Appro DVR-3011T Installation & Operation Manual

Appro digital video recorder - installation & operation manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION &
OPERATION MANUAL

Digital Video Recorder

DVR-3011T / DVR-3011ST
Before trying to connect or operate this product, please read this manual completely

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR-3011T and is the answer not in the manual?

Questions and answers

Related Manuals for Appro DVR-3011T

Summary of Contents for Appro DVR-3011T

  • Page 1: Digital Video Recorder

    INSTALLATION & OPERATION MANUAL Digital Video Recorder DVR-3011T / DVR-3011ST Before trying to connect or operate this product, please read this manual completely...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS All the following safety and operated instructions which will prevent harm or damage to the operator and other persons should be read before the unit is operated. WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Do not block ventilation openings.

  • Page 4: Table Of Contents

    Table Of Contents 1. PRODUCT FEATURES ....................4 1.1 Product Introduction ........................4 1.2 Product Features........................4 2. DESCRIPTION OF THE FRONT/REAR VIEW............... 5 2.1 Front View ..........................5 2.2 Rear View ...........................7 2.3 ALARM In/Out ...........................8 3. INSTALLATION ......................9 3.1 Basic Connection ........................9 3.2 Hard-Disk Drive Installation ....................
  • Page 5 7.1 Built-in hard disk........................49 7.2 Mobile Rack ..........................50 8. SYSTEM DEFAULT...................... 53 9. O.S.D MESSAGE ......................55 10. NETWORK VIEWER AND IMAGE VIEWER (FOR DVR-3011T ONLY)..... 56 10.1 The Network Viewer .......................56 10.2 The Image Viewer........................65 11. INDEX TABLE ......................66 12.

  • Page 6: Product Features

    ＊ Motion detection. ＊ Disk-full warning and operation status LEDs. ＊ RS-232, RS-485 communication port. ＊ Remote control via RS-232, RS-485 and Ethernet ports (FOR DVR-3011T ONLY). ＊ Power interruption recovery. ＊ Operation-status record log. ＊ Distributing live and recorded images through TCP/IP network environment. (This function focuses on the DVR-3011T.)

  • Page 7: Description Of The Front/Rear View

    2. DESCRIPTION OF THE FRONT/REAR VIEW 2.1 Front View PLAY STOP PAUSE Power Display Setup Search A-rec Enter Monitor T-rec DISK POWER 17 18 Hard-disk drive compartment The compartment allows you to install a hard disk drive mostly for backup purposes. Make sure the drive is well secured with the mounting screws in the mobile rack before you put the rack into the compartment.
  • Page 8 Left / Right buttons: Press the two buttons to highlight desired items in the menu setup mode. For Key Lock operation, press these two buttons simultaneously once; to disable Key Lock, press these two buttons simultaneously again. Up / Down buttons: Press these two buttons to select the desired contents for programming in the setup menu mode.

  • Page 9: Rear View

    DVR. ETHERNET 10/100 Connector: This is one standard RJ-45 connector for 10/100 Mbps Ethernet networks. (FOR DVR-3011T ONLY) RS-485 Port: The RS-485 communication ports function as connectors when two or more units are serially connected to an external control device.

  • Page 10: Alarm In/Out

    2.3 ALARM In/Out DISK FULL ALARM RESET ALARM OUT RECORD IN GROUND ALARM IN SWITCH OUT NO CONNECTION NO CONNECTION THIS FIGURE IS LOOKED FROM THE REAR VIEW GND: Ground Contact. ALARM OUT (OUTPUT): This is an alarm output trigger. Connect this to external devices such as buzzers or lights.

  • Page 11: Installation

    CONNECTING WITH A QUAD Please set the MULTIPLEXER option to OFF on the REC SETTING page in the setup menu when it is connected with a quad. (Please refer to section 5.1 MULTIPLEXER option) Note: The network function focuses on the DVR-3011T.
  • Page 12 Audio in Monitor GROUND SWITCH OUT Quad Audio S-video SD Card FROM MUX VIDEO MAIN MONITOR AUDIO RS-485 ETHERNET RS-232 10/100 ALARM MUX'S VCR IN DC12V MONITOR Video in Audio in Monitor Note: The network function focuses on the DVR-3011T.

