- Page 1 www.philipscsi.com O b s e r v a t i o n S y s t e m V S S 7 3 9 0 / 0 0 T S w i t c h e r I n s t a l l a t i o n I n s t r u c t i o n s...
- Page 2 Page English ............................3 French............................15 German ............................27 Spanish ............................39 Dutch ............................51 Italian............................63 Portuguese..........................75 Danish............................87 Finnish............................99 Norwegian..........................111 Swedish............................123 Greek ............................135...
-
Page 3: Table Of Contents
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R C O N T E N T S SECTION 1 GENERAL SAFETY PRECAUTIONS . -
Page 4: Safety Precautions
(including amplifiers) that produce heat. Note: Any change or modification not expressly approved by Philips of the Do not defeat the safety purpose of the polarized or grounding-type plug. -
Page 5: Hardware Installation
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R S E C T I O N 2 I N S TA L L AT I O N HARDWARE INSTALLATION SYSTEM CONNECTION... -
Page 6: Vcr In/Output
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R Connect the BNC connectors to the video in and WIZARD INSTALLATION video output of the VCR or CVBS monitor. -
Page 7: System Settings
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R When completed the following screen will appear: 2.4.3 Sequence You can change the sequence dwell time from 02 sec to C O N F I G U R A T I O N... -
Page 8: Aux Output
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R MOTION The camera detects motion 2.4.5 Aux output within the defined motion area. -
Page 9: Vcr
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R SEQUENCE The presentation is sequenced 2.4.7 Installation with a live camera image when... -
Page 10: Motion Sensitivity
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R REMOTE Can be selected ON or OFF to AUTO - White balance is CONTROL... -
Page 11: Service
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R 3. Walkthrough motion area (motion indicator 2.4.10 Disable System Setting Option indicates level of motion). - Page 12 P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R Section 2 - Installation...
-
Page 13: Electrical
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R S E C T I O N 3 T E C H N I C A L S P E C I F I C AT I O N S APPROVALS AUX/VCR... - Page 14 P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R...
- Page 15 3122 165 22151 01-17 © 2001 by Philips Electronics N.V. © 2001 by Philips Communication, Security & Imaging, Inc. ® All Rights Reserved. Philips is a registered trademark of Philips Electronics N. A. Corp. Data subject to change without notice...
- Page 16 www.philipscsi.com O b s e r v a t i o n S y s t e m V S S 7 3 9 0 / 0 0 T S w i t c h e r O p e r a t i o n I n s t r u c t i o n s...
- Page 17 Page English ............................3 French............................11 German ............................21 Spanish ............................31 Dutch ............................41 Italian............................49 Portuguese..........................57 Danish............................67 Finish ............................75 Norwegian..........................83 Swedish............................91 Greek ............................99...
- Page 18 P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R C O N T E N T S SECTION 1 - GENERAL SAFETY PRECAUTIONS .
-
Page 19: Safety Precautions
Consult the dealer or an experienced radio/ TV technician for help. 15. The equipment shall not be exposed to dripping or splashing and that no Note: Any change or modification not expressly approved by Philips of the objects filled with liquids, such as vases, shall be placed on the equipment. - Page 20 Instructions supplied. Playback detection When you switch on the VCR playback, the system will The Philips Observation System is a sophisticated, easy- automatically detect the VCR and to-operate observation and security system. Up to 4 will display the VCR images.
-
Page 21: Basic Operation
The LED colour changes accordingly. The functional operation of the Philips Observation System Switcher is as follows. An alarm generated in night mode will be processed by the system after the entry delay time is expired. -
Page 22: Picture-In-Picture (Pip)
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R The talk function is only functional in combination 2.1.10 Picture-In-Picture (PIP) with an intercom box (optional). -
Page 23: Switching Between Playback And Live
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R The following view settings can be altered: 2.2.1 Switching between playback and live PIP POSITION Set PIP (Picture-In-Picture) to... -
Page 24: Alarm Functions
P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R ALARM FUNCTIONS 2.3.2 Recorded Alarms The alarm function can be enabled or disabled in the During playback the recorded alarms will be visible. - Page 25 P H I L I P S O B S E RVAT I O N S YS T E M V S S 7 3 9 0 / 0 0 T S W I T C H E R...
