- Page 1 U S E R M A N U A L Matrix SPDIF 4x2 Model No: ADMX0402M1 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost- efficient.
- Page 3 The accessories with the machines lists： 1、5V Power Adaptor 2、Operation Manual 3、Remote-control unit Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture A:Power switch B:Standby and over-voltage indication. C:Switch button for A channel D:Switch button for B channel E:A channel output indication F:A channel input indication G:IR Remote receiver H:B channel output indication...
- Page 4 Figure 1.1 rear panel showing picture A: SPDIF input port 1~4 B: SPDIF output port A,B C: DC/5V Power Adaptor Interface Remote-control unit operating instructions PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
- Page 5 1,SPDIF output port A switch button, If the user wants to let the signal output from port A, only press the Number Keys under the Letter A. For example, source 2 output form A port, directly press the digital key 2 under Letter A. 2,Power swtich button 3, SPDIF output port B switch button.
- Page 6 SPECIFICATIONS: ADMX0402M1 Support audio format……………………DTS-HD/Dolby-trueHD/LPCM2.0/DTS/Dolby-AC3/DSD Peak wavelength………………................………650nm Max baud rate…..…………….…...………………………………………………………16Mbps Output cable distance ..……. …≤40m(Use the optical fiber cable loss less the 0.2Db/m ) Max working current………………………………………………………..……………...100mA Power adapter format………….Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/500mA Operating Temperature range……..…………….………………………………… (0 to +40℃) Operating Humidity range…………….………….….……….5 to 90%RH (No Condensation)
- Page 7 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
