AIR COMPRESSOR

operation manual
AC5060B
CAUTION READ THIS MANUAL CAREFULLY before operating or servicing this
air compressor, to familiarize yourself with the proper safety, operation, and standard
operating procedures of this unit. FAILURE TO COMPLY WITH INSTRUCTIONS IN
THIS MANUAL COULD RESULT IN THE VOIDING OF YOUR WARRANTY, AND
PERSONAL INJURY, AND/OR PROPERTY DAMAGE. THE MANUFACTURER
OF THIS AIR COMPRESSOR WILL NOT BE LIABLE FOR ANY DAMAGE
BECAUSE OF FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL.
By following the instructions and recommendations in this manual you will ensure a
longer and safer service life of your air compressor.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC5060B and is the answer not in the manual?

Questions and answers

Related Manuals for Xstream AC5060B

Summary of Contents for Xstream AC5060B

  • Page 1: Air Compressor

    AIR COMPRESSOR operation manual AC5060B CAUTION READ THIS MANUAL CAREFULLY before operating or servicing this air compressor, to familiarize yourself with the proper safety, operation, and standard operating procedures of this unit. FAILURE TO COMPLY WITH INSTRUCTIONS IN THIS MANUAL COULD RESULT IN THE VOIDING OF YOUR WARRANTY, AND PERSONAL INJURY, AND/OR PROPERTY DAMAGE.

  • Page 2: Table Of Contents

    table of contents Safety Safety Rules Safety Warnings Overview Basic Air Compressor Components Assembly 13 Assembling the Compressor Installation 15 Installation Chart 16 Typical Installation Controls 17 Compressor Controls Electrical Power Requirements 18 Electrical Wiring 18 Main Power Panel 18 Main Power Disconnect Switch Low Voltage Problems Grounding Instructions Break-In of the Pump...
  • Page 3 table of contents Maintenance 24 Draining the Tank 24 Checking the Oil 24 Changing the Oil 25 Belt Tension and Pulley Alignment 25 Adjusting Drive Belt Tension 25 Pulley Alignment 27 Cleaning the Air Filter 27 Checking the Relief Valve 27 Testing for Leaks 27 Storage 28 Maintenance Chart...
  • Page 4 introduction Attention: Read through the complete manual prior to the initial use of your Compressor Using the Operator’s manual The operating manual is an important part of your Compressor and should be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed.
  • Page 5 product identification Record Identification Numbers Compressor If you need to contact an Authorized Dealer or Customer Service (1-866-770-1711) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the pump and record the information in the places provided below.

  • Page 6: Safety

    safety Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards.
  • Page 7 safety WARNING Risk of Fire or Explosion. Never spray flammable liquids in confined area. It is normal for the motor and pressure switch to produce sparks while operating. If sparks come into contact with vapors from gasoline or other solvents, they may ignite, causing fire or explosion.
  • Page 8 safety WARNING Risk of Electrical Shock. Never use an electric air compressor outdoors when it is raining or on a wet surface, as it may cause an electric shock. WARNING Risk of Injury. This unit starts automatically. ALWAYS shut off the main power disconnect, and bleed all pressure from the system before servicing the compressor, and when the compressor is not in use.
  • Page 9 safety WARNING Risk of Eye Injury. Always wear ANSI Z87.1 approved safety goggles when using an air compressor. Never point any nozzle or sprayer toward a person or any part of the body. Equipment can cause serious injury if the spray penetrates the skin.
  • Page 10 safety CAUTION Drain the moisture from the tank on a daily basis. A clean, dry tank will help prevent corrosion. Pull the pressure relief valve ring daily to ensure that the valve is functioning properly, and to clear the valve of any possible obstructions.

  • Page 11: Overview

    overview Overview BASIC AIR COMPRESSOR COMPONENTS The basic components of the air compressor are the electric motor, pump, pressure switch and tank (see Fig. 1). The tank may be vertical or horizontal, varying in size and capacity. The electric motor (see A) powers the pump. The electric motor is equipped with an overload protector to help prevent possible motor burnout.
  • Page 12 overview BASIC AIR COMPRESSOR COMPONENTS FIG 1...

