Installation and Operation Instructions
for USA only.
Tested to UL 1482-2010
375-S-01-2 and 375-S-02-2
Models – HF-517U and HF-717U
Safety Notice: If this solid fuel room heater is not properly installed, a house fire may result. For
your safety and to reduce the risk of fire, follow the installation directions. Contact local building,
fire officials or the authority having jurisdiction about restrictions and installation inspection
requirements in your area, including the need to obtain a permit. Kindly save these instructions
for future reference.
VERY IMPORTANT
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM
HEATER. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR EVEN DEATH. FAILURE TO READ AND FOLLOW THESE INSTRUCTIONS BEFORE
YOU PROCEED MAY RESULT IN DAMAGE, VOIDING YOUR WARRANTY!
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING, AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
Please contact the
dealer in your area if you
have any questions about your stove that are not covered
1
Advertisement
Table of Contents
Related Manuals for Hi-Flame HF-517U
Summary of Contents for Hi-Flame HF-517U
-
Page 1: Very Important
Tested to UL 1482-2010 375-S-01-2 and 375-S-02-2 Models – HF-517U and HF-717U Safety Notice: If this solid fuel room heater is not properly installed, a house fire may result. For your safety and to reduce the risk of fire, follow the installation directions. Contact local building, fire officials or the authority having jurisdiction about restrictions and installation inspection requirements in your area, including the need to obtain a permit. -
Page 2: Table Of Contents
This instruction manual has been developed to ensure optimum performance from the Henan Hi-Flame® stove and fireplace range. It's very important that you thoroughly read and understand all instructions before using your new stove or fireplace. -
Page 3: Stove Safety
Warranty Policy & Procedures ..................20 Stove Safety When properly maintained and operated your stove should give you many years of service. However there are important safety aspects of these products that you need to be aware of when operating a wood stove. 1. -
Page 4: Before Installing Your Stove
We hope you have many years of warmth and comfort from your stove but please do so safely. Check Building Codes When installing, operating and maintaining your stove, follow the guidelines presented in these instructions, and make them available to anyone using or servicing the stove. Your city, town, county or province may require a building permit to install a solid-fuel burning appliance. -
Page 5: Installation
Installation Unpacking and preparing your stove for installation. Remove your stove from the outer packaging and place on floor. Please inspect stove and check that it is not damaged in any way. Never attempt to use a stove that has been damaged. -
Page 6: The Floor Protection
The floor protection If the stove is to be installed on a combustible floor, it must be placed on a non-combustible hearth pad. In the USA, the floor protector must extend 8” beyond each side of the fuel loading door and 16” to the front. (See fig. 4) 8”... -
Page 7: Installation Clearances
These surfaces are not limited to those that are visible and also include materials that are behind non-combustible materials. If you are not sure of the combustible nature of a material, consult your local fire officials. Parallel Installation Corner Installation HF-517U HF-717U Single wall Single wall connector pipe connector pipe A –... -
Page 8: Well Sealed Flue System
Well sealed flue system Only materials and items approved for solid fuel stoves should be used for your stove. Under no circumstances should you use aluminum or galvanized steel pipes for your stove flue. Always fit pipes with the narrow side down, this allow any creosote to run down the inside of the pipe and not to come out and cause an unsightly mess and possible fire hazard. -
Page 9: Chimney
This prevents any amount of condensed or liquid creosote from running down the outside of the pipe or the stovetop. All joints, including the flue collar connection must be secured with three sheet metal screws to ensure that the sections do not separate. For the best performance the chimney connector should be as short and direct as possible, with no more than two 90 elbows. -
Page 10: Factory Built Chimney
Factory-Built Chimney When a metal prefabricated chimney is used, the manufacturer‟s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. -
Page 11: Masonry Chimney
Masonry Chimney Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. -
Page 12: Combustible Wall Chimney Connector Pass-Throughs
Combustible Wall Chimney Connector Pass-Throughs Method A. 12” Clearance to Combustible Wall Member: Using a minimum thickness 3.5” brick and a 5/8” minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 13: Operating Your Stove
Operating Your Stove Do not use a grate, andiron or other fuel support method. Build fire directly on the hearth. Only open door to fuel/refuel the stove. Excess air can cause the stove to over fire. Do not over fire, if chimney or stove is glowing red you are over firing. Do not build the fire too close to the glass. -
Page 14: Refueling
Refueling Before refueling your stove, turn the air supply to high for a few moments until there is a good fire in the stove. This will ensure there is no build-up of harmful gases in the stove when the door is opened and will also get the new fuel burning quickly and not allow it to kill the fire. -
Page 15: Stove Maintenance
you need to try with it a little more open. After a couple of nights, you will find the setting that best suits the local conditions of your stove. When you return to your stove, fully open both air controls until you have a good fire and then set to normal operating levels. -
Page 16: Replacement Of Glass
opening, as this may break the glass when you close the door. This is especially relevant when loading logs. Always close the door gently. Do not operate with broken or cracked glass. If the glass does crack when the stove is lit, let the fire die out. - Page 17 42. ½” Fiberglass Gasket [not shown] a. Door Frame b. Window Chanel...
- Page 18 49. ½” Fiberglass Gasket [not shown] a. Door Frame b. Window Chanel...
-
Page 19: Trouble Shooting
Trouble Shooting Fire not burning A stove not burning is generally caused by either a shortage of air and/or incorrect or damp fuel. If fuel is not the problem check: That the air controls are opened. There is no blockage in the flue system. ... -
Page 20: Specifications
Henan Hi-Flame will repair or replace (parts and labor) at its option, any stove or fireplace insert or part thereof found to be defective. - Page 21 7. Travel time or any other expenses are not covered under warranty. 8. At no time will Henan Hi-Flame be liable for any consequential damage which exceeds the purchase price of the unit. All warranties, implied warranties of merchantability or other, are limited in duration to the length of this written warranty.