  • Page 13: Hard-Disk Drive Installation

    Ground Alarm in (Normally Open) Note: The network function focuses on the DVR-3011T. 3.2 Hard-Disk Drive Installation The DVR is equipped with two compartments of hard-disk drive. The unit usually comes with one hard-disk drive installed in the compartment HD1, which is default-configured as a master. If you need a second hard-disk drive to be installed in the compartment HD2 (Mobile), please contact your distributors or installers for specific instructions on how to install it.
  • Page 14 Table 3.2 Compatible SATA hard-disk drives Manufacturer Model Capacity Rotation Cache ST340215AS 7200 RPM Seagate ST340815AS 7200 RPM ST380215AS 7200 RPM ST380815AS 7200 RPM 7200 RPM ST3120215AS 120G ST3120815AS 120G 7200 RPM ST3160215AS 160G 7200 RPM ST3160815AS 160G 7200 RPM ST3200820AS 200G 7200 RPM...

  • Page 15: System Information

    (SIZE 20G): The capacity of the installed hard disk (POS): Percentage of system; R: Recording; P: Playback the Ethernet (IP : 192 . 168 . 1 . 90): Setting of communication,192.168.1.90 (FOR DVR-3011T ONLY) : External signal ): Cannot operate at now...

  • Page 16: Updating System Software

    3.4 Updating System Software If the system software of the DVR needs to be upgraded, please take the following steps to safely update it. Important: Before carrying out the following procedures, please ensure the SD card is working and the file of system software is intact 1.

  • Page 17: Basic Operations

    ON. This can be done by either of methods detailed below. (1) If an APPRO multiplexer is connected for use, you can program the REC time mode of the multiplexer by referring to the table below (each refresh rate refers to one REC time mode).

  • Page 18: Audio Off

    NTSC (MUX ON) Possible Recording Time HDD=20GB ( hour ) Audio OFF 11.3 24.8 56.5 110.7 192.1 544.7 1087.3 BEST Image 14.1 31.0 70.6 138.4 240.1 680.9 1020 1359.1 HIGH Quality 11.3 18.8 41.4 94.1 184.6 320.2 907.9 1360 1812.2 STANDARD 11.3 16.9...
  • Page 19 PAL (MUX OFF) Possible Recording Time HDD=20GB ( hour ) Audio ON 13.2 21.8 38.3 109.8 456.6 682.6 908.7 BEST Image 11.2 16.7 27.4 47.7 84.9 133.1 576.7 862.3 1147.8 HIGH Quality 15.1 22.4 36.6 63.2 110.3 168.8 782.7 1170.3 1557.8 STANDARD 11.4 32.5...

  • Page 20: Recording Operations

    4.2 Recording Operations This section details the way to record video into hard-disk drives. Before commencing with the recording function, please configure the recording setting properly according to your needs. 4.2.1 Manual Recording When the DVR is in live display mode, take the following steps to start recording: (1) In live display, press the REC button to record video into a hard disk drive with the corresponding programmed recording settings.
  • Page 21 NOTE: You can proceed to start the scheduled recording from the current time if it is in the scheduled interlude as soon as setting is completed, and come out from menu to start recording. NOTE: If you activate the recording function before the scheduled recording, the unit will operate recording as shown in the diagram below and keep those Images in different files.
  • Page 22 MAIN MENU MAIN MENU RECORD RECORD ALARM / MOTION ALARM / MOTION CLOCK / TIMER CLOCK / TIMER COMMUNICATION COMMUNICATION DISK DISK SYSTEM SYSTEM GOTO CLOCK / TIMER PAGE GOTO CLOCK / TIMER PAGE CLOCK / TIMER CLOCK / TIMER CLOCK : SET CLOCK...
  • Page 23 4.2.3 Alarm / Motion Recording Take the following steps to activate the programmed alarm recording. For ALM OPERATION, REC RATE, REC QUALITY, AUDIO, ALM TYPE, ALM DURATION, and PRE-ALARM settings, please refer to section 5.2 for more details. (1) Press the Setup button to enter the MAIN MENU.
  • Page 24 NOTE: The status of recording operations when an alarm takes place are shown in the diagrams below. Manual or Externally Triggered Recording Alarm Takes Place Actual Recording Speed Normal Alarm Normal Timer Recording Alarm Takes Place Actual Recording Speed Normal Alarm Normal Timer Recording...