  • Page 13: Assembly

    assembly Assembly ASSEMBLING THE COMPRESSOR 1. Unpack the air compressor. Inspect the unit for damage. If the unit has been damaged in transit, contact the carrier and complete a damage claim. Do this immediately because there are time limitations to damage claims.
  • Page 14 assembly 4. Connect an air hose or distirbution line (not included) to the compressor. FIG 2...

  • Page 15: Installation

    installation Installation INSTALLATION CHART WARNING • Risk of bursting, resulting in injury. Never use Plastic pipe for compressed air. CAUTION • Never use lubricator for paint spraying or similar applications.

  • Page 16: Typical Installation

    installation A. Air flow B. Feeder line C. Drain leg D. Moisture trap with drain E. Non-lubricated supply line F. 1/4 turn valve G. Bypass H. Air dryer or aftercooler J. Line filter K. Drip tee with drain L. Air/water filter with petcock M.

  • Page 17: Controls

    controls Controls COMPRESSOR CONTROLS Motor Reset Switch WARNING • Ensure that all guards and shrouds are in place before pressing the reset switch to restart the motor. If the motor shuts down because of overload, wait 10–15 minutes so the motor can cool down, then press (NEVER force) the reset switch on the front of the motor to restart the motor.

  • Page 18: Electrical Power Requirements

    electrical power requirements Electrical Power Requirements ELECTRICAL WIRING Refer to the air compressor’s serial label for the unit’s voltage and amper- age requirements. Ensure that all wiring is done by a licensed electrician, in accordance with the National Electrical Code. Use electrical conduit to protect the wiring.

  • Page 19: Grounding Instructions

    electrical power requirements GROUNDING INSTRUCTIONS This product must be connected to a grounded, metallic, permanent wiring system, or an equipment - grounding terminal or lead on the product.

  • Page 20: Break-In Of The Pump

    break-in of the pump Break-In of the Pump BREAk-IN OF THE PUMP NOTICE • The pump is shipped with break-in oil which should be changed after the first 8 hours of operation. 1. Make sure the power is connected at the power panel. 2.
  • Page 21 break-in of the pump FIG 6 Open Close...

  • Page 22: Operating Instructions

    operating instructions Operating Instructions DAILY STARTUP 1. Check the oil level in the pump (see “Checking the Oil” in the maintenance section). 2. Make sure the main power disconnect switch is shut OFF. 3. Close the tank petcock (see E). 4.
  • Page 23 operating instructions CAUTION Escaping air and moisture can propel debris that may cause eye injury. Wear safety goggles when opening petcock. Open Close...

  • Page 24: Maintenance

    maintenance Maintenance WARNING • This unit starts automatically. ALWAYS shut off the main power disconnect, and bleed all pressure from the system before servicing the compressor, and when the compressor is not in use. Do not use the unit with the shrouds or belt guard removed. Serious injury could occur from contact with moving parts.

  • Page 25: Belt Tension And Pulley Alignment

    maintenance A = Full B = Add C = Oil drain plug D = Oil level sight glass E = Oil fill plug FIG 7 BELT TENSION AND PULLEY ALIGNMENT WARNING • This unit starts automatically. ALWAYS shut off the main power disconnect, and bleed all pressure from the system before servicing the compressor, and when the compressor is not in use.

  • Page 26: Pulley Alignment

    maintenance FIG 8 PULLEY ALIGNMENT To check pulley alignment, remove the belt guard and place a straightedge (see A) against the pump flywheel (see B) (See Fig. 9). Measure and record the distance from the straightedge to the edge of the drive belt at point C. Then measure the distance from the straightedge to the edge of the drive belt again at points D and E.

  • Page 27: Cleaning The Air Filter

    maintenance CLEANING THE AIR FILTER A dirty air filter will reduce the compressor’s performance and life. To avoid any internal contamination of the pump, the filter should be cleaned frequently, and replaced on a regular basis. Felt filters should be cleaned in warm, soapy water, rinsed, and allowed to air dry before reinstalla- tion.

