Page 1: Installation Guide
TV Adapter Installation Guide www.sonici.com... -
Page 3: Table Of Contents
Table of Contents Warnings Purpose of this Guide TV Adapter Overview Connecting to Power Connecting to TV Optional Adapters for Connecting to a TV Prepare SoundGate for TV Listening Using the SoundGate and Support Product Approval, Precautions and Markings International Warranty... -
Page 5: Warnings
If a part is swallowed, see a doctor immediately. The safety of the use of the TV adapter with an auxiliary input cable is determined by external signal source. When the input cable is connected to mains operated equipment, this equipment must comply with IEC-60065, IEC-60601 or equivalent safety standards. -
Page 6: Purpose Of This Guide
Before your Bluetooth enabled instruments can ® receive sound from the TV, the TV adapter must be connected to the TV and a power outlet. All needed parts for the installation are included in the packaging. -
Page 7: Tv Adapter Overview
TV Adapter Overview Back TV connection Power connection Front Status indicator Power indicator Light Meaning Light Meaning Solid Connected to Solid Power on SoundGate and Power off streaming TV sound Stand-by Flashing Pairing... -
Page 8: Connecting To Power
Connecting to Power Begin the installation by connecting power to the TV adapter. Use the power adapter from box no. 1. • Plug the power adapter into the wall socket or another power source. • Plug the power cord into the power connection marked A. -
Page 9: Connecting To Tv
Connecting to TV Connect the TV to the TV adapter. Use the TV cord from box no. 2. • Connect the black plug on the TV cord to the connector marked B. • Connect the red and white connectors to the “AUDIO OUT”... -
Page 10: Optional Adapters For Connecting To A Tv
Optional Adapters for Connecting to TV Option 1: SCART connection If an adapter must be used for connecting the TV cord to the TV set, this is found in box no. 3. If the installation was completed in step 2, box no. 3 should not be used! SCART connection using the SCART adapter. - Page 11 Optional Adapters for Connecting to TV Option 2: Head phone connection Head phone connection using the jack adapter. • Connect the TV cord to the jack adapter and plug it into the TV’s head phone output. The head phone output may be found on the side or front of the TV.
-
Page 12: Prepare Soundgate For Tv Listening
The very first time your SoundGate is used with the TV adapter, the two devices must be paired together. Pairing In order to pair the TV adapter and the SoundGate, the devices must be placed close together. Place the SoundGate right next to the TV adapter (less than 1 ft / 30 cm between devices). -
Page 13: Using The Soundgate And Support
The TV adapter uses very little power so it is not necessary to turn it off. TV sound range The TV adapter has a range of about 30 feet / 10 meters, depending on room furniture and placement. Connection with SCART adapter... -
Page 14: Product Approval, Precautions And Markings
Product Approval, Precautions and Markings The emission power from the TV adapter is below international emission limits for human exposure. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and... - Page 15 frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or...
- Page 16 This TV adapter is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Declaration of conformity is available at: Sonic Innovations, Inc. 2501 Cottontail Lane Somerset, NJ 08873 www.sonici.com Only use the power adapter that was originally supplied...
-
Page 17: International Warranty
The TV adapter has a limited warranty, covering defects in materials and workmanship. This warranty covers the TV adapter itself, but not accessories such as charger units, cables, etc. This warranty becomes invalid if a defect is a result of misuse or maltreatment. - Page 18 Notes...
- Page 19 Notes...
- Page 20 Morgenstrasse 131B Somerset, NJ 08873 USA 3018 Bern, Switzerland +1 888 423 7834 +41 31 560 21 21 Australia Canada Sonic Innovations Canada Ltd. Sonic Innovations Pty Ltd. 3 Unley Road 920 Industriel Blvd. Terrebonne, Quebec Parkside, SA 5063 Australia...
