Central Pneumatic 95386 Operating Instructions Manual

Central Pneumatic 95386 Operating Instructions Manual

8 gallon 2 hp air compressor

Advertisement

AIR COMPRESSOR

OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
©
Copyright
2006 by Harbor Freight Tools
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
8 GALL
8 GALL
ON 2 HP
ON 2 HP
8 GALL ON 2 HP
ON 2 HP
8 GALL
8 GALL
ON 2 HP
Model 95386
®
. All rights reserved. No portion of this

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 95386 and is the answer not in the manual?

Questions and answers

Bill Williams
February 19, 2025

I need to order a capacitor for this compressor.

Subscribe to Our Youtube Channel

Summary of Contents for Central Pneumatic 95386

  • Page 1: Air Compressor

    8 GALL 8 GALL ON 2 HP AIR COMPRESSOR Model 95386 OPERATING INSTRUCTIONS Due to continuing improvements, actual product may differ slightly from the product described herein. 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at: http://www.harborfreight.com ©...
  • Page 2: Product Specifications

    Failure to follow all instructions listed below may result in electric shock, fire, and/or serious injury. SAVE THESE INSTRUCTIONS WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. SKU 95386 For technical questions, please call 1-800-444-3353. Page 2...
  • Page 3: Electrical Safety

    Do not use a power tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury. SKU 95386 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4 Do not use a damaged tool. Tag damaged tools “Do not use” until repaired. SKU 95386 For technical questions, please call 1-800-444-3353. Page 4...
  • Page 5: Grounded Tools: Tools With Three Prong Plugs

    The green wire in the cord must be the only wire connected to the tool’s grounding system and must never be attached to an electrically “live” terminal. (See Figure A.) SKU 95386 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6: Double Insulated Tools: Tools With Two Prong Plugs

    Association, and the National Electrical Code. (See Figure B.) Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration. (See Figure B.) FIGURE B SKU 95386 For technical questions, please call 1-800-444-3353. Page 6...
  • Page 7: Extension Cords

    Always replace a damaged extension cord or have it repaired by a qualified electrician before using it. Protect your extension cords from sharp objects, excessive heat, and damp or wet areas. SKU 95386 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Specific Safety Rules

    Make sure to fill the Air Compressor with a premium quality, 30-weight, non-detergent, compressor oil before each use. Running the Air Compressor with no oil or low oil will cause damage to the equipment and void the warranty. SKU 95386 For technical questions, please call 1-800-444-3353. Page 8...
  • Page 9 Operation of electrical equipment in close proximity to a heart pacemaker could cause interference or failure of the pacemaker. Do not leave the Air Compressor running while it is unattended. SKU 95386 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10: Operating Instructions

    Oil Sight Gauge (33). (See Figure D, next page) If the level of oil is below the red circle, carefully unscrew and remove the Oil Plug (31) and SKU 95386 For technical questions, please call 1-800-444-3353.
  • Page 11: Top View

    Air Outlet Valve of the Air Compressor to the air tool. (See Figure F.) CLOSED POSITION TOP VIEW OPEN POSITION OUTLET VALVE CONNECT (63) AIR HOSE HERE. FIGURE F SKU 95386 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12 Pull out and then turn the pressure adjustment knob above the Outlet Pressure Gauge (60) to the left to increase output air pressure or to the right to decrease output air pressure. Once the pressure level reaches the recommended SKU 95386 For technical questions, please call 1-800-444-3353. Page 12...
  • Page 13 - as explained on page 7. RESET BUTTON (19) Figure I SKU 95386 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Inspection And Maintenance

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 95386 For technical questions, please call 1-800-444-3353.
  • Page 15: Parts List

    Screw M8x30 Crank Unload pipe Screw M12x12 Outlet valve Crankcase cover gasket Cord and plug Oil plug Drain valve Crankcase cover Rubber foot Oil sight gauge Screw M8x25 Screw M5x12 SKU 95386 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16: Assembly Diagram

    THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 95386 For technical questions, please call 1-800-444-3353. Page 16...