  • Page 25: Playback Operations

    4.3 Playback Operations This section shows you how to operate the fast, slow, and single-picture playback functions, and details how the unit is to playback a file in a different operation status. Please refer to the following paragraphs specifying the relevant details. When playing a file, the monitor should display a flashing PLAY message and the PLAY button will light up indicating that the DVR is in the playback status.
  • Page 26 NOTE: When Normal playing a recorded video from a multiplexer at 60 F/S~30F/S (50F/S~25F/S for PAL), the playback speed is half at recorded speed NOTE: The playback speed will be displayed on the screen. However, when playing a recorded video from a multiplexer, the playback speed will only display in encoding (multiplexing) the mode.

  • Page 27: Search Operations

    4.3.4 Play Back Recorded Video from a HDD of the mobile rack To play back a recorded video from a HD2, take the following steps:: (1) Press the Search button to enter the search mode. (2) Press the “ ” and “v”...
  • Page 28 4.4.2 Alarm list Search Take the following steps to proceed with the alarm-list search function. (1) Press the Search button to enter the search mode. (2) Select the ALARM LIST and press the Enter button to access the complete list of alarm-event recorded video.
  • Page 29 4.4.4 THUMBNAIL Search Take the following steps to proceed with the thumbnail search function. (1) Press the Search button to enter the search mode. (2) Select the THUMBNAIL and press the Enter button to access the thumbnail page. (3) Set the date you wish to search for the recorded video. (4) Press the Enter button to start searching and displaying the concerned image.
  • Page 30 4.4.5 SD CARD Search Take the following steps to proceed with the SD card search function. (1) Insert a SD Card into the SD card slot of the rear unit. (2) Press the Search button to enter the search mode. (3) Select the SD CARD and press the Enter button to access the complete list of JPG files.

  • Page 31: Backup Operations

    4.5 Backup Operations 4.5.1 Mobile Rack HD Backup Operations There are three ways available to duplicate the recorded video from HD 1 (Fixed HD) to HD 2 (Mobile Rack HD). Please take the following steps to proceed. (1) Set HD 2 to BACKUP first. Take the following steps. Press the Setup button to enter the setup mode and select the DISK.
  • Page 32 MAIN MENU DISK SETTING RECORD REFORMAT ALARM / MOTION HD2 USAGE CLOCK / TIMER BACKUP----------------FULL COMMUNICATION SD FILE ALARM DISK SELECT SYSTEM MAIN PAGE BACKUP ALARM TO HD2 GOTO DISK PAGE SELECT: Duplicate a particular recorded video from HD1 to HD2. Stay on the DISK SETTING page.
  • Page 33 4.5.2 Secure Digital Card (SD Card) Backup Operations The SD card slot of the rear unit has four functions as shown below: Archive Single image Clips into SD Card Please take the following steps to archive a critical image in a SD card. (1) Insert a SD Card into the SD card slot of the rear unit.

  • Page 34: Key Lock Operation

    Save the whole setting into the SD card: Insert a SD card into the SD card slot. Press the Setup button to enter the setup mode and select the SYSTEM. Highlight SYSTEM and press the Enter button to enter the SYSTEM SETTING page. Set SD SETUP to SAVE.

  • Page 35: Menu Setup

    5. MENU SETUP There are 6 categories for operation setting in the setup menu system as shown below. The following sections will instruct you step by step to configure the operation setting and state each menu’s purpose and options. Press the Setup button to access the setup menu.

  • Page 36: Rec Setting

    5.1 REC SETTING This page allows you to set the recording rate and recording quality, and enables you to continue recording when the disk is full. MAIN MENU REC SETTING REC RATE : 20 F/S RECORD REC QUALITY : BEST ALARM / MOTION DISK FULL : REWRITE...

