm out, alarm input, and a peripheral device as shown in the diagram below. -
Page 14: Hard-Disk Drive Installation
3.2 Hard-Disk Drive Installation The 16CH DVR is equipped with two compartments of hard-disk drives and a CD-RW drive (FOR CD-ROM MODEL ONLY). The unit usually comes with one hard-disk drive installed in the compartment HD1, which is default-configured as a master. If you need a second hard-disk drive to be installed in the compartment HD2, please contact your distributors or installers for specific instructions on how to install it. -
Page 15: Hdd Information And Channel Selection
3.3 HDD Information and channel selection 3.3.1 HDD information You can display the HDD information as shown on Figure 3.3 A below at any time by pressing the Display button . In the playback mode, the recorded video information is displayed. In the live or recording mode, the Manual Recording information is displayed. -
Page 16: Updating System Software
3.4 Updating System Software If the system software of the 16CH DVR needs to be upgraded, please take the following steps to safely update it. Important: Before carrying out the following procedures, please ensure the SD card is working and the system software file is intact. 1. -
Page 17: Basic Operations
4. BASIC OPERATIONS This section shows you how to operate and manage the DVR. 4.1 Recording Operations This section details the way to record video into hard-disk drives. Before commencing with the recording function, please configure the recording setting properly according to your needs. 4.1.1 Manual Recording When the DVR is in the live display mode, take the following steps to start recording: (1) In live display, press the REC button... - Page 18 NOTE: You can proceed to start the scheduled recording from the current time if it is in the scheduled interlude as soon as the setting is complete, and come out from the menu to start recording. NOTE: If you activate the recording function before the scheduled recording, the unit will operate recording as shown in the diagram below and keep those Images in different files.
- Page 19 MAIN MENU 1 QUICK SETTING: ENTER 2 DISPLAY OPTION: ENTER 3 SEQUENCE SETTING: ENTER 4 PICTURE ADJUST: ENTER 5 OPERATION LOG: ENTER 6 ADVANCED SETTING: ENTER 7 DEFAULT SETTING: ENTER 8 PASSWORD SETTING: ENTER 9 EXIT MENU: ENTER enter: select ▲/▼/jog/ch1~9: item ADVANCED SETTING 1 ALARM SETTING:...
-
Page 20: Alarm Recording
4.1.3 Alarm Recording Take the following steps to activate the programmed alarm recording. For ALARM settings, please refer to section 5.6.1 for more details. (1) Press the menu button (2) Select the ADVANCED SETTING and press the Enter button SETTING page. (3) Select the ALARM SETTING and press the Enter button page. -
Page 21: Externally Triggered Recording
4.1.4 Externally triggered Recording By connecting the RECORD IN of ALARM I/O on the rear panel of the DVR, you can activate/deactivate the recording function of a DVR. NOTE: The status of recording operations when an alarm takes place is shown in the diagrams below. -
Page 22: Playback Operations
4.2 Playback Operations This section shows you how to operate the fast, slow, and single-picture playback functions, and details how the unit is to playback a file in a different operation status. Please refer to the following paragraphs specifying the relevant details. When playing a file, the PLAY button DVR is in the playback status. -
