Punttoo GPS Tracking Device
User Operation Manual
Ver. 1.05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Punttoo and is the answer not in the manual?

Questions and answers

Related Manuals for Soniya Punttoo

Summary of Contents for Soniya Punttoo

  • Page 1 Punttoo GPS Tracking Device User Operation Manual Ver. 1.05...
  • Page 2 Punttoo User Manual KEY, PORT, AND INDICATORS Power switch with indicator STATUS slowly blinking – Waiting for cellular connection. fast blinking – Calculating satellites (seeking). blinking with flashing BLUE/GREEN background–GPS satellites acquired (captured). Battery charging jack with protective cover CAUTION Always cover this port during deployment for safety and protection.
  • Page 3 Punttoo User Manual Magnet for mounting on metal surface CAUTION: this magnet is made from Rare Earth Element and may show extreme strength during operation. Personal and property safety is strongly advised. Tips Clean and flat metal surface provides much more pull-force than rusted, dust covered, or uneven shaped.
  • Page 4 Punttoo User Manual Important Steps before Deployment 1. GETTING CELLULAR NETWORK REGISTERED FIRST Power on the device by single press on the power button. Make sure the red power indicator slow blinking (half second on, half second off). The slowly blinking red will turn to fast blinking (¼ second on, ¼ second off), meaning cellular is registered and in normal transmission status.

  • Page 5: Battery Type

    Punttoo User Manual What’s the reasonable time battery can last?  Your device built with motion sensor and power is automatically controlled by motion sensor - that means device automatically powers up when motion is detected, and goes to sleep when motion no longer lasts.
  • Page 6 Punttoo User Manual PRODUCT WARRANTY 1. This product carries One-Year (1 year) limited manufacturer Warranty, except battery. 2. Warranty voids if opened or modified by user, operated under extreme conditions, or charged with non-designated chargers. 3. Warranty does not apply to operation area not covered by wireless carrier. Merchandise with operation worn or physical damage, defectives by improper operation are not eligible for warranty.

  • Page 7: Specification

    Said variables must be taken into consideration when installing or using the product, and Soniya shall not be responsible for installations or transmissions that fall outside of the parameters set forth in this publication.
  • Page 8 Punttoo User Manual SONIYA UNITED TRACKING SERVICE OPERATION GUIDE Ver. 4.0 Technical Support: support@soniyatech.com Page 8...

  • Page 9: User Login

    Punttoo User Manual USER LOGIN Browser Compatibility - computer based:  [Recommended] Mozilla Firefox or Google Chrome  [Supported] Microsoft IE 6.0 or above, Apple Safari (PC and iOS).  [Not Recommended] Aol, Opera, and other non-mainstream broswers. Note: When viewed by incompatible browsers, map and some function may not display properly.
  • Page 10 Punttoo User Manual SUMMUARY PAGE This page provides a summary of a day recorded. Date can be selected from by calendar. Select a device to Click “Hide Panel” slide switch the display of related information off panel and make bigger map screen...
  • Page 11 Punttoo User Manual The following two screens when control panel is slide off and on: Click to slide in control Controls of panel for device viewing information details direction Controls of viewing mode: Zoom control to road, bird’s eye, automatic.
  • Page 12 Punttoo User Manual LIVE PAGE A colored arrow indicates target moving with direction at the moment. Screen refreshes automatically based on device interval setting. Different devices are shown in different colors. This section displays details of most recent reading received from...
  • Page 13 Punttoo User Manual Click on this button to open set interval window (as shown from left of this screen) Select new interval to send over to device. Depends on device models, the range of interval may vary. Shorter interval tracks more often, but may consumes more power and shorten battery life.

  • Page 14: History Page

    Punttoo User Manual HISTORY PAGE This page contains comprehensive history information to manage your report or diagnose problem. DEVICE RECEPTION HISTORY Three types of history record available in this page: Device Reception History: Record of all incoming signals received from device, whether locations is successfully detected (captured) or failed to detect (seeking).
  • Page 15 Punttoo User Manual CAPTURED LOCATION HISTORY Select device and date/time period to query history records. Maximum 7 days per query. If query period is more than 7 days, split into different phases less than 7 days. Captured Location History ...
  • Page 16 Punttoo User Manual More options:  Daily Report  Print  Download  Playback Playback Console Click on spot to view specific information being playing now already played not played yet Page...
  • Page 17 Punttoo User Manual Print Console GEOFENCE TEXT SENT LOG GeoFence Text Set Log Text messages/emails triggered by occurrence of GeoFence events. Once logged here, it means those messages have been delivered to your notification phone (as text message) and/or email address already at the time indicated here.

  • Page 18: Device Page

    Punttoo User Manual DEVICE PAGE This page shows devices status of airtime service. INACTIVE: airtime expired. ACTIVE: airtime in service OFFLINE: airtime service expired long time ago View/Pay : click here to view service status or purchase new airtime. Depends on the dealer/agency user goes through.

  • Page 19: Alert Menu

    Punttoo User Manual ALERT MENU This is the page where Geo-Fence and other alert notifications are management. Notification is text messages to mobile phone (SMS), or email, or both at the same time. Types of notification are explained below:  Arriving Location – Approaching a range of user defined area or user provided postal address.
  • Page 20 Punttoo User Manual STEP 1: Set up Text-To-Phone first Add a new phone Delete existing phone Click on Alert-Text-To-Phone first Edit existing phone Page...
  • Page 21 Punttoo User Manual STEP 2: Add/Edit texting notifications GeoFence is user defined area. When unit is detected entering or leaving this range, a notification alert will be generated and delivered to Notification Phone as text message.  Arriving Location - Entering a defined area centered by a user defined address (so called GeoFence).

  • Page 22: User Account Page

    Punttoo User Manual USER ACCOUNT PAGE This page is for user to:  Check Airtime Service Status, and purchase new airtime.  Update profile, e.g. email to receive service notice and recover lost password. User can also adjust time zone. (All date time in history are in location time zone as set at the time.)