  • Page 28: Maintenance Chart

    maintenance MAINTENANCE CHART PROCEDURE DAILY 100 HOURS Inspect and clean air filter Check pump oil level Change pump oil (use synthetic, non-detergent air compressor oil) Operate the pressure relief valves Check belt tension Drain tank Check and tighten all bolts...

  • Page 29: Troubleshooting

    troubleshooting Troubleshooting TROUBLESHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTION Excessive Low voltage/motor Check that power supply is current draw overload adequate and that compressor trips circuit is on a dedicated circuit. If using breaker of extension cord, try using without. motor reset If compressor is connected to a switch circut protected by a fuse, use...
  • Page 30 troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Overheating Poor ventilation Relocate compressor to an area with cool, dry, well circulated air, at least 12 in. from nearest wall. Dirty cooling surfaces Clean all cooling surfaces thoroughly. Restricted air passages Replace transfer tubes and/or unloader.

  • Page 31: Glossary Of Terms

    glossary of terms CFM: Cubic feet per minute; a unit of measure of air flow. PSI: Pounds per square inch; a unit of measure of air pressure. Kick-in pressure: Factory set low pressure point that starts the com- pressor to repressurize the tank to a higher pressure. Kick-out pressure: Factory set high pressure point that stops the com- pressor from increasing the pressure in the tank above a certain level.

  • Page 32: Parts List

    List of Parts COMPRESSOR Torque to 85-90 lb-in. Note: Tighten compression nut hand tight plus 1 full turn. Model No. Running Tank Capacity Voltage, Kick-In Kick-Out H.P. (GAL) Amps, pressure Pressure (CV) Phase AC5060B 60 (227,1) 230/15/1 (NLA3706056) (8,62 bar) (10,69 bar)
  • Page 33 parts list Item Part No. Description 125-0151 Beltguard (outer) 061-0114 Plastite screw 059-0255 Bolt, 5/16-18 x 1/2 125-0152 Beltguard (inner) 061-0238 Setscrew 146-0016 007-0037 V-Belt, 4L-530 006-0108 Pulley 026-0188 Cord, interconnect 059-0012 Bolt, 5/16-18 x .50 153-0123 Tank assembly (includes items 11A-13) 512-0041 Bushing, 2”...
  • Page 34 parts list 755H PUMP ASSEMBLY Torque to 25-27 lb-ft. Torque to 14-16 lb-ft. Torque to 9-12 lb-ft. Torque to 8 lb-ft. Torque to 5 lb-ft.
  • Page 35 parts list Item Part No. Description 059-0424 Screw, M4 x 8 060-0227 Lock washer, M4 042-0112 Inlet cover 118-0032 Screen 019-0220 Filter, felt 059-0425 Screw, M8x60 060-0222 Lock washer, M8 042-0108 Head assembly 059-0416 Screw, M8x35 046-0283 Gasket, head 043-0180 Valve plate assy (includes items 10 &...
  • Page 36 parts list 048-0116 Piston assembly 054-0235 Ring set Available Service Kits Part No Description 165-0264 Overhaul kit (includes 1-5, 8, 11, 35, 37 and 40) 042-0116 Head and valve plate assy (includes 1-5, 8, 10, 11 and 12) 046-0279 Gaskets, complete set (includes 10, 12, 15, 21, 27 and 29) 040-0354 Pump assembly (includes 1-37 excluding 30-33)

  • Page 37: Parts Drawing

    parts list PARTS DRAWING Torque to 17-24 lb-in. Torque to 125-150 lb-in. Item Part No. Description 032-0025 Gauge, 300# 1/4” bottom connect 034-0184 Switch, pressure 155 PSI (includes 3-4 and 7) 071-0033 Strain relief 061-0216 Screw 136-0077 Valve, ASME 062-0035 Plug, 1/4”...
  • Page 38 If you need assistance with the assembly or operation of your Compressor please call 1-866-770-1711...