Page 23: Playback Picture-By-Picture
4.2.3 Playback Picture-by-picture While playing back recorded video at the recorded speed: (1) Press the PAUSE button (2) There are two ways, by PAUSE button or by JOG, to play in the picture-by-picture mode, but the PAUSE button can only function in a forward direction; the other, the JOG dial act in both a forward and a backward direction, as well as picture-by-picture. -
Page 24: Search Operations
4.3 Search Operations This section shows you how to access recorded video. 4.3.1 Full List Search Take the following steps to proceed with the full-list search function. (1) Press the Search button (2) Select FULL LIST and press the Enter button video. -
Page 25: Search Filter
SEARCH 1 FULL LIST ENTER 2 ALARM LIST ENTER 3 SEARCH FILTER ENTER 4 THUMBNAIL ENTER 5 SD CARD ENTER 6 CD (BACKUP) ENTER 7 EXIT ENTER enter: select ▲/▼/jog/ch1~7: item (“CD” IS FOR THE CD-ROM MODEL AND “BACKUP” IS FOR THE REMOVABLE HDD MODEL ONLY IN THE ITEM 6.) 4.3.3 SEARCH FILTER Take the following steps to proceed with the time-list search function. -
Page 26: Thumbnail Search
4.3.4 THUMBNAIL Search Take the following steps to proceed with the thumbnail search function. (1) Press the Search button (2) Select the THUMBNAIL and press the Enter button ● You can set up by using the “<” button select the image you wish to search for the recorded video. ●... -
Page 27: Cd (Backup) Menu
SEARCH 1 FULL LIST ENTER 2 ALARM LIST ENTER 3 SEARCH FILTER ENTER 4 THUMBNAIL ENTER 5 SD CARD ENTER 6 CD (BACKUP) ENTER 7 EXIT ENTER enter: select ▲/▼/jog/ch1~7: item (“CD” IS FOR THE CD-ROM MODEL AND “BACKUP” IS FOR THE REMOVABLE HDD MODEL ONLY IN THE ITEM 6.) 4.3.6 CD (BACKUP) Menu 4.3.6.1 CD Menu (FOR CD-ROM MODEL ONLY) -
Page 28: Backup Operations
4.3.6.2 BACKUP Menu (FOR HARD-DISK MODEL ONLY) Please refer to section 4.4.2 “Mobile Rack HD Backup Operations” for more details. 4.4 Backup Operations 4.4.1 CD ReWritable unit Backup Operations (FOR CD-ROM MODEL ONLY) This device now includes a CD-RW unit. SAVE MENU 1 SD CARD JPEG: 2 SD CARD AVI:... -
Page 29: Mobile Rack Hd Backup Operations (For Removable Hdd Model Only)
to view your selections. 4. CD AVI: You can archive a video in the CD disc by entering this item. Please follow the steps given below. Please insert the CD disc in its tray. Hear that beeping signal to confirm your disc is ready. - Page 30 ADVANCED SETTING 1 ALARM SETTING: ENTER 2 RECORD SETTING: ENTER 3 MOTION SETTING: ENTER 4 CAMERA COVERT: ENTER 5 OPERATION LOCK: ENTER 6 COMMUNICATION: ENTER 7 DISK SETUP: ENTER 8 SCHEDULE: ENTER RETURN menu: exit enter: select ▲/▼/jog/ch1~8: item (2) Backup to HD3. Press the “Search”...
-
Page 31: Security Digital Card (Sd Card) Backup Operations
4.4.3 Security Digital Card (SD Card) Backup Operations The SD card slot of the front unit has four functions as shown below: 1. Archive Single image Clips into the SD Card Please take the following steps to archive a critical image in an SD card. (1) Insert an SD Card into the SD card slot of the front unit. - Page 32 SAVE AVI0001.AVI TO SD CARD SAVE AVI0002.AVI TO SD CARD SAVE AVI000N.AVI TO SD CARD NOTE: ●The JPEG file format can be played and deleted in the DVR. Please refer to section 4.3.5. ●The AVI file format cannot be played and deleted in the DVR. It can only be played in a card reader connected to a computer.
