Ask Technology HDMX0008M1 Operating Instructions Manual

8-by-8 hdmi matrix
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Ask Technology Co.,Ltd-Top leading in Audio & Video industry
Model No： HDMX0008M1

Operating Instructions

Thanks for purchasing our product.
Please be sure to read this instruction manual
carefully before using our product.
www.ask-corps.com Service Hotline：400-007-5518
0755-81753086 Fax：0755-81751802

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMX0008M1 and is the answer not in the manual?

Questions and answers

Related Manuals for Ask Technology HDMX0008M1

Summary of Contents for Ask Technology HDMX0008M1

  • Page 1: Operating Instructions

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry Model No： HDMX0008M1 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. www.ask-corps.com Service Hotline：400-007-5518 0755-81753086 Fax：0755-81751802...
  • Page 2 Introduction HDMX0008M1 is an 8-by-8 HDMI matrix. It allows any of the eight Input Channels (HDMI) to be routed to any of the eight Output Channels (HDMI), no matter the source is HDCP or not. Users can choose several different ways to control the matrix: by using infrared, RS232, and LAN and supplied remote control.

  • Page 3: Product Overview

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry HDMI Matrix (Routing Type) Product Overview ■ Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
  • Page 4  Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6.

  • Page 5: Package Contents

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry Package Contents ■ ① 1x Main unit. P/N_ HDMX0008M1. ② 1x Remote. ③ 1x IR RX (IR receiver cable). ④ 1x RS232 converter. ⑤ 12V/DC Power Supply. P/N_VDC01205. ⑥ Operating Instructions. P/N_INS HDMX0008M1.

  • Page 6: Connections And Operations

    HD-DVD/ PS3/STB etc.)Into HDMX0008M1. Connect HDMI OUT of HDMX0008M1 to display equipment. Connect the Broadband IR receive cable into HDMX0008M1 IR RX ports. Power on the input source you want to show. ( Keep the unused input power off, otherwise it may interfere the normal display).

  • Page 7: Control Via Ir Remote

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry Use the remote to control the matrix, or using Front Panel, RS232 and LAN port to control. 2. Control via IR remote. User can control the HDMI route of the matrix by using the IR remote.
  • Page 8 1) The Interface of HDMX0008M1 comctl...
  • Page 9 Ask Technology Co.,Ltd-Top leading in Audio & Video industry 2) The Message Window 2.1) Receive Window The “receive window” will show the message received from MX0808. When you click the Control Buttons ( see step 4) or send Control Command ( see 2.3) to MX0808, it will send out the...
  • Page 10 output. 2.3) Send Window Input the control command in this window. The control command use ASCII. 2.4) Setting Button Click this button to enter Setting menu. 2.5) IP SET Button Click this button to set IP address for LAN control (for example: 192.168.0.3). 2.7) EDID Set button...
  • Page 11 Ask Technology Co.,Ltd-Top leading in Audio & Video industry Select the Output Port in “Port Select” column, click “Read” button to get EDID from display equipment. Select the Input Port in “Port Select” column, click “Write” button to set EDID of this Input Port the same as display equipment.
  • Page 12 3.1) Connect state. Connect state shows the com open or not. 3.2) Com select.  Select which com you will use.  Connect button. The word on this button will change when the connection state changes. If the word is “Disconnect”, then click this button, the com will be closed.
  • Page 13 Ask Technology Co.,Ltd-Top leading in Audio & Video industry 63 69 72 20 32 xx 0D 0A cir_2x\r\n Output 3 select input 1~8 “x” : indicate the input port, range from 0~7. “y” : indicate the input port, range from 1~8.
  • Page 14 “x” : indicate the input port, range from 0~7. “y” : indicate the input port, range from 1~8. 62 63 20 0D 0A bc_\r\n Obtain the input status. “x” : indicate the input port, range from 1~8. 73 65 64 20 xx 20 yy 0D sed_x_y\r\n sed_x_y Copy edid from “x”...

  • Page 15: Lan Control

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry 4. LAN control  Note: Use the direct UTP cable to connect with PC, or use cross cable to connect to the Ethernet switcher A. Double click Netfinder.exe. Click “Search” button to get the device IP address.
  • Page 16 The right area is for device controlling. Click these buttons to control the device. It is the same as using the remote controller. The left area shows which input ports are being chosen by the output ports. C. Telnet Control Telnet matrix’s IP address Now you can control the matrix (Page 14: Control command format)

  • Page 17: Specifications

    Ask Technology Co.,Ltd-Top leading in Audio & Video industry Specifications ■ Operating Temperature Range 0 to +35°C (32 to +95°F) Operating Humidity Range 5 to 90 % RH (no condensation) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL)

  • Page 18: Provided Service

    Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;...
  • Page 19 Ask Technology Co.,Ltd-Top leading in Audio & Video industry below, (Parts (1) Year, Labor(90) Days)which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product.
