ORBRY OBUHTOUCH Easy Setup Manual

ORBRY TOUCH THERMOSTAT
EASY SET UP GUIDE:
OBUHTOUCH
Don't forget to activate your
warranty within 60 days of purchase.
Visit orbry.com/warranty.
1. SET TIME & DATE
1. Tap the 'power' button to switch unit on.
2. The backlight will fade after around 10 seconds.
3. Tap the "Clock" button to switch it back on at any point.
4. Press and hold the "Clock" button for around 7 seconds or until the
minutes begin to flash.
5. Use the "Up" and "Down" arrows to select correct minute.
6. Tap the "Clock" button to switch to hour and use "Up" and "Down"
to select the correct hour.
7. Tap the "Clock" button again to edit the day.
8. Use the "Up" and "Down" arrows to select the correct day number:
1 = Mon, 7 = Sun.
9. Tap the "Clock" button to save time and date settings.
2. ADVANCED SETTINGS
1. To access advanced setting switch the unit off by tapping
the "Power" button.
2. Then press and hold both the "Power" and "Menu" button.
3. Tap the "Menu" button to switch to Sensor mode (2SEN)
and set to OUT.
4. Tap "Menu" x3 to switch to Frost Protection Mode (SLrP).
5. Set this to "On" using the "Up/Down" arrows.
6. Tap the "Menu" button to set your program days.
7. Tap "Up/Down" to set the program days.
8. Program options include:
6 days same & 1 separate day
7 days same
5 days & weekend (recommended)
Program off
9. Tap the "Menu" button and switch off to save your settings.
web: www.orbry.com tel: 0845 208 0221
ICON KEY:
Up
Down
Power
Manual control mode
Program mode indicator
Menu button
Period 1
3. MANUAL MODE
1. You can switch between Manual and Schedule by tapping
"Menu".
2. When in Manual mode, set a target temperature manually
using the "Up/Down" arrows.
3. When the target temperature is set above the ambient temp,
you will see the HEAT symbol (flame) below the target temp.
Period 2
Period 3
Period 4
Period 5
Period 6
Heating on
Clock button