-
Page 33: Key Lock Operations
4.5 Key Lock Operations ● To activate the key lock function. Press the Menu button to enter the MAIN MENU page. Select ADVANCE SETTING to enter the ADVANCE SETTING page. Select OPERATION LOCK to enter the OPERATION LOCK mode. Select FRONT KEY LOCK to enable its function. Exit and save, activating the key lock function. -
Page 34: Triplex Operations
4.6 Triplex Operations 4.6.1 Live mode: ● Simultaneous live viewings of any one channel in multiple channels. (1) Use the enter button to show a red-framed Channel 1. (2) Press the enter button to move the red-framed rectangle to Channel 2, and so on to the other channels consecutively until you arrive at your chosen channel. -
Page 35: Menu Setup
5. MENU SETUP There are 9 functional items for operation setting in the setup menu system as shown below. The following sections will instruct you step by step to configure the operation setting and will state each item’s purpose and options. To enter any particular item, press the corresponding channel number from CH 1~9 on the front panel. -
Page 36: Quick Setting
5.1 QUICK SETTING This page enables you to rapidly install your desired setting. For more detailed changes, enter each item page. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU:... -
Page 37: Display Option
5.2 DISPLAY OPTION This item enables you to fix the display labels on your screen. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU: enter: select ▲/▼/jog/ch1~9: item... - Page 38 2. TIME DISPLAY COLOR: You can choose between red, yellow, blue, green, black, and white. 3. DATE DISPLAY: Select to ON or OFF as desired. 4. DATE DISPLAY COLOR: Select any of the six colors, namely red, yellow, green, blue, black, and white. 5.
- Page 39 9. DAYLIGHT SAVING SETTING: This entry allows users to set the daylight saving time. NONE: Disables the daylight saving time. EUROPE GMT +00:00: Daylight saving time begins at 1:00 a.m. on the last Sunday of March. Time reverts to standard time at 2:00 a.m. on the last Sunday of October. EUROPE GMT +01:00: Daylight saving time begins at 2:00 a.m.
-
Page 40: Sequence Setting
5.3 SEQUENCE SETTING This page enables you to use ten modes to set the sequence of displays you want for the main monitor, and a single mode for the call monitor. The dwell time for displays in each channel can be set at your own preference anywhere between 0 ( no - show ) and 99 seconds when you press the Sequence button. -
Page 41: Picture Adjust
5.4 PICTURE ADJUST This page enables you to position your images the way you desire. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU: enter: select ▲/▼/jog/ch1~9: item... -
Page 42: Avanced Setting
5.6 AVANCED SETTING This page includes multiple special functions. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU: enter: select ▲/▼/jog/ch1~9: item 5.6.1 ALARM SETTING This page enables you to set all the various alarm - related functions. -
Page 43: Record Setting
4. ALARM RECORD RATE: For an NTSC unit we provide many different speeds from 0 to 60 fields per second, and for a PAL unit the figures are from 0 to 50 F/S. 5. ALARM RECORD MODE: Each channel is provided with four categories of alarm record rates: NORMAL, DOUBLE, INTERLEAVED, and EXCLUSIVE. -
Page 44: Motion Setting
1. RECORD QUALITY: You can enter and set each channel's record quality at 4 different levels of image recording from "BEST","HIGH", and "STANDARD" to "BASIC". 2. NORMAL RECORD RATE: The rate range is from 1 field per second (F/S) to 60 F/S. 3. -
Page 45: Covert Camera
5.6.4 COVERT CAMERA Enter and activate each channel to ON or deactivate to OFF for hidden or exposed recording respectively. ADVANCED SETTING 1 ALARM SETTING: 2 RECORD SETTING: 3 MOTION SETTING: 4 CAMERA COVERT: 5 OPERATION LOCK: 6 COMMUNICATION: 7 DISK SETUP: 8 SCHEDULE: RETURN menu: exit... -
Page 46: Communication
5.6.6 COMMUNICATION We provide you with two settings: the RS 232 and RS 485. ADVANCED SETTING 1 ALARM SETTING: 2 RECORD SETTING: 3 MOTION SETTING: 4 CAMERA COVERT: 5 OPERATION LOCK: 6 COMMUNICATION: 7 DISK SETUP: 8 SCHEDULE: RETURN menu: exit enter: select ▲/▼/jog/ch1~8: item 1. -
