ADVANCED FLUID TECHNOLOGY
INSTALLATION AND SERVICE MANUAL
VORTEX WATER TREATMENT SYSTEM
VRTX
Technologies
™
5807 Business Park
San Antonio, TX 78218
(210) 661-8800
FOR
Part Number 85-1448-10 (10 GPM)
Part Number 85-1448-20 (20 GPM)
This manual is an initial issue.
For further Information:
e-mail: vrtx@vrtxtech.com
Or see our Web Site
www.vrtx-technologies.com
DATE:
10/23/00
P.N.
28–0470
