Punttoo/PunttooMini/PunttooPlus
GPS Mobile Tracking Device
User Operation Manual
Ver. 1.12
WARNING
THESE PRODUCTS CONTAIN LITHIUM BATTERY. HIGHLY HAZARDOUS IF OPENED, DAMAGED, SHOCKED,
OVERHEATED, DISPOSED OF IN FIRE OR WATER, OR CHARGING BATTERY WITH INCORRECT CHARGER.
WARRANTY VOID IF OPENED OR MODIFIED BY UNAUTHORIZED PERSONNEL. WARRANY DOES NOT
APPLY IF DAMAGED, SHOCKED, OVERHEATED, DISPOSED OF IN FIRE OR WATER, IMPROPERLY
CHARGED, OPERATED, HANDLED, STORED, OR TRANSPOSRTED. ALWAYS USE DESIGNATED CHARGER
AND LEAVE CHARGING ATTENDED. ALWAYS KEEP OUT OF REACH OF CHILCHREN.
Advertisement
Table of Contents
Related Manuals for Soniya Punttoo
Summary of Contents for Soniya Punttoo
- Page 1 Punttoo/PunttooMini/PunttooPlus GPS Mobile Tracking Device User Operation Manual Ver. 1.12 WARNING THESE PRODUCTS CONTAIN LITHIUM BATTERY. HIGHLY HAZARDOUS IF OPENED, DAMAGED, SHOCKED, OVERHEATED, DISPOSED OF IN FIRE OR WATER, OR CHARGING BATTERY WITH INCORRECT CHARGER. WARRANTY VOID IF OPENED OR MODIFIED BY UNAUTHORIZED PERSONNEL. WARRANY DOES NOT APPLY IF DAMAGED, SHOCKED, OVERHEATED, DISPOSED OF IN FIRE OR WATER, IMPROPERLY CHARGED, OPERATED, HANDLED, STORED, OR TRANSPOSRTED.
-
Page 2: Led Indicator Status
Punttoo User Manual Punttoo/PunttooPlus - POWER KEY, LED INDICATOR, CHARGING PORT Power Key with embedded LED indicator Power Key Operation Short Single Press – turn on power Hold for 3 seconds – turn off power LED indicator status RED slow blinking –... - Page 3 Punttoo User Manual Punttoo Mini - POWER KEY, LED INDICATOR, CHARGING PORT Power Key Power Key Operation Short Single Press – turn on power Hold for 3 seconds – turn off power LED indicator status RED slow blinking – in process to register with cellular network.
- Page 4 Punttoo User Manual Punttoo Mini – Magnet Mount Assembly and Removal Removable Magnets Use a tool or by hand: Assemble – fasten clockwise Remove – release counter-clockwise Rubber Magnet Boots The rubber magnet boots are to reduce magnet pull- force during transportation. They should be removed when deploy to metal surface.
- Page 5 Punttoo User Manual Before Deployment - Important Steps and Advices 1. GETTING CELLULAR NETWORK REGISTERED FIRST (3-10 seconds) Single press on the power button to power on. Observe for a red light slowly blinking (half second on, half second off).
- Page 6 Punttoo User Manual ALWAYS avoid placing this device in a metal enclosure, where radio signals are shielded. 4. PROTECT THE CHARGING PORT WITH THE RUBBER BUD IN OUTDOOR USE (safety advice) Water leaking to inside may cause device damages and electronic hazardous.
- Page 7 Punttoo User Manual PRODUCT WARRANTY 1. Product carries one year limited warranty. Battery carries six months limited warranty. 2. Warranty voids if: opened or modified, operated under extreme conditions, or charged using non-designated chargers. 3. Warranty does not apply to operation area not covered by wireless carrier.
-
Page 8: Specifications
Said variables must be taken into consideration when installing or using the product, and Soniya shall not be responsible for installations or transmissions that fall outside of the parameters set forth in this publication. - Page 9 Punttoo User Manual ONLINE OPERATION GUIDE Soniya United Tracking www.unitedtracking.com Technical Support: support@unitedtracking.com Page 9...
-
Page 10: User Login
Punttoo User Manual USER LOGIN Browser Compatibility - computer based: [Recommended] Mozilla Firefox, Google Chrome [Supported] Microsoft IE 6.0 or above, Apple Safari (PC and iOS). [Not Recommended] Aol. Note: When viewed by incompatible browsers, map and some function may not display properly. - Page 11 Punttoo User Manual SUMMUARY PAGE This page provides a summary of a day recorded. Date can be selected from by calendar. Select a device to Click “Hide Panel” slide switch the display of off panel and make related information (below)
- Page 12 Punttoo User Manual The following two screens when control panel is slide off and on: Click to slide in control Controls of panel for device viewing information details direction Controls of viewing mode: road, Zoom control to bird’s eye, automatic.
- Page 13 Punttoo User Manual LIVE PAGE A colored arrow indicates target moving with direction at the moment. Screen refreshes automatically based on device interval setting. Different devices are shown in different colors. This section displays details of most recent reading received from...
- Page 14 Punttoo User Manual Click on this button to open set interval window (as shown from left of this screen) Select new interval to send over to device. Depends on device models, the range of interval may vary. Shorter interval tracks more often, but may consumes more power and shorten battery life.
-
Page 15: History Page
Punttoo User Manual HISTORY PAGE This page contains comprehensive history information to manage your report or diagnose problem. DEVICE RECEPTION HISTORY Three types of history record available in this page: Device Reception History: Record of all incoming signals received from device, whether locations is successfully detected (captured) or failed to detect (seeking). - Page 16 Punttoo User Manual CAPTURED LOCATION HISTORY Select device and date/time period to query history records. Maximum 7 days per query. If query period is more than 7 days, split into different phases less than 7 days. Captured Location History ...
- Page 17 Punttoo User Manual More options: Daily Report Print Download Playback Playback Console Click on spot to view specific information being playing now already played not played yet Page...
- Page 18 Punttoo User Manual Print Console GEOFENCE TEXT SENT LOG GeoFence Text Set Log Text messages/emails triggered by occurrence of GeoFence events. Once logged here, it means those messages have been delivered to your notification phone (as text message) and/or email address already at the time indicated here.
-
Page 19: Device Page
Punttoo User Manual DEVICE PAGE This page shows devices status of airtime service. User can also change device settings from here. INACTIVE: airtime expired. ACTIVE: airtime in service OFFLINE: airtime service expired long time ago View/Pay : click here to view service status or purchase new airtime. -
Page 20: Alert Menu
Punttoo User Manual ALERT MENU This is the page where Geo-Fence and other alert notifications are management. Notification is text messages to mobile phone (SMS), or email, or both at the same time. Types of notification are explained below: Arriving Location – Approaching a range of user defined area or user provided postal address. - Page 21 Punttoo User Manual Add a new Notification Delete existing Notification Edit existing Notification STEP 1: Set up Text-To-Phone first Page...
- Page 22 Punttoo User Manual Add a new phone Delete existing phone Click on Alert-Text-To-Phone first Edit existing phone STEP 2: Add/Edit texting notifications GeoFence is user defined area. When unit is detected entering or leaving this range, a notification alert will be generated and delivered to Notification Phone as text message.
-
Page 23: User Account Page
Punttoo User Manual Arriving Location - Entering a defined area centered by a user defined address (so called GeoFence). This notification is a text message. Leaving Location - Leaving a defined area centered by a user defined address (so called GeoFence). -
Page 24: End Of Document
Punttoo User Manual Update profile, e.g. email to receive service notice and recover lost password. User can also adjust time zone. (All date time in history are in location time zone as set at the time.) Update profile Change password...