Page 47: Disk Setup
5.6.7 DISK SETUP Enter the disk mode to select your desired setting. ADVANCED SETTING 1 ALARM SETTING: 2 RECORD SETTING: 3 MOTION SETTING: 4 CAMERA COVERT: 5 OPERATION LOCK: 6 COMMUNICATION: 7 DISK SETUP: 8 SCHEDULE: RETURN menu: exit enter: select ▲/▼/jog/ch1~8: item 1. -
Page 48: Schedule
9. RETURN: Go back to the previous page. 5.6.8 SCHEDULE Enter the setting to set up 8 forms of schedule. A schedule can change the record setting as well as the alarm setting at designated times. You can directly "ENABLE" or "DISABLE" each schedule. ADVANCED SETTING 1 ALARM SETTING: 2 RECORD SETTING:... -
Page 49: Return
8. RETURN: Go back to the previous page. 5.6.9 RETURN To exit the “ADVANCED SETTING” page choose “RETURN” and go back to the “MAIN MENU” page. ADVANCED SETTING 1 ALARM SETTING: 2 RECORD SETTING: 3 MOTION SETTING: 4 CAMERA COVERT: 5 OPERATION LOCK: 6 COMMUNICATION: 7 DISK SETUP:... -
Page 50: Password Setting
5.8 PASSWORD SETTING This page enables you to set the password. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU: enter: select ▲/▼/jog/ch1~9: item 1. -
Page 51: Exit Menu
5.9 EXIT MENU If you wish to exit the menu, focus on this item and enter. MAIN MENU 1 QUICK SETTING: 2 DISPLAY OPTION: 3 SEQUENCE SETTING: 4 PICTURE ADJUST: 5 OPERATION LOG: 6 ADVANCED SETTING: 7 DEFAULT SETTING: 8 PASSWORD SETTING: 9 EXIT MENU: enter: select ▲/▼/jog/ch1~9: item... -
Page 52: Netguard System: Introduction
6. NETGUARD SYSTEM: Introduction NETGUARD SYSTEM : This version of the NETGUARD SYSTEM uses the Microsoft .Net Framework version. The .Net Framework performs the XML Web Services which applies this operation system. The .Net Framework provides a very high performance environment to solve the network program. Therefore, please use our NETGUARD software to connect the 16CH DVR. -
Page 53: Tcp/Ip Communication Setup
6.1 TCP/IP Communication Setup Follow the instructions below to install the TCP/IP communication program into your computer. . Click the Start Menu from your computer, and point to the Control panel. .Click the Network Connections icon twice to enter the Network setting windows. Point to the Local Area Connection and click the right bottom of the mouse. - Page 54 Click on the Configuration tag; check if the TCP/IC is included among the network components list. If the TCP/IP is included, please process step 5. If it is not included, please follow step 4 to install the TCP/IP. TCP/IP installation During the installation, you will be requested to insert the windows XP CD ROM.
- Page 55 TCP/IP Configuration setting Click Start Control Panel Select Internet Protocol (TCP/IP), and then click Properties. Before processing the DVR installation in a WAN, please make sure the Internet connection works properly. If not, please contact your ISP provider. If you are using a DHCP server, please select Obtain an IP address automatically. Any assigned IP address for the connected DVRs must be in the same class type as the server.
-
Page 56: Connection Testing
6.2 Connection Testing With the previous settings, follow the instructions below to ensure whether you have established the connection successfully. . Click Start Command Programs . Type in ping 192.168.1.1 then Enter. (See the sample screen below) ** This IP is the DVR IP address that is assigned for the connected DVR. If you receive a response as in the sample screen below, the connection hasn’t been successfully established. -
Page 57: Software Installation
If you receive a response as in the sample screen below, you have successfully made the connection. 6.3 Software installation. Step 1: Exit all applications currently running in the selected PC. Step 2: Insert the supported PC in the CD - ROM device. The program will execute the installation of the .Net Framework automatically after you click the "Setup.exe"... - Page 58 Step 4: The installation screen will show the message "C :\ Program Files \ NETGUARD \". Or you can select the path you want. Note: Click "Next" to continue the installation. ※ Step 5 : The window below tells you the process is complete. Note: Click the "Close"...
