Summary of Contents for Kontron PD14

  • Page 1: Power Supply

    CPCI Power Supply Manual PRODUCT DOCUMENTATION PD14 CP3-SVE-P200DC-24V Reference ID:24139 PD14, Rev. 02 June 28, 2013...
  • Page 2: Revision History

    Kontron and the Kontron logo and all other trademarks or registered trademarks are the property of their respec- tive owners and are recognized. Specifications are subject to change without notice.
  • Page 3: Cpci Power Supply

    = + 12 V at 3 A = - 12 V at 0.5 A Cooling 250 LFM forced-air cooling (ca. 1.3 m/s) Redundant Supply Capability Always LED’s for input good and power fail Status Indication Special Feature(s) None RID 24139 PD14, Rev.02 Page 3...
  • Page 4: Mechanical Specifications

    PD14: CP3-SVE-P200DC-24V CPCI Power Supply Mechanical Specifications Figure 1: View of Power Supply Unit CP3-SVE-P200DC Page 4 RID 24139 PD14, Rev.02...
  • Page 5 CPCI Power Supply PD14: CP3-SVE-P200DC-24V Figure 2: Power Supply Dimensions 6.671" (169.4mm) 6.399" (162.5mm) 0.1" (2.54mm) 3U x 8HP POWER ALARM 1.6" (40.6mm) RID 24139 PD14, Rev.02 Page 5...
  • Page 6: Power Supply Connector

    For the pinouts of the Positronic P-47 power supply connector please refer to the following table. 42 43 44 39 40 41 36 37 38 33 34 35 30 31 32 27 28 29 24 25 26 21 22 23 Page 6 RID 24139 PD14, Rev.02...
  • Page 7: Installation

    Failure to comply with this may result in an Output Failure indication on the power supply. This is due to an internal protection feature of the power supply which requires time to cool down before the power supply is put back into operation. RID 24139 PD14, Rev.02 Page 7...
  • Page 8: Electrical Specifications

    OUTPUT ADJUSTMENT OUTPUT LINE LOAD RIPPLE & NOISE VOLTAGE RANGE CURRENT REGULATION REGULATION pk-pk 0.5% < 60 mV +3.3V 0.5% < 60 mV +12V 0.5% < 120 mV -12V 0.5A 0.5% < 120 mV Page 8 RID 24139 PD14, Rev.02...
  • Page 9: Protection And Control

    Class Interference Radiated: ESD Susceptibility Per EN61000-4-2, level 4. Radiated Per EN61000-4-3, level 3. Susceptibility EFT/Burst Per EN61000-4-4, level 3. ± 2 Input Surge Per EN61000-4-5, level 3. Line to Line Line to Ground RID 24139 PD14, Rev.02 Page 9...
  • Page 10 Adequate thermal cooling of the power supply must be ensured. Therefore do not obstruct or hinder cooling air circulation or heat con- duction within the power supply or surrounding equipment. Failure to comply with this warning may result in damage to your equipment. Page 10 RID 24139 PD14, Rev.02...
