Table of Contents
Summary of Contents for info-rise SunLight-206
- Page 1 TECHNOLOGIES SUNLIGHT SERIES USER MANUAL UNINTERRUPTIBLE POWER SUPPLIES ( 3 Phase Input & 1 Phase Output ) SunLight-206 6 kVA SunLight-207 7,5 kVA SunLight -210 10 kVA SunLight -215 15 kVA SunLight -220 20 kVA SunLight -230 30 kVA...
-
Page 2: Table Of Contents
SunLight Series UPS User Manual CONTENTS SAFETY .................. 2 INTRODUCTION 2.1. System Description ..........3 2.2. Technical Specifications ..........5 III. INSTALLATION 3.1. Unpacking .............. 7 3.2. Location Selection ............7 3.3. Cable Connections ............7 3.3.1. 6-7,5-10 kVA ............8 3.3.2. -
Page 3: Safety
SunLight Series UPS User Manual I. SAFETY This manual contains important instructions for SUNLIGHT series UPS that should be followed during installation and maintenance. IMPORTANT NOTICES 1. Read instructions carefully before operating the UPS 2. All warnings in the manual should be adhered to. 3. -
Page 4: Introduction
SunLight Series UPS User Manual II. INTRODUCTION Thank you for selecting this uninterruptible power supply (UPS). To choose the SUNLIGHT series as your equipment protector was a wise investment. It includes many features to protect your critical equipments. The SUNLIGHT series UPS system is connected between mains and critical loads , such as computer systems , telecommunication systems, computerized instruments etc. - Page 5 SunLight Series UPS User Manual The S.T.S will transfer back to the inverter automatically when the overload condition has been cleared. If the inverter fails internally, the unit switches to bypass within a few milliseconds. Mechanical Transfer Switch Static By-Pass 3 Phase 1 Phase AC Input...
-
Page 6: Technical Specifications
SunLight Series UPS User Manual 2.2 Technical Specifications SL-206 SL-207 SL-210 SL-215 SL-220 SL-230 Power 6 kVA 7,5 kVA 10 kVA 15 kVA 20 kVA 30 kVA Power Factor Automatic Battery Test Alarm Relays RS 232 INPUT Input Voltage 380 VAC 3Ph + N Input Voltage Tolerance + 15% , -15% 220 VAC ±10%... - Page 7 SunLight Series UPS User Manual DB9 Port AC Output 220V AC 50Hz. (10A max.) Main Switch On-Off Switch Battery Fuse UPS electrical connections Figure 2.2.1 6 - 7,5 - 10 kVA Rear view Front Panel PK1 On-Off Switch Main Switch UPS Electrical Connections and Fuse Board...
-
Page 8: Installation
SunLight Series UPS User Manual III. INSTALLATION 3.1 Unpacking The UPS is packed and enclosed in a structural cardboard carton to protect it from damage. 1. Inspect for damage that may have occurred during the shipment If any damage is noted, call the shipper immediately and retain the shipping carton and the UPS. -
Page 9: Kva
SunLight Series UPS User Manual 20 kVA 3 x 10+6 mm and 4mm Eart Cable 30 kVA 3 x 16+10 mm and 4mm Eart Cable The safety earth cable must be connected to the earth bus bar and bonded to each cabinet in the system. All cabinets should be earthed in accordance with local regulations. -
Page 10: Start-Up
SunLight Series UPS User Manual CAUTION! To reduce the risk of electric shock, disconnect the UPS from the mains supply before installing a computer interface signal cable. Reconnect the power cord only after signaling interconnections have been made. WARNING! DO NOT DEFEAT GROUND CONNECTIONS 3.4 Start-Up 3.4.1 6 - 7,5 - 10 kVA... -
Page 11: Kva
SunLight Series UPS User Manual 3.4.2 15-20-30 kVA The PK1 switch acts as follows: "0" Off position (there is no Voltage at the UPS output) "1" Maintenance By-Pass (there is Line Voltage at the UPS output) "2" By-Pass (there is Line Voltage at the UPS output) "3"... -
Page 12: Operation Procedure
SunLight Series UPS User Manual IV. OPERATING PROCEDURE 6 - 7,5 - 10 kVA 4.1.1 Turn On procedure 1 . Turn on the Main Switch on the rear panel to "1" position. (There is line voltage at the output.) 2 . Turn on the On-Off Switch PK1 on the rear panel to the "1" position. Turn on the power switches on your critical load after the "Inverter"... -
Page 13: Operator Control Panel
SunLight Series UPS User Manual Battery back-up time is more than 10 minutes for full load and can be extended by removing non-critical loads. After an utility power blackout, the audible alarm and "LINE FAILURE " indicator on LCD panel will start operating .1 minute after the power is interrupted , and you will see the message "BAT.USED :001min"on the LCD panel. -
Page 14: Second M.l.(Alarms)Of The Lcd
SunLight Series UPS User Manual LANG. ENGLISH : Display language FREQ : UPS output frequency. SOUND ON : Audible alarm is active. SOUND OFF : Audible alarm is not active. SYNC:OK : UPS and LINE synchronization status. COMM:OK : Communication active. BATT.USED : It shows battery operation time (the time passed after the last line failure alarm) LOG. -
Page 15: Fault Codes
SunLight Series UPS User Manual 4.4.4 FAULT Codes FAULT 1 “BYPASS FAILURE” An AC voltage exists at the output of the UPS, although the inverter is not in operation . In such a case , disconnect all the critical equipment from the UPS and turn it off and on again. -
Page 16: Optional Equipment
SunLight Series UPS User Manual V . OPTIONAL EQUIPMENT 5.1 Software Options The UPS can send digital data (optional) to the computer thought the RS232 port. No additional card is needed. It also has two alarm relays: Line failure and battery low. Computer systems require time to perform an orderly shutdown, without corrupting or losing data In an extended power failure , a computer system protected by a UPS eventually will lose power when the battery is exhausted. -
Page 17: Snmp Module
SunLight Series UPS User Manual Operating systems : Novell Netware , MS Windows 95-98-2000 -, NT Server , Linux 5.2 SNMP Module Using the SNMP module , your UPS is seen as a network device in your WAN or LAN applications, and with this way it can be monitored more than one UPS’s connected to your network through SNMPVIEW Software supplied with the module or it is possible to monitor the UPS through an Internet Browser. -
Page 18: Remote Monitoring Panel
SunLight Series UPS User Manual 5.4 Remote monitoring panel (RMP) You can see UPS status and parameters without using a computer up to 200 meters ( via RS485 interface). And you can connect more than one remote panel in cascade for monitoring your UPS system from several different locations at the same time. - Page 19 SunLight Series UPS User Manual...
-
Page 20: Connection Diagram
SunLight Series UPS User Manual COM1 Connection Diagram Of The RMP... -
Page 21: Customer Service
SunLight Series UPS User Manual VI . CUSTOMER SERVICE WARNING! There are no customer serviceable components inside. DO NOT open the cover or attempt to service the unit. High voltage may remain when the unit is shut down. Unauthorized service will void the warranty and could cause serious injury. 6.1 Maintenance The unit is designed for easy maintenance. -
Page 22: Limited Warranty
SunLight Series UPS User Manual VII . LIMITED WARRANTY The UPS is warranted against all defects in workmanship and materials under normal use for a period of one ( year from the date of shipment to the original user. The conditions of this warranty and the extent of responsibility of …………………………………………………………………………………………………………………………..