  • Page 37: Alarm / Motion Setting

    AUDIO: This option determines the way to record sound if necessary. ON: Enables AUDIO recording. OFF: Disables AUDIO recording. NOTE: Audio function can only be activated in the following refresh rate in NTSC(PAL): 20(17), 12(10), 5.5(5.5), 2.4(2.9), 1.22(1.52), 0.71(0.88) fields/sec MULTIPLEXER: For optimum image recording please set this option to ON when the DVR is connected to a multiplexer for use.
  • Page 38 REC QUALITY: This option determines the image quality to be recorded when an alarm input occurs. There are 4 levels of image quality to choose from: BEST, HIGH, STANDARD, and BASIC. The table below shows the level of image quality with the corresponding compression ratio and image size. Compression Ratio Image Quality Best...
  • Page 39 PRE- ALARM: This option determines that images prior to an alarm occurs will be recorded in the hard-disk drive. When an alarm is triggered the device will record the image prior to the alarm for 5 seconds. ( fields/sec ON: Enables this function. OFF: Disables this function.

  • Page 40: Clock / Timer

    5.3 CLOCK / TIMER The DVR provides a weekly table, consisting of two periods of time each day for scheduled recording. This option allows you to set the time each day that the DVR will start and stop recording. MAIN MENU CLOCK / TIMER RECORD CLOCK...

  • Page 41: Communication

    5.4 COMMUNICATION This option allows you to configure the status of the RS-232 communication port when connected to an external device, and the Ethernet(FOR DVR-3011T ONLY) communications settings. (Please refer to the RS-232 Protocol and Network Function for more details)
  • Page 42 NET DHCP: (FOR DVR-3011T ONLY) This option selects enable or disable for the DHCP communication function. OFF: Disables it. ON: Enables it. NOTE: If provided with a DHCP server, the DVR can get an IP automatically by setting this option to ON.
  • Page 43 ACCOUNT: This option is used to configure the FTP account settings. This is required for the purpose of making a FTP connection. Please consult with a qualified MIS professional to configure it. FTP ACCOUNT FTP IP : 192.168.001.128 USER : [ dvr PASSWORD : [ 00000000 PATH : [ /dvrvideo...

  • Page 44: Disk Setting

    5.5 DISK SETTING MAIN MENU DISK SETTING RECORD REFORMAT : HD 1 2 ALARM / MOTION HD 2 USAGE : REC CLOCK / TIMER BACKUP : FULL COMMUNICATION SD FILE : JPEG DISK SYSTEM MAIN PAGE GOTO DISK PAGE DISK REFORMAT/CLEAR REFORMAT: This option allows you to clear out all the data in the hard-disk drive.

  • Page 45: System

    5.6 SYSTEM This page is used for accessing the history of the operation status, setting the password, resuming factory default, and determining the menu display background. SYSTEM MAIN MENU OPERATION LOG : ENTER RECORD OSD LANGUAGE : ENGLISH ALARM / MOTION MENU BACKGND CLOCK / TIMER BUZZER...
  • Page 46 This option allows you to set a password to prevent any unauthorized re-formatting of the hard disk drives or use by a network viewer (FOR DVR-3011T ONLY). The standard password is “9999”. OLD PASSWORD: Enter the pre-set password (or the standard password if this is the initial setting) to access the password setting system.
  • Page 47 LOAD: Loads the whole setting to the SD card. VERSION: This item is in the setup menu reveal network MAC (FOR DVR-3011T ONLY), BIOS version, and software version, and last updated date. : 00 : 0c : 0c : 00 : 00 : 07 BIOS : 1.03...

