Audio-video player for USB-Media
Product features
• Playback of audio and video files from USB-media up to 2TB
• NTFS and FAT32 multi partition capable
• Compatible with MP3, AVI, VOB, MOV, RMVB, JPG and many more
• Last position memory
• Stand-alone
• Controllable by IR-sensor and remote control
• Visualisation via ON-screen display
• Controllable and combinable by dvbLOGiC or c.LOGiC
Version 18.04.2011
usbLiNK AV-player
USB-LINK
Universal
USB-LINK
Advertisement
Table of Contents
Related Manuals for Caraudio-Systems usbLiNK AV-player
Summary of Contents for Caraudio-Systems usbLiNK AV-player
- Page 1 AV-player USB-LINK Universal Audio-video player for USB-Media Product features • Playback of audio and video files from USB-media up to 2TB • NTFS and FAT32 multi partition capable • Compatible with MP3, AVI, VOB, MOV, RMVB, JPG and many more •...
-
Page 2: Table Of Contents
Contents 1. Prior to installation 1.1. Delivery contents 2. Installation 3. Operation 3.1. Remote control 3.2. In combination with xLOGiC interfaces 3.3. “Home“ menu 3.4. “Settings“ menu 3.5. “Select Media” menu 4. Specifications 5. Technical support Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. -
Page 3: Prior To Installation
1. Prior to installation Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation must be free of moisture and away from heat sources. 1.1. Delivery contents Take down the SW-version and HW-version of the interface boxes, and store this manual for support purposes. -
Page 4: Operation
3. Operation 3.1. Remote control Remote control operations Button Function POWER Select power-on or stand-by SOURCE Select Photo, Music, Movie, Text and File MUTE Mute control Select play or pause ■ Stop EXIT Exit the current setup AUDIO No function ▲... -
Page 5: Home" Menu
3.3. “Home“ menu In the “Home” menu, you can highlight the items “USB” (if an data medium is connected) and “Settings”. You can use [ ] and [ ] buttons to highlight the item and press [OK] to set the setting. ... -
Page 6: Select Media" Menu
Music repeat mode Selection of the music repeat mode. Choose between Repeat all or Repeat one. Movie repeat mode Selection of the movie repeat mode. Choose between Repeat all or Repeat one. Display mode Selection of the display mode. Choose between 16:9 and 4:3. ... - Page 7 Photo 1. In menu mode, select “Photo“. 2. Press [OK] button to show all of the stored photos. 3. Press [ ], [ ], [▲] and [▼] buttons to select a photo and press the [OK] button to show the photo.
- Page 8 Movie 1. In menu mode, select “Movie“. 2. Press [OK] button to show all of the stored movie files. 3. Press [▲] and [▼] buttons to select a movie file and press the [OK] button to start the movie file. 4.
-
Page 9: Specifications
Temperature range -30°C bis +80°C Weight 112g Measurements (box only) B x H x T 93 x 29 x 55 mm 5. Technical support Caraudio-Systems Vertriebs GmbH NavLinkz GmbH manufacturer/distribution corporate sales/tech dealer-support Rheinhorststr. 22 Eurotec-Ring 45 D-67071 Ludwigshafen am Rhein...
