  • Page 2: User Manual

    User Manual www.mobisat.it Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it Mobisat - GPS Tracker M102 PRO - User guide - www.mobisat.it...
  • Page 3 MOBISAT - GPS Tracker M102 PRO This manual will show in detail all the product features. For a proper use, we recommend a thorough reading of the entire manual. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 4: Table Of Contents

    - Auto Track 6.13 - Environmental surveillance 6.14 - Geographic fencing 6.15 - Movement alarm 6.16 - Speed alarm 6.17 - IMEI number 6.18 - Button SOS 6.19 - Antishock sensor Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 5 - Precautions - Solutions in case of malfunction (Troubleshooting) - After sales service & warranty - Accessories supplied - Instructions for use and disposal - EC Declaration of Conformity Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 6: What Is It

    Thanks to its small size, it can be installed anywhere and on any vehicle just in a few minutes. MOBISAT - GPS Tracker M102 PRO houses inside it a common SIM card (not supplied), also a prepaid card. Tracking it is as simple as making a phone call.

  • Page 7: Applications

    Sports: cross-country skiing, equestrianism, trekking, paragliding, ultra light aviation, competition management: running, cycling and car races, etc. Applied to animals for research. Professional or personal investigation. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 8: Functions

    FLEET MANAGEMENT ANTISHOCK SENSOR ADVANCED ADMIN MANAGEMENT MOVEMENT ALARM EMERGENCY ENVIRONMENTAL LISTENING GEO FENCE - GEOGRAPHIC FENCING SPEED ALARM - SPEED CONTROL SOS BUTTON BATTERY ALERT SD MEMORY CARD SLOT Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 9: Hardware

    4 - Hardware GPS antenna Power supply Indicator light SOS button On/Off button Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 10: Technical Features

    - In-built GSM and GPRS antenna - In-built active GPS antenna - Battery max life: 48 hours in standby - Size: 44x63x24,5mm - Weight: 50g - Optimal temperature: -20°C to +55°C Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 11: Use

    - Subscription SIM cards - Data SIM cards Important: GPS Tracker M102 PRO can house tri-band SIM cards only (900/1800/1900MHz). You cannot use the device with operators that use 3G band. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 12: Installing The Sim Card

    6 - Use 6.4 - Installing the SIM card Before inserting the SIM card into your GPS Tracker M102 PRO, make sure that: - there is not a PIN set to access the SIM card - the call diverting service is not enabled...

  • Page 13: Starting The Device

    6 - Use 6.5 - Starting the device After inserting the SIM card into your GPS Tracker M102 PRO - when the battery is fully charged - you can start using the device. GPS Tracker M102 PRO will start working immediately after inserting the battery.
  • Page 14 6 - Use 6.5 - Starting the device (Continued) Wait 5 minutes so as to allow GPS Tracker M102 PRO to pick up signals from the greatest possible number of satellites (this procedure must only be executed for the first use. Afterwards you can query the device in real time).

  • Page 15: Interpreting The Sms Message

    6 - Use 6.6 - Interpreting the SMS message GPS Tracker M102 PRO has just sent you an SMS message of this type: lat: 45.443113 long: 9.178747 speed: 000,0 25/10/09 11:50 F:3.83V,0, Signal:F imei: 354776033382695 04 222 01 4E27 161D Interpreting the message: Lat: 45.443113 - Latitude...

  • Page 16: Checking The Position

    The data must be typed in exactly how you received them, separated by a space (as above). Click on button: “Search on maps” Google will show you the current position of your tracker. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 17 9 - Solutions in case of malfunction (Troubleshooting). Important: Failing the numbers authorized to query GPS Tracker M102 PRO, any phone number will be able to track the device by simply making a call to the SIM card inserted in this latter. Should there be an authorized number, all call attempts made from unauthorized numbers would not receive any answer.

  • Page 18: Power User

    Once you have received the correct position, you can register as Power User. The device works properly only if the Power User’s figure has been defined. MOBISAT - GPS Tracker M102 PRO can answer 1 Power User and 4 Administrators. 1 POWER USER 4 Administrators...
  • Page 19 “quotes” are not part of the message. In order to remove the Power User or an administrator, send the following SMS message: “noadmin+password+space+mobile No.” Example: “noadmin123456 +44333001122” Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 20 6 - Use 6.8 - Registering the Power User and 4 administrators (Continued) If the operation has been successful, your GPS Tracker M102 PRO will reply by sending the following SMS message: “Admin OK!” Power User is the only administrator who can:...

