Summary of Contents for MOBISAT ROCK
- Page 1 MOBISAT - SATELLITE PROTECTION AND TRACKING SYSTEMS ® ROCK User manual – V2.0.3 THANK YOU! FOR CHOOSING ROCK MOBISAT ® THIS MANUAL OUTLINES IN DETAIL ALL THE SERVICES OFFERED BY THE PRODUCT. FOR THE PRODUCT'S PROPER USE, WE RECOMMEND READING THE ENTIRE MANUAL THOROUGHLY.
-
Page 2: Legal Notes
The nominal voltage is 12V DC To avoid mechanical damage, we recommend carrying ROCK in a shockproof container/pack. Before using ROCK, set the device so as to be able to comfortably view the LED indicators, which show the device's operating status ... -
Page 3: Product Description
GSM/GPRS network. ROCK is equipped with integrated antennas (GNSS and GSM), a 3D accelerometer (for "Black-Box" functionality ) and a Lithium Nickel backup battery. ROCK is suitable for all applications that require the remote tracking of objects. - Page 4 Deep Sleep: On average, less than 2mA Operating temperature: -25°C to +55°C Storage temperature: -40°C to +70°C Relative humidity for storage : 5 ... 95% (No condensation) MOBISAT ROCK - User Manual v.2.0.3 - www.mobisat.eu - Page 4 of 16 ®...
-
Page 5: Electrical Specifications
Supply Voltage (Absolute Max. Value) Drain-Source clamp threshold voltage (Absolute Maximum Ratings), (Idrain = 2mA) Digital Input voltage (Absolute Maximum Value) Analog Input Voltage (Maximum Absolute Value) MOBISAT ROCK - User Manual v.2.0.3 - www.mobisat.eu - Page 5 of 16 ®... -
Page 6: Sim Card
® To calculate consumption for the cards when connecting to the Mobisat Greenbox service, establish how often you want to receive a position from the GPS tracker. Although sending 1 position has a weight of just a few bytes, the operator charges for 1Kb for each connection (similar to a flat fee per answered call). -
Page 7: Inserting The Sim Card
6 – Close the unit as indicated in the picture below. (see picture 4), taking care to also screw the GSM antenna between the motherboard and the product body. MOBISAT ROCK - User Manual v.2.0.3 - www.mobisat.eu - Page 7 of 16 ®... -
Page 8: Navigation Led
Analog Input: Channel 1. Input Range 0-30V / 0-10V DC DATA_DALLAS Data Channel for Dallas 1-Wire devices ® DIN 3 Digital Input. Channel 3 Ucc_DALLAS + 3,8 V output for devices Dallas 1-Wire® (max 20mA) MOBISAT ROCK - User Manual v.2.0.3 - www.mobisat.eu - Page 8 of 16 ®... -
Page 9: Types Of Installation
Caution: The mains connection must be at a very low impedance point in the vehicle's electrical system. On a car, these points are the battery terminals. Therefore, it is advisable to connect the power supply for ROCK (GND and POWER cable) directly to the battery terminals. -
Page 10: Optional Accesories
ROCK cannot be installed onto moveable or overheated parts The SIM card must be inserted when the connector is unplugged (ROCK is not powered on) The GNSS antenna is under the logo, and should therefore face upwards. It is not advisable to install the device at a point that is more than ¾... - Page 11 External alarms (e.g. sirens), panic buttons, sensors that detect the opening of doors, the vehicle ignition, etc., always detect 2 states: High or Low Voltage. The digital input 2 (DIN2) on ROCK is used to read this information. The figure below shows the wiring diagram of a Panic Button, open door sensor, etc.
- Page 12 All commands can be transmitted as an SMS from any mobile phone. 2. ALL LOWER CASE ROCK's operating system recognizes and discriminates the use of characters in Upper and Lower case. All SMS commands MUST be transmitted in lowercase. 3. SPACES ARE IMPORTANT Each command is made up of characters and <spaces>.
- Page 13 "Immobilizer" scenario (an ® SMS command). IMMOBILIZER SCENARIO COMMANDS ENABLE THE IMMOBILIZER SCENARIO: <space><space>setparam<space>1601<space>2 DISABLE THE IMMOBILIZER SCENARIO: <space><space>setparam<space>1601<space>0 MOBISAT ROCK - User Manual v.2.0.3 - www.mobisat.eu - Page 13 of 16 ®...
- Page 14 We recommend not changing the amplitude of the Autogeofence radius in order to prevent the triggering of "false alarms." False alarms can be generated in cases where the vehicle on which ROCK is installed is parked indoors or in a shaded area (where the satellite network is inaccessible).
-
Page 15: Troubleshooting
(from one to a virtually infinite number of vehicles). TO ACCESS THE SERVICE To connect ROCK to the Greenbox service, you must register the device using the two codes found on the product's packaging: the IMEI no. -
Page 16: Warranty And Support
WARRANTY AND SUPPORT ROCK has a 2-year warranty. For technical support on the product visit: http://www.mobisat.eu/support, register (if you do not already have access credentials) to open a support ticket, indicating: the cause of the problem the product's IMEI no.
