Page 1
CG100H-SKY S ERIES 2000 KYNET CONTROL PANEL ANUAL CG100H4-SKY CG100HTH-SKY CG100HHB-SKY 4 Button Mood Control Panel Thermostat Doorbell Switch ERSION 30 J , 2015 Disclaimers and Copyright Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring anyone against liability for infringement of letters patent.
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
1. Introduction Thank you for buying Citygrow’s product. CG100H-SKY Series is both powerful and easy to use and install. Description 1. Wall mount control panel for SkyNET2000 2. Data communicates through RS485 bus and running on Citygrow’s SmartBus protocols. 3. LED indicator for on/off status. 4.
2. Understanding of the product-CG100H4-SKY Button panel (front Button panel Control view) (bottom view) button Programming Dip Switch (for port address setting) Reset button Connector to Bracket Bracket Metal clip to fix Bracket (front view) the button panel (bottom view) Mounting Model number hole...
3. Understanding of the product-CG100HTH-SKY Button panel (front Button panel view) (bottom view) Control button Programming Dip Switch (for port address setting) Connector to Bracket Reset button Metal clip to fix Bracket Bracket the button panel (front view) (bottom view) Model number Mounting plate...
6. Wiring Before getting started WARNING! It must be installed by a qualified electrician in accordance with all applicable regulations and building codes. Improper wiring can result in personal injury or damage to control units or other equipment. Always turn off circuit breaker or remove main fuse from power line before doing any work. To avoid overheating and possible damage to equipment.
Wiring Diagram CG801SKN-M SkyNET 2000 Main Unit Daisy chain RS485 Wall mount control panels DC 12V Power AC 220V supply Distribution board Neutral Live Power supply Neutral (System) For CG100HHB-SKY only AC Live Door Dry contact Neutral Bell control...
7. Installation In order to install the product correctly, please follow the below steps: STEP 1: IMPORTANT! Turn off main power at the main switch board. STEP 2: Loosen the screws of the original wall switch. Remove the switch and the wiring.
Page 13
STEP 5: At the last panel of the RS485 bus (the last one of the daisy chain), add a termination resistor of 120ohm 1/4W across the RS485A and RS485B terminals to terminate the data transmission impedance. STEP 6: For the SkyNET 2000 main unit, connection of cable and power wires, please refer to the SkyNET 2000 User Manual.
1 seconds, during this 1 second duration, the bell will be driven on and doorbell will ring for 1 second. If CG100HHB-SKY is selected to be used for hotel project, see diagram above, the Do Not Disturb or Clean Room LED indicator cab be programmed to be switched on when the preselected button on a CG100H4-SKY panel is being pressed down.
8.3 CG100HTH-SKY, Thermostat COVER PLATE 1. Display window to show temperate 1. Display readings and settings. 2. Frame 2. Frame 3. Up / Down control fan speed High / Mid / Low 4. Up/ Down preset room temperature 5. On/off control of A/C 3.
9. Programming the SkyNET system Remove one of the button panel from the wall, then you will see the wall bracket is still fixed on the wall box. Then prepare a PC with SkyNET Planner Software installed and run it with the CG101UT5 and CG100UTC cable connected from PC to the CG101TP-SKY Tools Panel.
DND and Clean room the down button cannot LED indicator is be programmed as provided on scene function. CG100HHB-SKY. 2. Maximum number of devices programmed into the whole product is limited to 150 devices. Maximum current 200mA max.
Page 19
CG100H4-SKY CG100HTH CG100HHB Dimensions mm 85x85x28 85x85x28 85x85x28 (Length x Width x Depth ) Recommended 0 to 40 degC 0 to 40 degC 0 to 40 degC operation temperature RS485 A & RS485B to Panels should be connected in daisy chain configuration. Maximum 32 control SkyNET 2000 panels can be connected.