  • Page 21: Admin Management

    - Movement alarm - Shock sensor - Geographic fencing - Speed alarm All the relevant alert messages will be sent to all the registered administrators and to the Power User. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 22 Power User. We suggest that you do not use this system for the Power User’s registration, but to proceed as indicated in chapter 6.8. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 23 Satellites uses the Greenwich Meridian Time. MOBISAT - GPS Tracker M102 PRO is set to display 1 hour ahead of Greenwich Mean Time (GMT +1). User will have to specify to the device the current time zone for his/her country.
  • Page 24 Example: let us suppose you choose as new password the following numeric combination: “000111”, and that you want to replace with this the factory default password (set by the parent company): “123456”. Send the following SMS message: “password123456 000111” Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 25 6.12 - Auto Track In case of emergency, authorized users will be entitled to request GPS Tracker M102 PRO to send an SMS message with the geographic position every so many seconds. The message will be sent a given number of times (up to a maximum of 255 messages).
  • Page 26 Now you can call the phone number of the SIM card inserted into GPS Tracker M102 PRO. In the mute and anonymous mode, the device will accept the call in order to allow you to listen to what is happening in the surrounding environment.
  • Page 27 To go back to the “tracker” mode, send the following SMS message: “tracker+password” If the operation is properly executed, you will receive the following SMS response message: “Tracker OK!” Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 28 6.14 - Geographic fencing It is possible to trace out a geographic area which your GPS Tracker M102 PRO will not be able to leave. In case of border violation, your GPS Tracker M102 PRO will send an alarm SMS message: “stockade!+geographic information”...
  • Page 29 YES: longitude,latitude NO: latitude,longitude Check the exact matching of the coordinates used in the example. To remove the control relevant to the geographic fencing, send the following SMS message: “nostockade+password” Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 30 6 - Use 6.15 - Movement alarm It is possible to request GPS Tracker M102 PRO to store the last position reached (e.g. the car park). An SMS alarm message is only sent in the event that the geographic position recorded by GPS Tracker M102 PRO does not correspond to the one you have stored (e.g.
  • Page 31 6 - Use 6.16 - Speed alarm It is possible to set GPS Tracker M102 PRO in order to receive an SMS message every time a given speed limit is exceeded, e.g.: 80 Km/h. To start this mode, send the following SMS message: “speed+password+space+080”...

  • Page 32: Imei Number

    6 - Use 6.17 - IMEI number The IMEI number is the unique serial number of GPS Tracker M102 PRO. To know the IMEI number, send an SMS message as follows: “imei+password” 6.18 - SOS button By pressing the button SOS for approx. 5 seconds, your GPS Tracker M102 PRO will send to all the authorized numbers the following message: “Help me!+geographic information”...
  • Page 33 6 - Use 6.19 - Shock sensor Your GPS Tracker M102 PRO has a shock sensor with 10 user- adjustable sensitivity levels. This allows you, in case of theft, to be warned immediately upon the occurrence of any tampering with your vehicle, even before this is set in motion and taken away.
  • Page 34 SMS message: “shake+password+space+value from 1 to 10” For instance, if you wish your GPS Tracker M102 PRO to send all administrators an alert message in the event of the occurrence of a road accident, send the following SMS message: “shake123456 1”...

  • Page 35: Sms Message With Hyperlink

    SOS button, you will not receive an SOS message with the words “help me!+ geographic coordinates”, but you will receive the SOS message with the hyperlink and geographic coordinates without the words “help me!”. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 36: Low Battery Alarm

    6 - Use 6.21 - Low battery alarm In each message, MOBISAT - GPS Tracker M102 PRO returns the value in voltage of the remaining charge of the lithium battery. This will help you keep always under control the battery level.
  • Page 37 6 - Use 6.22 - SMS Central (Continued) Each time an authorized number queries GPS Tracker M102 PRO, the following SMS message will be sent to the “SMS Exchange”: “authorized number+geographic information” To disable this function, send the following SMS message: “noadminsms+password”...

  • Page 38: Fleet Management

    You will have to register at the Website: “http://mappe.mobisat.it” then register every device you want to enable. Each GPS Tracker M102 PRO unit is unique, as it is linked to two identification numbers: - the IMEI No. - the activation key These codes can be found on the product packaging.

