Caraudio-Systems USB-LINK3 AV-player Manual

Universal stand-alone audio-video player for usb-media
Hide thumbs

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
usbLiNK3 AV-player
USB-LINK3
Universal stand-alone
Audio-video player for USB-Media
Product features
• Playback of audio and video files from USB-media up to 2TB
• NTFS and FAT32 multi partition capable
• Support of all common Audio & Video formats (e.g.MP3, AVI, VOB, MOV, RMVB, JPG,
FLV, MKV, H.264)
• Last position memory
• Controllable by IR-sensor and remote control
• Visualisation via ON-screen display
• Controllable and combinable by c.LOGiC, dvbLOGiC and V4
• Search in Audio + Video files during playback possible
• Scroll page by page possible in Audio + Video files
Version 22.06.2016
USB-LINK3

Advertisement

loading
Need help?

Need help?

Do you have a question about the USB-LINK3 AV-player and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Caraudio-Systems USB-LINK3 AV-player

Summary of Contents for Caraudio-Systems USB-LINK3 AV-player

  • Page 1 All manuals and user guides at all-guides.com usbLiNK3 AV-player USB-LINK3 Universal stand-alone Audio-video player for USB-Media Product features • Playback of audio and video files from USB-media up to 2TB • NTFS and FAT32 multi partition capable • Support of all common Audio & Video formats (e.g.MP3, AVI, VOB, MOV, RMVB, JPG, FLV, MKV, H.264) •...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Contents 1. Prior to installation 1.1. Delivery contents 2. Installation 3. LEDs 4. Operation 4.1. Remote control operations 4.2. usbLiNK3 in combination with xLOGiC interfaces 4.3. “System Setting“ menu 4.4. “Movie“ menu 4.5. “Music”...

  • Page 3: Prior To Installation

    All manuals and user guides at all-guides.com 1. Prior to installation Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation must be free of moisture and away from heat sources. 1.1. Delivery contents Take down the SW-version and HW-version of the interface boxes, and store this manual for support purposes.

  • Page 4: Operation

    All manuals and user guides at all-guides.com 4. Operation Before attempting to operate your remote control, install the batteries as described below: 1. Turn the remote control face down. 2. Press down on the ridged area of the battery cover and slide it off.

  • Page 5: Usblink3 In Combination With Xlogic Interfaces

    All manuals and user guides at all-guides.com 4.2. usbLiNK3 in combination with xLOGiC interfaces If the usbLiNK3 is connected to an xLOGiC input at an xLOGiC interface, the usbLiNK3 is automatically powered off/on when (de-)selected. The last playback position is saved. Exceptions: C1-MFD1, C1-MFD2, C1/C2-LR, C1/C2-LR10, C4-LR12-NB Manual use of the usbLiNK3’s remote control power button is not recommended other than for rear-seat-entertainment.
  • Page 6 All manuals and user guides at all-guides.com Monitor Port Setting No function. Version/Upgrade Display the hardware and software version and the possibility to update the usbLiNK3 by USB. Reset default Reset of the factory settings. Version 22.06.2016 USB-LINK3...

  • Page 7: Movie" Menu

    All manuals and user guides at all-guides.com 4.4. “Movie” menu 1. In menu mode, select “Movie“. 2. Press the [OK] button to show all the stored movie files. 3. Press the [▲] and [▼] buttons to select a movie file and press the [OK] button to start the movie file.

  • Page 8: Music" Menu

    All manuals and user guides at all-guides.com 4.5. “Music” menu 1. In menu mode, select “Music“. 2. Press the [OK] button to show all the stored music files. 3. Press the [▲] and [▼] buttons to select a music file and press the [OK] button to start the music file.

  • Page 9: Photo" Menu

    All manuals and user guides at all-guides.com 4.6. “Photo” menu 1. In menu mode, select “Photo“. 2. Press the [OK] button to show all the stored photos. 3. Press the [▲] and [▼] buttons to select a photo and press the [OK] button to display it.

  • Page 10: Specifications

    All manuals and user guides at all-guides.com 5. Specifications Operation voltage 10.5 – 14.8V Stand-by power drain <1mA Operation power drain <1000mA Power consumption <13W Temperature range -30°C to +80°C Weight 290g Measurements (box only) 49 x 25 x 140 mm W x H x D Version 22.06.2016 USB-LINK3...

  • Page 11: Frequently Asked Questions

    All manuals and user guides at all-guides.com 6. Frequently asked questions For any troubles which may occur, check the following table for a solution before requesting support from your vendor. Symptome Reason Possible solution Check the Power cable and the usbLiNK3 don´t switch on, no connection on the usbLiNK3.

  • Page 12: Technical Support

    All manuals and user guides at all-guides.com 7. Technical support Please note that direct technical support is only available for products purchased directly from NavLinkz GmbH. For products bought from other sources, contact your vendor for technical support. NavLinkz GmbH distribution/tech dealer-support Eurotec-Ring 39 D-47445 Moers...
