CG100H S
ERIES
Z
IGBEE WIRELESS CONTROL PANEL
U
M
SER
ANUAL
CG100HTH /
CG100H4-MD
CG100H8-MD
CG100HHB
CG100HTHV1
4 Button Mood Control Panel
8 Button Mood Control Panel
Doorbell switch
Thermostat
V
02
ERSION
30,
, 2015
JAN
Disclaimers and Copyright
Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the
manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring
anyone against liability for infringement of letters patent.
Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however, Citygrow
Energy Systems Limited. makes no representation, warranty, or guarantee in connection with this publication and hereby
expressly disclaims any liability or responsibility for loss or damage resulting from its use or from the use of any product
or methodology described herein; for any violation of any federal, state, or municipal regulation with which this
publication may conflict; or for the infringement of any patent from the use of this publication. Nothing contained in this
publication should be viewed as an endorsement by Citygrow Energy Systems Limited of any particular manufacturer's
products.
Copyright © 2012 Citygrow Energy Systems Limited, All Rights Reserved
Advertisement
Table of Contents
Related Manuals for CityGrow CG100HTH
Summary of Contents for CityGrow CG100HTH
- Page 1 Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however, Citygrow Energy Systems Limited. makes no representation, warranty, or guarantee in connection with this publication and hereby expressly disclaims any liability or responsibility for loss or damage resulting from its use or from the use of any product or methodology described herein;...
-
Page 2: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
Table of Content 1. Introduction ......................1 Understanding of the product-CG100H ..............2 Understanding of the product-CG100H8-MD ............3 Understanding of the product-CG100HTH ............4 Understanding of the product-CG100HHB ............5 Dimensions ....................... 6 Wiring ......................7 Installation ....................... 8 Operation instruction .................. -
Page 4: Introduction
1. Introduction Thank you for buying Citygrow’s product. CG100H Series is both powerful and easy to use and install. It is specially designed for scene control function. User is able to program each of the button to control groups of lights, AV equipment, A/C, curtain, etc. -
Page 5: Understanding Of The Product-Cg100H
1. Understanding of the product-CG100H Frame Button panel Button pane (bottom view) l (front view) Control button Model number Programming port plate Connector to bracket Reset button Bracket Metal clip to fix Bracket (bottom view) the button panel (front view) Mounting Model number hole... -
Page 6: Understanding Of The Product-Cg100H8-Md
2. Understanding of the product-CG100H8-MD Frame Button panel (bottom view) Control Button panel (front button view) Model number Programming plate port Reset button Connector to Bracket Bracket Bracket Metal clip to fix (front view) (bottom view) the button panel Mounting hole Model number plate... -
Page 7: Understanding Of The Product-Cg100Hth
3. Understanding of the product- CG100HTH/CG100HTHV1 Frame Button panel (front Button panel view) Temperature (bottom view) display window Control button Model number plate Programming port Connector to Temperature Bracket Reset button sensor Bracket Bracket Metal clip to fix (front view) -
Page 8: Understanding Of The Product-Cg100Hhb
4. Understanding of the product-CG100HHB Frame Button panel (front Button panel view) (bottom view) Doorbell button Programming Model number port plate Connector to Bracket Reset button Bracket Bracket Metal clip to fix (front view) (bottom view) the button panel Mounting Model number hole plate... -
Page 9: Dimensions
5. Dimensions CG100H4-MD, CG100HTH, CG100HHB 85mm 28mm CG100H8-MD 156mm 28mm... -
Page 10: Wiring
! This product is designed for residential and commercial use, for indoor use only. WARNING! Install in accordance with all national and local electrical codes. IMPORTANT! Citygrow® is not liable for any damage incurred with the misuse of this product. -
Page 11: Installation
STEP 3: Connect the main power cable to the Live and Neutral terminals of the CG101AD Mini Power Supply, and then connect the DC output wires of the CG101AD to the DC input of CG100H Series. Case 1: For CG100H, CG100HTH... - Page 12 Case 2: For CG100HHB - connect the doorbell according to the following … > Dry connect output to bell >max. 1A, 24Vdc/ac 6V - DC 6V input from CG101AD 6V +...
- Page 13 Case 3: For CG100H8-MD STEP 4: Fasten the screws of all terminals and check that the wires are properly secured. Retrofit the bracket of CG100H series into the standard switch box and mount it on the wall by fastening the two screws in the wall box.
- Page 14 STEP 5: Power up the main switch board, the LED indicators on CG100H series will be lighted up. Since the CG100H is not programmed and setup by HomeNET planner software at this moment, the product buttons will not function at this stage. Notes: Use standard UK wall box BS4662;...
-
Page 15: Operation Instruction
8. Operation instruction 8.1 CG100H4-MD, 4 Button Mood Control Panel COVER PLATE 1. 1, 2, 4, 4, 5, 6, 7, 8 are buttons location. 2. Frame 1. Button 2. Frame MAIN UNIT 3. 4 pcs Locks to fix the main unit onto 3. -
Page 16: Cg100H8-Md, 8 Button Mood Control Panel
8.2 CG100H8-MD, 8 Button Mood Control panel COVER PLATE 1. 1, 2, 4, 4, 5, 6, 7, 8….. 13, 14, 15, 16 are buttons location. 2. Frame 1. Button 2. Frame MAIN UNIT 3. Reset button 4. Program port 5. 8 pcs Locks to fix the main unit onto the wall bracket. -
Page 17: Cg100Hhb, Doorbell Switch
8.3 CG100HHB, Doorbell switch COVER PLATE 1. Doorbell button. 2. Frame. 3. Clean Room Indicator ( For Hotel 1. Button Only) 4. Do Not Disturb ( For Hotel Only) 2. Frame 4. Do Not 3. Clean Room Disturb MAIN UNIT 5. -
Page 18: Cg100Hth, Thermostat
8.4 CG100HTH / CG100HTHV1, Thermostat COVER PLATE 1. Display window to show temperate 1. Display readings and settings. 2. Frame 2. Frame 3. Up / Down control fan speed High / Mid / Low 4. Up/ Down preset room temperature 5. -
Page 19: Adding The Product To Your Home Wireless Zigbee Network
CG101UTC cable. STEP 3 Plug the CG101UTC cable into the USB port of a PC that is installed with Citygrow’s HomeNET Planner Software. STEP 4 Refer to the user manual of “HomeNET Planner” Software to program and set the address of the product. -
Page 20: Clear Memory
10. Clear Memory Clearing the memory inside of the product will result in: 1. The product will no longer reply to any Panels that it had previously bound to. 2. The product will no longer reply to any Remotes that it had previously bound to. In order to perform the Clear Memory function, please follow the below steps: STEP 1 Press and HOLD anyone of the button, say button “A”. -
Page 21: Specification
11. Specification... - Page 22 8. Support two way 6. Memory dim 6. Memory dim function, ie multiple function. function. CG100HTH control of single CG401S5-FCU 7. Two way control 7. Two way control Fan Coil Control Switch function. function. Module. 8. LED backlight.
- Page 23 Power supply DC6V DC6V DC6V DC6V Powered by Powered by Powered by CG101AD DC Powered by CG101AD CG101AD DC 6V Mini CG101AD DC 6V Mini 6V Mini Power Supply DC 6V Mini Power Power Supply Power Supply Supply RF frequency 2.4GHZ 2.4GHZ 2.4GHZ...
