InFocus RealCam Assembly Guide
1
®
Sony
EVI-HD7V
?
www.infocus.com/support
Connect the RealCam Adapter to the
2
camera and Mondopad device
Connect to the Mondopad
device's USB port
InFocus
®
RealCam
Adapter
Connect to the
camera's DVI
video port
Connect to the camera's
VISCA port
Connect the power cord to the camera
3
i
IMPORTANT INFORMATION:
•
The camera is pre-configured for the recommended resolution of
1920x1080@29.97fps. To confirm this setting, verify that that the blue
System Select switch on the back of the camera is set to "1." Additional
details can be found in the Sony user manual.
•
The Sony EVI-HD7V camera does not contain an embedded microphone. An
external microphone like the ClearOne
series must be used.
•
The Sony EVI-HD7V camera is warranted through Sony.
•
To install the RealCam camera kit (p/n INF-SPTZ) on the top of your
Mondopad device, you will need the INF-PTZMNT. The INF-VIDSHELF can
also be used (compatible with the INF-FLRSTAND and the INF-MOBCART
only).
•
To use the camera kit (p/n INF-SPTZ) on a shelf below the Mondopad
device, you will need the INF-ACCYSHELF (compatible with both the INF-
FLRSTAND and INF-MOBCART) or the INF-ACCYSHELFPRO-x (compatible
with the INF-MOBCARTPRO-x).
www.infocus.com/support
®
®
Chat
series or the Jabra SPEAK™