- Page 59 Step 6 : After completing installation, you can double - click the file shown below. Or click the "Start Menu" in the computer and select "Programs" to open the "Program Selection" page. Then click the "NETGURD SYSTEM" tag to start the program. NOTE: Please make sure the TCP/IP communication software has been properly set and configured in your computer.
-
Page 60: Short Introduction
6.4 Short introduction Once the NETGUARD is executed, a log in window will appear. Please type the appropriate user name and password to log into the DVR, ie “Admin” and “9999”, and click the "Login" button. 6.4.1 Program introduction 【Available Devices】 ： selection. -
Page 61: Operation
【Multiscreen】 ： Here all the videos of the cameras will show. 【Multiscreen Buttons】 ： "Video Panel", "Web Page" and the "Viewer Settings" buttons. 【Function Key】 ： Click each of these buttons to execute its functions. 6.5 Operation 6.5.1 Remote Control ※... - Page 62 Adjust the screen size: Move the mouse to the vertical bar on the right side of the "Work Devices" / "Available Devices" box on the left margin of the screen. This bar runs from the top to the bottom of the screen, and when you move the mouse to this bar, it shows like this: the left to narrow the "Working Devices"...
- Page 63 "Print": Click the "Print Preview" button and go to the "Preview" option to adjust the image size. Go to the "Print Settings" area and then to "Mark Date and Time" if you wish to stamp the date and time of the image on the image itself. Select "Dimension" to scroll the appropriate pixels from the drop - down list.
-
Page 64: Remote Play And Ptz Control
6.5.2 Remote play and PTZ control. This device has the full triplex so you can use the NETGUARD in the remote without affecting the performance of the 16 - channel DVR. You can also use the NETGUARD to play and back up. If you have a PTZ camera, the NETGUARD can also control it. -
Page 65: Backup And Video Edit
the way, without stopping, in one of the four designated directions. The fifth button, in the center, will stop the camera at any point you prefer. 3. The left-hand set of buttons, one short step only in any of the four designated directions. 4. - Page 66 ● Frame dimension : Sets the resolution. ● Mark Day and Time : Sets the date and time stamp. Play Options： ● Time to play : To search the date and time you want. ● Channel Number : To choose a camera. Play Monitor：...
-
Page 67: Web
6.5.4 Web Page Viewer This section provides instructions for using the NETGUARD's web page viewer feature. 1. " Click "PTZ Device" to open the control panel and remote control the pan/tilt/zoom function camera live over a local area network or the Internet. 2. -
Page 68: Viewer Setting
● Image: Click "Image" to enter the "Image " page to set each channel's "Channel Title", "Quality", "Noise Filter", "Brightness", "Contrast", "Color" and "Hue". Click "Submit" after each setting. ● Alarm: The upper part of the window enables you to set the "Duration", "Disk Full", "PreAlarm", and "Frame Rate" of the alarm for the device. - Page 69 2. "Playback Record Time". Click the "Display Mode" to select from a drop - down list of two choices, "Hide" and "Show". Your choice will decide whether the images will display the date and time or not. 3.”Data Format”. Click the “Display Mode” to select from a drop-down list of two choices, “DD/MM/YYYY” and “MM/DD/YYYY”.
