- Page 1 FW-5470 User’s Manual Part 1 FW5470 User’s Manual Part 1 (Product Overview) Version 3.0 Seyeon Technology Co., Ltd www.flexwatch.com １ 4034 Seyeon Tech Co., Ltd...
-
Page 2: Table Of Contents
FW-5470 HW installation and basic settings ................9 3.1. Before installation, ........................9 3.2. Factory Default Condition .....................9 3.3. FW-5470 Hardware installation ....................9 3.4. FW-5470 Rack Mount-kit installation .................10 3.4.1. Packing List of Rack Mount-kit ...................10 3.4.2. Installation procedure ....................11 ２ 4034 Seyeon Tech Co., Ltd... - Page 3 • The materials in this document are for information use only and are subject to change without notice. While reasonable efforts have been made in the preparation of this document, to assure its accuracy, Seyeon Tech. assumes no liability resulting from errors or omissions in this document; or from the use of the information contained herein.
-
Page 4: Product Overview
Encryption function by user authentication Image transmission function via FTP, Email Supports up to 2TB HDD, Anti-Vibration Supports Various PTZ (Pan/Tilt/Zoom) Devices Supports Sensor Input, Digital Output Supports Dynamic IP users by IPCCTVDNS server 4034 Seyeon Tech Co., Ltd... -
Page 5: Technical Specification Of Fw-5470
FTP, alarm Buffer by event or schedule Advanced Service IP notification, Alarm Notification to e-mail, CGI Call by event or schedule Accuracy: 12x12=144 blocks Built-in Motion detections Motion Sensitivity : -100 ~ 100 : 100 is hypersensitive 4034 Seyeon Tech Co., Ltd... - Page 6 CE : Class A Size :280 mm(L) x 217mm(W)X 44mm(H) Dimensions (HxWxD) and 11 ” (L) x 8.5 ” (W)X 1.73 ” (H) weight Weight : 1560 g (3.43lbs) without power supply. Table 1 : FW-5470 Specification 4034 Seyeon Tech Co., Ltd...
-
Page 7: Packing List
(Power Cable & SMPS DC12V 5A Adapter) CD (User’s Manual, installation wizard and Pictures) Table2 : FW-5470 Packing List Please check all the listed items are included in your package. For any missing items, please contact your local distributor. 4034 Seyeon Tech Co., Ltd... -
Page 8: Hardware Description
- Keep pressing FD button for 5~10 seconds until hearing three times short beep sound. ACT LED blinks during the process. The system will reboot automatically when it’s completed. HDD ventilation halls. HDD ventilation halls Always ensure to Keep open and clean around this area. 4034 Seyeon Tech Co., Ltd... -
Page 9: Fw-5470 Rear Panel View
Video Quad Out Video outport port for Quad View HDD Cooling FAN Always ensure to Keep open and clean around this Cooling FAN area. Table 5 : FW-5470 Rear Panel Description 4034 Seyeon Tech Co., Ltd... -
Page 10: Com Port Description
FW-5470 User’s Manual Part 1 2.2.1. COM Port Description Pin-out information of COM port. It’s RS-232 ports for Serial input device, Modem or Console (Hyperterminal.connection) Picture 5 : COM port Pin-out 4034 Seyeon Tech Co., Ltd... -
Page 11: Fw-5470 Hw Installation And Basic Settings
First, Network Configuration by FW-installer. Second, Camera Configuration by FW-installer or admin-menu. Third, Service Configuration by FW-installer or admin-menu. For IP setup, refer to “Chapter 2.Network Configuration” on User’s Manual Part2. 4034 Seyeon Tech Co., Ltd... -
Page 12: Fw-5470 Rack Mount-Kit Installation
Rack Mount-kit is sold separated, so it is not basically included in the product package. Following steps shows how to install it with FW-5470. 3.4.1. Packing List of Rack Mount-kit A. Right wing guide…………………………….. B. Power rack guide……………………………. C. Junction Joint (Long)……………………….. D. Junction Joint (Short)……………………….. E. Screw Bolts…………………………………… 4034 Seyeon Tech Co., Ltd... -
Page 13: Installation Procedure
C. Arrange Right Rack Guide D. Insert junction Part and fix by screw bolt E. Arrange Power Rack Guide F. Insert junction Part and fix by screw bolt G. Plug Power cable to Power connector and finish installation 4034 Seyeon Tech Co., Ltd...
