- Page 1 GE Appliances Room Conditioners Owner’s Manual & Installation Instructions AVE15 AVE18 AVE22 Part. No. 23-11-2130N-001 Pub. No. 49-7375 CG 11-98...
-
Page 2: Table Of Contents
If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back section. Or, you can always call the GE Answer Center® at 800.626.2000, 24 hours a day, 7 days a week. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock or personal injury. SAFETY PRECAUTIONS Use this appliance only for its intended Turn the mode control to OFF and unplug purpose as described in this Owner’s your air conditioner before making any... -
Page 4: Controls
About the controls on the air conditioner. Features and appearance may vary. HEAT ONLY HIGH HIGH HEAT COOL COOL TEMP CONTROL MODE CONTROL Controls Mode Control Temp Control HIGH COOL and LOW COOL provide cooling The temp control is used to maintain the with different fan speeds. - Page 5 Additional controls and important information. Vent Control When set at CLOSE , only the air inside the room will be circulated and conditioned. When set at OPEN , Closed some inside air is exhausted outside. Open Air Direction Two levers on each side of the grille let you control the air direction left or right.
-
Page 6: Care And Cleaning
Window Installation Instructions Parts Included 2 support brackets 2 sill brackets Foam top window gasket 2 sliders Case 2 case Window side seals locking 2 filler panels bracket 5/8″ carriage bolts (2) 5/8″ machine screws (2) Upholstery 3/8″ screws (6) 1″... -
Page 7: Preparing To Install The Air Conditioner
Preparing to install the air conditioner. Read these instructions completely and carefully. Before You Begin NOTE TO INSTALLER: Leave these instructions with CAUTION: the air conditioner after installation is completed. Do not, under any circumstances, cut or remove the third (ground) prong from the NOTE TO CONSUMER: Keep this Owner’s Manual power cord. -
Page 8: Window Installation
Window Installation Instructions Parts Included 2 support brackets 2 sill brackets Foam top window gasket 2 sliders Case 2 case Window side seals locking 2 filler panels bracket 5/8″ carriage bolts (2) 5/8″ machine screws (2) Upholstery 3/8″ screws (6) 1″... - Page 9 Read completely, then follow step-by-step. Window Requirements These instructions are for a standard double- hung window. You will need to modify them for other types of windows. The air conditioner can be installed without the filler panels if needed to fit in a narrow window. ″...
- Page 10 Window Installation Instructions Remove the Air Conditioner from the Case Remove the air filter. Lift the top of the filter Remove one screw from each side of the case. and gently pull it up. Keep these ground/anti-theft screws so they may be replaced at the end of the installation.
- Page 11 Assemble and Attach the Sill and Support Brackets Loosely attach the sill brackets to the support Attach both sill brackets to the window sill brackets with 5/8″ long carriage bolts and nuts. using two 1″ long screws on each side. Tighten the bolts and nuts on both sides.
- Page 12 Window Installation Instructions Install the Window Filler Panels and Locking Bracket Insert the cut edge of the filler panel into the Use upholstery tacks to attach the filler panel case side seal groove. to the face of the window molding through the holes provided.
-
Page 13: Through-The-Wall Installation
Through-the-Wall Installation The case may be installed through-the-wall in both existing and new construction. Read completely, then follow step-by-step. IMPORTANT: Any side louvers must project on the outdoor side of the wall. ″ from the finished wall. The room side of the case must project into the room at least 1 The case must be installed level from side-to-side and with a 1/ 4″... -
Page 14: Troubleshooting Tips
Before you call for service… Troubleshooting Tips Save time and money! Review the chart below first and you may not need to call for service. Problem Possible Causes What To Do • Make sure the air conditioner plug is pushed Air conditioner The air conditioner completely into the outlet. -
Page 15: Air Conditioner Warranty
Any part of the air conditioner which fails due to a defect in materials or workmanship. One Year During this full one-year warranty, GE will also provide, free of charge, all labor From the date of the and in-home service to replace the defective part. -
Page 16: Service Telephone Numbers
Expert GE repair service is only a phone call away. Special Needs Service 800.626.2000 800-TDD-GEAC (800-833-4322) GE offers, free of charge, a brochure to assist in planning a barrier-free kitchen for persons with limited mobility. Service Contracts 800-626-2224 Purchase a GE service contract while your warranty is still in effect and you’ll receive a substantial discount.