  • Page 48: Rs-232 & Rs-485 Protocol

    6. RS-232 & RS-485 Protocol 6.1 Setup 6.1.1 Use a Null Modem cable (the standard RS-232 9 Pin Cable with Pin 2 and Pin 3 exchanged, see pin configuration chart below for details) to connect the COM 1 on the rear panel of the DVR to a PC. RJ-11 PIN configuration for RS-485 PIN NO.
  • Page 49 The different command types and their corresponding parameters are as follows: 6.2.1 Keys and signals PC Send: <0x41>, <0x01>, <0x20>, <0x01>, <Key Value>, <0x4f> < The value of a specific front panel key > KEY_PLAY KEY_STOP KEY_PAUSE KEY_POWER KEY_REC KEY_SETUP KEY_ENTER KEY_SEARCH KEY_DISPLAY...
  • Page 50 6.2.2.4 Request State (Second Category=0x06) PC Request: <0x41>, <0x01>, <0x20>, <0x02>, <0x06>, <0x00>, <0x4f> DVR Response: <0x41>, <0x20>, <0x01>, <0x02>, <0x06>, <0x01>, <System State = 0..>, <0x4f> Description of <System State>: STATE_STOP STATE_REC STATE_PLAY STATE_SETUP STATE_SEARCH STATE_BACKUP STATE_NET_PLAY 6.2.2.5 Time Search (Second Category=0x0b) PC send: <0x41>, <0x01>, <0x20>, <0x02>, <0x0b>, <0x06>, <6 Bytes Date/Time>, <0x4f>...

  • Page 51: Sata Hard Disk Installation

    7. SATA Hard Disk Installation The unit usually comes with one hard-disk drive installed in the compartment HD1, which is default-configured as a master. If you need a second hard-disk drive to be installed in the compartment HD2. Please contact your distributors or installers for specific instructions on how to install it.

  • Page 52: Mobile Rack

    7. Screw the rack into the device, fixing in all the four screws. 8. Attach the interface connector and the power connector to the drive. Place the mobile rack back onto the device and screw it in. 7.2 Mobile Rack 1.
  • Page 53 4. Place the hard disk in the rack. 5. Place the HDD inside the mobile rack. Use four of the provided screws to fix the HDD in place. 6. Place the top cover back to the carrier body by sliding forward to secure.
  • Page 54 9. Push the active-handle inward. 10. Lock the Key.

  • Page 55: System Default

    8. System Default MAIN MENU REC SETTING RECORD REC RATE : 20 F/S ALARM / MOTION REC QUALITY : BEST CLOCK / TIMER DISK FULL : REWRITE COMMUNICATION AUDIO : OFF DISK MULTIPLEXER : ON SYSTEM MAIN PAGE SET REC RATE GOTO REC PAGE MAIN MENU ALARM / MOTION...
  • Page 56 COMM SETTING MAIN MENU COMM ID : 01 RECORD RS232 : ON ALARM / MOTION RS485 : ON CLOCK / TIMER NET ENABLE : OFF (3011T) COMMUNICATION NET DHCP : OFF (3011T) DISK NET IP : SET (3011T) SYSTEM FTP SETTING (3011T) MAIN PAGE SET RS232 / RS485 ID...

  • Page 57: Message

    9. O.S.D Message O.S.D Message Meanings NO DISK No hard-disk detected after power activated BATTERY LOW Suggest change the battery and reset the system time LOADING System Boot up VIDEO LOSS Video loss VIDEO IN Video input source KEY LOCKED Key lock function is on KEY UNLOCKED Key lock function is off...

  • Page 58: Network Viewer And Image Viewer (For Dvr-3011T Only)

