ATD Tools ATD-6810 Instruction Manual

Spray gun w/cup

ATD-6810

SPRAY GUN W/CUP

INSTRUCTION MANUAL

Read this Instruction Manual carefully and understand it completely, basic precaution

should be strictly followed to prevent the damage to the tool and injury to the operator.

Retain this manual for further reference. And you should pay more attention to the

Technical Data.

Description

A High pressure spray gun is ideal for refinishing a classic car or a wide variety of home improvement

projects. This high pressure paint sprayer features air, fluid and fan controls to offer a wide variety of patterns.

It is supplied with a 1000 cc suction feed aluminum cup.

Technical Data

Type of Feed: Suction

Air Inlet: 1/4"

Standard Diameter of Nozzle: φ2.0mm

Optional Diameter of Nozzle: φ1.5~2.5mm

Recommended air pressure: 3.0~ 4.0 bar (45-60psi)

Max. Pressure of air: 8.3 bar (120psi)

Paint Capacity: 1000cc

Avg. Air Consumption: 170-250l/min (6.0-8.8cfm)

Pattern Width: 180-230mm (7.1-9.1")

Weight: 1.1kgs (2.42lbs)

A-weighted sound pressure level: 77.1dB(A)

Sound power level: 88.1dB(A)

Table of Contents

Do you have a question about the ATD-6810 and is the answer not in the manual?

Page 1: Technical Data
ATD-6810 SPRAY GUN W/CUP INSTRUCTION MANUAL Read this Instruction Manual carefully and understand it completely, basic precaution should be strictly followed to prevent the damage to the tool and injury to the operator. Retain this manual for further reference. And you should pay more attention to the Technical Data.
Page 2: Important Safety Instructions
Important Safety Instructions 1. For toxic vapors produced by spraying certain materials can create intoxication and serious damage to health. Always wear safety glasses, gloves and respirator to prevent the toxic vapor hazard, solvent and pointing paint coming into contact with your eyes or skin. 2.
Page 3: Maintenance
Adjustment The desired pattern, volume of fluid output and fine atomization can easily be obtained by regulating the Pattern Adjusting Knob, Fluid (PAINT) Adjusting Knob and Air Adjusting Knob. Adjusting pattern: Turning the Pattern Adjusting Knob to the right until tight will make spray pattern round and turning it to the left will make spray pattern ellipse.
Page 4: Troubleshooting
Storing When not using spray gun, turn the fluid adjustment knob counter-clockwise to open which will reduce spring tension on needle fluid tip. Spray gun MUST BE well cleaned and lightly lubricated. Troubleshooting Symptom Problems Solution Fluttering or Material level too low. Add material into container.
