Related Manuals for LG MFL62881369
Summary of Contents for LG MFL62881369
- Page 1 INSTALLATION MANUAL LCD TV / LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. P/NO: MFL62881369 (1103-REV00) www.lg.com Printed in Korea...
-
Page 3: Table Of Contents
LG Hotel Mode Setup . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’ . The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators . -
Page 5: Lg Hotel Mode Setup
▼ MCU Version 3 . 1 0 Use the button to select the LG Hotel Mode Setup . Use the OK button and then button to select Hotel Mode Operation . *When ' Hotel Mode Operation' is set to Yes(Work), all functions of Hotel Mode apply . - Page 6 (3) Setup Menu Display - Decide to enter 'Setup Menu Display' or not in the 'Main Menu' by setting 'Setup Menu Display' as Yes(Enter Possible) or No(Enter Impossible) on the "LG Hotel Mode Setup" OSD . (4) Programme Change - Decide to change channel or not by setting 'Programme Change' as Yes(Change Possible) or No(Change Impossible) when present source is TV .
- Page 7 - Decide whether work the LG remote control or not . - Set to Yes(Work) or No(Do Not Work) . - When ‘LG IR Operation’ is set to NO(Not Work), all keys don’t work . - Although set to No, it can work in Service mode .
- Page 8 Installation Menu LG Hotel Mode Setup (12-2) Programme - If the Input source is DTV or ATV, the set programme is played when the power is turned on . - Only when the Input source is DTV or ATV, it can be entered into the Programme item .
- Page 9 Active De-active Initial Hotel Mode Operation Power On Status Setup Menu Programme Change Input Source Change Menu Display OSD Display LG IR Operation Local Key Operation Max Volume 0~100 DTV Channel Update Auto Manual Auto Power On Default Input Source...
-
Page 10: Tvlink-Loader
In addition to this, TVLink-Loader enables to load programme for menu installation with wireless basis . Image shown may differ from your TV . Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader TV Link-Loader Password Change... - Page 11 USB Cloning Procedure - Introduction (1) Overview USB Cloning Procedure Commercial TVs have the capability to support cloning internal TV data and programme information with an external clone device called “TVLink-Loader”, in order to copy TV data accurately and quickly. The clone internal functions use slightly different internal processes for the two types of commercial TVs .
- Page 12 Installation Menu Send To USB Image shown may differ from your TV . “Send To USB” must be done first before “Receive From USB” process, as it generate the file to be used in “Send To USB”. While writing is in process, the user must not turn TV off nor unplug the USB memo- ry card.
-
Page 13: Password Change
Image shown may differ from your TV . - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V2 . 2 3) Password Change LG Hotel Mode Setup Change Password TV Link-Loader Confirm Password Password Change... -
Page 14: Configuration Setup
Installation Menu Configuration setup Image shown may differ from your TV . Installation Menu (V2 . 2 3) Configuration Setup LG Hotel Mode Setup Select RCU Enable TV Link-Loader Number of RCU Password Change Splash Offset Time Set ID Setup... -
Page 15: Download Splash Image File To Tv Set
Download a splash image Download Splash Image file to TV set MENU INPUT Make a ‘LG_DTV’ folder in the USB flash drive and then copy splash image file to the folder . Image shown may differ from your TV . Connect the USB device to the USB IN jack on the TV . - Page 16 INPUT ENTER MENU You can see a new Splash Image on TV which TV Software Upgrade you downloaded while turning on TV . The Following update files are found in the USB device . Select the file you want to apply to update this TV Or press EXIT to cancel the update .
