Parts Listing; Field Service Troubleshooting Tips - Vortex 85-1448-10 (10 GPM) Installation And Service Manual

ITEM PART NO. DESCRIPTION
1 51-5692 Weldment, Frame
2 30-7820 Panel, Back
3 30-7875 Cover, Control Box
4 30-7821 Panel, Left
5 30-7877 Plate, Base, Fluid End
6 30-7822 Panel, Right
7 30-7833 Cover, Floor, Left
8 30-7834 Cover, Floor, Right
9 30-7835 Mount, Pump
10 30-7832 Cover, Top
11 86-0103 Pump, 10 GPM, Vortex
- 86-0110 Pump, 20 GPM, Vortex
12 04-0551 Screw, Machine, 5/16 - 18 x
3/4, HH, SS
13 04-1178 Nut, 5/16 - 18, HEX, SS, PL
14 04-1179 Washer, 5/16, Split, SS, PL
15 01-1999 Fitting, 90 Degree Elbow,
Connecter
16 01-2066 Fitting, Straight, 1/2 Conduit
17 08-0393 Hose, 1", 299 PSI
18 01-2068 Fitting, 1", Barb x NPTM, SS
19 01-2068 Fitting, 1", Barb x NPTM, PVC
20 82-2953 Control Box Assy
21 12-0424 Overload, Thermal, 20 GPM, 3
HP, 460V
- 12-0403 Overload, Thermal, 10 GPM, 2
HP, 460V
- 12-0404 Overload, Thermal, 10 GPM,
2 HP, 230V
- 12-0426 Overload, Thermal, 20 GPM,
3 HP, 230V
VRTX UNIT
1. Pressure gauge reads low.
• Clean strainer.
• If low on start-up, check pump rotation.
•• If running backwards, have electrician change two of the three black wires.
2. Vacuum gauge reads low.
• See pressure gauge.
• Make sure liquid filled pressure gauges are vented (see installation instructions).
• Check vacuum gauge line to make sure it is not plugged.
3. Gauges fluctuating.
• Check suction for leaks - starved for water.
• Check for pump cavitation (minimum submergence).
4. If pump does not come to full pressure after the above remedies are applied, hold hand over the discharge
vent tube to build up some back pressure in the reactor chamber.
5. If there is still a problem, shut down the VRTX unit. Wait for 2-3 minutes and re-start.
NOTE: If air leaks into the suction piping, the VRTX will not work (i.e., cavitate). The suction piping
must be air-tight.

PARTS LISTING

FIELD SERVICE TROUBLESHOOTING TIPS

ITEM PART NO. DESCRIPTION
22 04-0448 Screw, 8 - 32 x 0.250, THD,
PH, MS18-8, SS
23 04-1233 HEX HD, 1/4 - 20 x 7/8, C/S,
SS
24 01-1991 Fitting, Adapter, 1/4 NPT(M),
1/4 Tube
25 06-2174 Nameplate, Water Vortex,
Chesterton
26 82-2954 Control Panel Assy
27 02-0231 O-Ring
28 04-0548 Screw, 8 - 16 x 0.750, PHD,
PH, PL, T302
29 07-0569 Clamp, Hose, 0.813 x 1.500
30 82-2778-10 Vortex Assy, 10 GPM
- 82-2778-20 Vortex Assy, 20 GPM
31 07-0571 Plug Hole, 1 1/4"
32 04-1170 Washer, Split, 1/4, IN, SS
33 04-0279 Nut, HEX, 1/4 - 20, SS
34 51-5761 Weldment, Outlet
35 13-0097 Conduit, Liquid Tight, 1/2"
36 10-475 Stem, Vacuum, 3/8
37 01-2081 Elbow, Reducing, JG,
1/4 x 3/8
38 01-2107 Fitting, Union Tee, 1/4 JG
39 01-2109 Fitting, Nipple, 1.25 x 3", SS
40 90-1092 Cap, Protective, 1.25, Red,
Shipping
41 06-0986 Label, WARNING, High Voltage
42 06-2405 Label, Electric, Diagram,
Vortex
4