-
Page 70: The Image Viewer
6.6 The Image Viewer The 16CH DVR is equipped with a digital watermark. It's a check software which protects archived images and informs you whether the images have been modified or not. Follow the instructions below to open an archived image from an SD card or an HDD. Pop up the START menu in your computer, and point to Programs / NETGUARD SYSTEM to open up the program selection page. -
Page 71: Microsoft Internet Explorer
7. Microsoft Internet Explorer This section provides instructions for accessing the 16CH DVR via Microsoft Internet Explorer. Connecting the 16CH DVR Start up the Microsoft Internet Explorer, and then follow the steps given below to connect the 16CH DVR: Click the URL block at the top of the screen. Type in the URL address of the 16CH DVR into the URL block and press the “Enter”... -
Page 72: Function Buttons
Function Buttons Stop- Click to stop playing back the recorded video or Pause / Play- Click to a recorded video from the PLAY LIST. Step- Click to view images in the reverse direction Step- Click to view images in the forward direction REV- Click to play a recorded video in the reverse FWD- Click to play a recorded video in the forward The Split-Screen display function bar: This allows you... - Page 73 " Click "PTZ Device" to open the control panel and remote control the pan/tilt/zoom function camera live over a local area network or the Internet. Please refer to section 6.3.2.2 for more details. The "General Setting" page is used to set the title, the date and time modes, and the time. Click "Advanced Settings"...
-
Page 74: Specifications
8. SPECIFICATIONS Model Resolution Operation Mode Video Input Video Output Audio In/Out Compression Storage Media >900Gb / 2 Fixed HDD, 1 Removable HDD Hot Swappable Removable HDD / SD Archive Watermark Recording Rate Image Size Recording Mode Alarm Recording Pre-alarm Recording Playback Speeds Slow Forward/ Reverse: 1/2X, 1/4X, 1/8X, 1/16X, 1/30X, 1/100 and pause Event List/ Time/ Alarm List/ Filter/... -
Page 75: Appendix 1. - Rs-232 & Rs-485 Codes
APPENDIX 1. – RS-232 & RS-485 Codes RJ-11 PIN configuration for RS-485 PIN NO. PIN Assignment Not Connected Not Connected CONNECTION More than one device can be controlled via the RS-232 & RS-485 port from a host computer. Three kinds of RS-232 &... - Page 76 Separation Code A separation code is used to insert between two control command codes to ensure a proper operation. They do not have any explicit function themselves. The following codes can be used as separation code: Key Codes-- These codes are used to operate all the functions performed by the buttons on the front panel. These Key codes are usually in a single code format.
- Page 77 Same as display button Same as freeze button Same as search button Same as zoom button Same as jog+ button Same as jog- button Same as jog- button Same as shuttle + button Same as shuttle - button Same as shuttle button homing Same as button Same as...
- Page 78 R10/ Selects “CH10” to display under PIP, Quad, 2x2, 3x3, or 4x4 format R11/ Selects “CH11” to display under PIP, Quad, 2x2, 3x3, or 4x4 format R12/ Selects “CH12” to display under PIP, Quad, 2x2, 3x3, or 4x4 format R13/ Selects “CH13”...
- Page 79 Status inquiry: This code is used to inquire the operating status of a specific unit in the system. The addressed unit will response with a message code as follow: “〈SP〉﹕〈MODE〉 〈STATUS〉 〈CR〉 〈LF〉” “ :SQ_2 S=0000000000000000 V=0000000000000000〈CR〉 〈LF〉” “ :VR_PIP S=0000000000000000 V=0000000000000000〈CR〉 〈LF〉” 〈MODE〉There are 8 different modes.
-
Page 80: Appendix 2. - Using Cd Discs (For Cd-Rom Model Only)
APPENDIX 2. – Using CD Discs (FOR CD-ROM MODEL ONLY) Please note that when using CD-ROM, CD-R and CD-RW discs, do not write or stick anything on the surface as this could cause an error in recording or the data on the disc may be damaged. Inserting Disc 1. - Page 81 Emergency Eject Button The device has an emergency eject button, which allows for manual retrieval of the disc in case the machine needs repair, or there is a cut in the power supply. In the above circumstances use the following method to eject the disc.
