User's
Manual
Crimp-on lugs
with isolation
sleeves
DC output side
(Connects to the MW100)
Yokogawa Electric Corporation
772075
AC Adapter
This user's manual covers the specifications of the AC adapter. The polarity of the
connector is shown in the figure below. For details on how to use the AC adapter, see
the MW100 Data Acquisitin Unit User's Manual. An AC power cord comes with the
772075 AC Adapter. The type of AC power cord varies depending on the suffix code.
Suffix Code
Cord Type
D
UL/CSA cable
F
VDE cable
R
SAA cable
Q
BS cable
H
GB (CCC) cable
772075
AC input side
(Connect to the
AC power cord )
Power Cord
Red :
Connect to the MW100
power supply terminal +
Blue : Connect to the MW100
power supply terminal –
2nd Edition: January 2009 (YK)
All Rights Reserved, Copyright © 2005 Yokogawa Electric Corporation
Maximum Rated Power Voltage [V]
125
250
250
250
250
AC power cord
D: UL/CSA cable
F: VDE cable
Q: BS cable
R: SAA cable
H: GB cable
IM 772075-01E
2nd Edition
1/2
Advertisement
Table of Contents
Related Manuals for YOKOGAWA 772075
Summary of Contents for YOKOGAWA 772075
- Page 1 For details on how to use the AC adapter, see the MW100 Data Acquisitin Unit User’s Manual. An AC power cord comes with the 772075 AC Adapter. The type of AC power cord varies depending on the suffix code. Suffix Code...
- Page 2 410 g or less * AC adapter unit only WARNING • Use only power cords supplied by YOKOGAWA for the instrument. • Ensure that the supply voltage matches the rated supply voltage of the AC adapter before connecting the power cable.