    10.1 The Network Viewer 10.1.1 Introduction to Network Viewer The Network Viewer allows you to potentially access 16 units of the DVR-3011T from a remote desktop or a laptop in a TCP/IP networking environment. It can perform the following functions.
  • Page 59 3. After the installation is complete, pop up the START menu from your computer, and point to Programs / APPRO 1CH DVR Network Viewer to open up the program selection page as shown below. Click the APPRO 1CH DVR Network Viewer tag to start the APPRO 1CH DVR Network Viewer program.
  • Page 60 NOTE: Upon connection, the connection status box indicates the name and IP address of the selected device. If there’s a failure to connect, a “Fail” message appears on the screen right after the User Name; otherwise an “OK” appears. To add more connections or units to the DVR-3011T, please repeat the above instructions.
  • Page 61 Description Functions Device List Displays the entire list of connected devices if and as necessary. This list includes a lot of information about all the connected devices. 800x600 This option is to select the resolution of the Multi-device mode window. 1024x768 Channel Assigns a display location when you have multiple devices connected.
  • Page 62 Function Buttons Description The Split-Screen display function bar. This allows you to display the connected device in the multi-format screens of 1, 2x2, 5+1, 7+1,3x3, 12+1, and 4x4. Press to enter the PC SYSTEM SETUP window, which allows you to program the System Setup, Record Setup, and Alarm Setup. Press to enter the selected device (the Single-device display mode).
  • Page 63 View single device Follow any one of the instructions below to get into the single device mode. 1. Select the desired device from the DEVICE LIST box on the Multi-device Mode. The button will enable. Click the button to view the image of the selected device and have access to certain functional operations of the device via the network.
  • Page 64 PgUp/PgDn: To scroll up and down the list. DVR-3011T Status Box. This box indicates the selected device status. PLAY: The device is in the playback mode. LIVE: The device is in the live display mode.
  • Page 65 10.1.4 Change the Record & Timer Properties Via the Network Follow the instructions below to reconfigure the record and schedule recording settings via the network. Set the regular record settings 1. When in the single –device mode, click to enter the SETUP page. (See the sample screen as in A above) 2.
  • Page 66 Press again to save images. (where the images will be stored into folder of C:\Program Files\APPRO 1CH DVR Network Viewer automatically) 3. For saving random images choose Yes tag. Select a folder in the computer for copying images in. Enter the number of images into the NUMBER OF SAVING box you wish to save in.

  • Page 67: The Image Viewer

    HDD of a computer, but also protects an archived image from reproduction or interpolation. If an image isn’t in the original format made by a DVR-3011T, the Image Viewer won’t display the image and instead will send a warning message” Wrong File, Can’t Open”. Follow the instructions below to open an archived image from a SD card or a HDD.

  • Page 68: Index Table

    11. Index Table The following description details how the DVR manages an index table issue. The DVR will generate a time index table indicating recorded data is kept in a particular HDD. This allows to individually selecting recorded data to be displayed via the alarm list search and full list search.

  • Page 69: Network Configuration (For Dvr-3011T Only)

    12. Network Configuration (FOR DVR-3011T ONLY) 12.1 Cable Connections Please follow the instructions below to connect your DVR to a computer or a network and to choose a proper RJ-45 cable configuration for connections. Physical specification of RJ-45 cable for Ethernet Wire Type Cat.

  • Page 70: Configure Your Dvr Network Settings

    RJ-45 PIN configuration for LAN Hub PIN NO. PIN Assignment TX + RJ-45 socket TX - RX + Not Connected 1 2 3 4 5 6 7 8 Not Connected RX - Not Connected Not Connected 12.1.3 Connect to WAN (INTERNET) The RJ-45 PIN configuration for connecting to a WAN is the same as connecting to a LAN.
  • Page 71 12.2.2 Enable DHCP Function Use the “ ” and “v” buttons , and , to highlight NET DHCP; select ON. Then press the Enter button to proceed. MAIN MENU COMM SETTING RECORD COMM ID : 01 ALARM / MOTION RS232 : ON CLOCK / TIMER RS485...

  • Page 72: Tcp/Ip Communication Software

    NOTE: When only one unit of the DVR is connected to a computer or LAN, you can freely assign an IP address for the DVR. For example, there is a range of DVR IP addresses from 192.168.0.1 to 192.168.0.255. You can pick one for use from the range of the IP.
  • Page 73 Click the NETWORK icon twice to enter the NETWORK setting windows. Click on the Configuration tag; check if the TCP/IC is included among the network components list. If the TCP/IP is included, please process step 5. If it is not included, please follow step 4 to install the TCP/IP.

  • Page 74: Tcp/Ip Installation

    12.4 TCP/IP installation During the installation, you will be requested to insert the windows 98 CD ROM. After installation, the PC will be restarted. 12.5 TCP/IP Configuration setting Click Start Settings Control Panel Network. Select TCP/IP, and then click Properties. Before processing the DVR installation in a WAN, please make sure the Internet connection works properly.

  • Page 75: Connection Testing

    If you are using a DHCP server, please select Obtain an IP address automatically. Any assigned IP address for the connected DVRs must be in the same class type as the server. If there is no DHCP server, please select specify an IP address and type in the IP address of your PC.
  • Page 76 If you receive a response as in the sample screen below, the connection hasn’t been successfully established. Please re-check all the hardware and software installation by repeating steps 1 to 5. If you still can’t establish the connection after rechecking, please contact your dealer.

