- Page 1 MMSV58 5.8” LCD MONITOR OPERATION MANUAL 1287159.p65 8/4/2004, 11:08 AM...
- Page 2 System adjustments can be accomplished using the remote control unit, while seatbelts remain fastened. Enjoy your Movies 2 Go entertainment system but remember-safety of all passengers remains the number one priority.
- Page 3 Congratulations on your purchase of the Movies 2 Go MMSV58 Video Monitor . The MMSV58 has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product and to ensure that you obtain the best results from your equipment.
-
Page 4: Controls And Indicators Diagram
CONTROLS AND INDICATORS DIAGRAM POWER COLOR BRIGHT LAMP 1287159.p65 8/4/2004, 11:08 AM... -
Page 5: Main Function Description
MAIN FUNCTION DESCRIPTION Power Button To turn the MMSV58 ON and OFF. Color Up/Down Button To increase and decrease the color intensity. Bright Up/Down Button To increase and decrease the brightness. Sensor Eye Allows Remote Control operation of the MMSV58. -
Page 6: Remote Control Operation
3) Align the cover tabs with the remote control and press down until the cover clicks. The remote control will operate the MMSV58. It is not a universal remote control and will not control equipment from other manufacturers. If a universal remote control is to be... - Page 7 REMOTE CONTROLLED MONITOR Functions Power Button Press this button to turn the MMSV58 ON. The current video source will be displayed on screen and the picture will appear in a few seconds. Press the button again to turn the MMSV58 OFF.
-
Page 8: Operation
OPERATION VANITY LIGHT The light integrated into the MMSV58 is controlled by a two position slide switch. Sliding the switch to the on position will turn the light on. The off position will prevent the light from turning on. Do not leave the vehicle unattended with the vanity light switch in the on position, as this could result in a discharged battery. -
Page 9: Video Inputs
The AV1 and AV2 inputs can be connected to any AV source. Press the source button on the remote to select from Video 1 and Video 2. BACKUP CAMERA OPTION The MMSV58 has the capability of displaying an image from optional back up camera (Audiovox P/N VCCS130) on either Video 1 and Video 2 . -
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION • IR sensor inoperative Verify that the batteries in the remote are fresh. • Verify that the remote sensor eye is not obstructed. • No power Make sure vehicle is in park or vehicle’s parking brake is applied. No picture •... -
Page 11: Specifications
SPECIFICATIONS LCD BacklightingEdge Light Tube Resolution 400 X 234 Pixels 93,600 Operation Temperature-10 ~ 60º C (14°~140°F) Storage Temperature-30 ~ 70º C (-22° ~ 158°F) Expected Backlight life10,000 Hours Video Display SystemNTSC / PAL Overall Dimensions 10.75" X 5.25" X.75" 1287159.p65 8/4/2004, 11:08 AM... -
Page 12: 12 Month Limited Warranty
12 MONTH LIMITED WARRANTY Applies to AEC Mobile Video Products AEC (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