  • Page 39: Settings Gprs

    6 - Use 6.24 - Settings GPRS MOBISAT - GPS Tracker M102 PRO is able to communicate its position by sending SMS messages and string data through the GPRS protocol. In the latter case, the device connects to the Internet and sends its position to a server (a computer), which will interpret the string data in graphic locations on the geographic map.
  • Page 40 - send a minimum of 50mb of GPRS traffic per month To use GPS Tracker M102 PRO in GPRS mode, you will need to set the IP port of the server to which it sends the data and the APN (Access Point Name) of the telephone company owing the SIM card you have inserted into your device.
  • Page 41 To start the GPRS connection with the access point of the telephone operator, send the following SMS message: “apn+password+space+apn of the telephone operator” Example: “apn123456 ibox.tim.it” Please refer to the APN settings of the main telephone operators in your country. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 42 6 - Use 6.24 - GPRS Settings (Continued) GPS Tracker M102 PRO can be set to send its position constantly by SMS or GPRS (e.g. every 60 seconds 24 hours a day). If your vehicle is left parked in the same position all night long, it would be inappropriate (as well as an economic waste) to receive the position constantly every 60 seconds.
  • Page 43 6 - Use 6.24 - Settings GPRS (Continued) If you call the number of the SIM installed in GPS Tracker M102 PRO, your call will be interrupted and the device will send its position to the server. Now you can send an SMS message to the device in order to start a GPRS constant data transmission.
  • Page 44 To disable this function, send the following SMS message: “notracking+password” Warning: if you have set this function, you will no more receive the SOS messages when sent from areas where the GPS signal is not “Full”. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 45 6 - Use 6.24 - GPRS Settings (Continued) Developers wishing to integrate GPS Tracker M102 PRO with their own applications will find the explanation of the values contained in the GPRS strings sent by the device useful. String example: 091215095929,+44346111222,GPRMC,085929.000,A,4537.6231,N,00924.8287,E,0.00,,151209 ,,,A*78,F,, imei:354776034541026,07,253.0,F:3.86V,0,135,8254,222,88,2726,3615...

  • Page 46: Micro Sd Card

    Afterwards you will have to tell the device to send the data stored to the server. Proceed sending the following message: “readsd+password+space+1” (readsd123456 1) The device will start sending the data stored on the micro SD card to the server. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 47: Resetting The Device

    GPS chip will reset. Through this procedure, both password and time zone will not be reset. Should GPS Tracker M102 PRO stops responding to the SMS commands, it is possible to reset only the GSM module by sending the following SMS message: “wdttest+password”...

  • Page 48: Low Power Mode

    The device will go on/off automatically every time it connects with the satellites. This will imply an extension of the life of the inner lithium battery. To disable this function, send the following SMS message: “lowpowermode123456 0”. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 49: Installation On A Vehicle

    The installation of the device on a vehicle must be carried out in such a way as to allow that GPS Tracker M102 PRO will receive a good signal from the satellites. In any case, the upper part of the device (where the logo is) should be held facing upwards.
  • Page 50 To obviate this problem, GPS Tracker M102 PRO can be powered directly from the vehicle battery. This is possible thanks to the special cable supplied, so that you can hide GPS Tracker M102 PRO inside the dashboard or wherever you deem appropriate, without taking care to recharge the battery, which will be constantly powered by the car battery.

  • Page 51: Precautions

    Chapter: 5 - Technical features. - Handle with care - Do not use detergents to clean GPS Tracker M102 PRO. Instead, use a dry cloth. - Do not paint, color or change the device in any way (the warranty becomes void if tampered with).

  • Page 52: Solutions In Case Of Malfunction (Troubleshooting)

    Solution: - make sure there is credit in the SIM card inserted into the device. - make sure that you are calling GPS Tracker M102 PRO from an authorized number. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 53 SMS message. Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it Mobisat - GPS Tracker M102 PRO - User guide - www.mobisat.it...

  • Page 54: After Sales Service & Warranty

    2 years. For technical support on the product, please send an e-mail to the following address: info@mobisat.it Warranty terms and rules for replacement are indicated on the Website: www.mobisat.it Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...

  • Page 55: Accessories Supplied

    11 - Accessories supplied: MOBISAT - GPS Tracker M102 PRO is sold supplied with the following standard accessories: Lithium batteries: BL-5B In the box you will find 2 lithium batteries BL-5B. A battery should always be left inside the device, even in the case that you have permanently installed GPS Tracker M102 PRO in your vehicle with the cable supplied for costant charging from 12/24V batteries.
  • Page 56 1000mA Made in China Connection diagram Car power supply cable: Car Battery Charger MnM S.r.l. - Mobisat Model: M102CBC Input: 9 - 24V Output: 5V 1000mA Made in China Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 57 Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it Mobisat - GPS Tracker M102 PRO - User guide - www.mobisat.it...

  • Page 58: Declaration Of Conformity

    Art. 6.3 of Directive 99/5/EC: “Herewith MnM S.r.l. declares that this (type of equipment) meets the essential requirements and other relevant provisions according to Directive 1999/5/EC.” Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
  • Page 59 MnM S.r.l. Via Ascanio Sforza, 79 20141 - Milan VAT ID No.: 05879140969 E-mail: info@mobisat.it www.mobisat.it Mobisat - GPS Tracker M102 PRO - User Manual - www.mobisat.it...