  • Page 77: Specifications

    13. SPECIFICATIONS Model Number DVR-3011T DVR-3011ST Image System NTSC NTSC 720 x 240 pixels 720 x 288 pixels 720 x 240 pixels 720 x 288 pixels Resolution 352 x 240 pixels 352 x 288 pixels 352 x 240 pixels 352 x 288 pixels...

  • Page 78: Compatible Multiplexer Drives

    14. Compatible Multiplexer Drives Decode by Decode by VIEWER Manufacturer Model Channel COLORS (FOR DVR-3011T ONLY APPRO MPX-9004, 9104 NTSC / PAL 4CH COLOR, B/W APPRO MPX-9019, 9119 NTSC / PAL 9CH COLOR, B/W APPRO MPX-9016, 9116 NTSC / PAL 16CH...

  • Page 79: Microsoft Internet Explorer (For Dvr-3011T Only)

    Click the URL block at the top of the screen. Type in the URL address of the DVR-3011T into the URL block and press the “Enter” button to enter the login page. The default User Name and password is admin and 9999 respectively.
  • Page 80 Click to freeze the image. Click to activate the recording function of the device. Click to leave the home page of the DVR-3011T. Press to enter the SETUP window, and open the device setting page in order to add more devices for viewing.
  • Page 81 DVR-3011T Time & Status Box. This box indicates the selected device status. PLAY: The device is in the playback mode. LIVE: The device enters the live display mode. This allows you to search a recorded video stored in the HDD of the device. Enter the YEAR/MONTH/DAY HOUR: MINUTE you wish to search and click the GO button to proceed.

  • Page 82: Change Record / Alarm Setting

    15.2 Change Record / Alarm Setting Please follow the steps given below to change the Record / Alarm setting through the network as and when necessary. Click the button on the home page to enter the Record / Alarm setting page. Adjust the Record / Alarm setting, including the “REC rate”, “REC quality”, “ALARM REC enable”, “ALARM REC rate”, and “ALARM REC quality”...

  • Page 83: Change Timer Record Setting

    There are two time-periods available for scheduling each day. The Timer Record setting page allows users to program the time each day that the DVR-3011T will start and stop recording. The time is displayed in a 24-hour clock format. If there is a time overlap showing between two continual time-period settings, the device will automatically combine the two time-period settings into one combined time-period setting.

  • Page 84: Change Pan/Tilt/Zoom Setting

    15.4 Change Pan/Tilt/Zoom Setting Please follow the steps provided below to control the Pan/Tilt/Zoom setting through the network as and when necessary. Click the button on the home page to open the Speed Dome Controller. Click the button to control the Zoom setting on the Speed Dome Controller. The right-hand set, , has four buttons, each of which, upon being clicked, will turn the camera all the way, without stopping, in one of the four designated directions.
  • Page 85 The ‘AutoPan’ section has three buttons. The ‘Start’ and ‘End’ buttons fix the two points of any panning movement you select. The third or bottom button sets the chosen movement in the play mode.

  • Page 86: Appendix 1. -Scanip (For Dvr-3011T Only)

    APPENDIX 1. –SCANIP (FOR DVR-3011T ONLY) Follow the instructions below to use the SCANIP software to search the DVR-3011T devices from a local location. 1. Click the button to discover the connection of the all-type device in the LAN. The Device List will display the connection of the all-type device.
  • Page 87 5. Manual insertion of “Free IP Address”. If you have clicked “No”, please manually type in insertions as required in the “Free IP Address”, “Gateway Address”, and “NET Mask”. Follow each insertion you make by typing in the “Login Name” and “Password”, and click “UPDATE” to send your alterations to the DVR.
  • Page 88 8. To change any IP address, type in the new address in the “Free IP Address” box on the right as well as the device “Login Name” and “Password” in their respective blanks at bottom left, then click “UPDATE”, and the new address will automatically be sent to the device. 9.

This manual is also suitable for:
