ASSEMBLY MANUAL AND SETUP GUIDE
DISTRIBUTED IN NORTH
AMERICA BY:
Global Hobby Distributors
8480 Bandilier Circle
Fountain Valley, CA 92708
All Contents Copyright © 2006, Global Hobby Distributors
Version  August 2006
Before beginning assembly of your new EF Helicopters M.A.S.H. Army Rescue Chopper, please read and understand the
warnings listed on the next two pages. Failure to do so could lead to bodily harm and/or injury.
The EF Helicopters M.A.S.H. Army Rescue Chopper is not intended for persons under 14 years of age, unless closely
supervised by an adult.
Made in China
DISTRIBUTED IN
EUROPE BY:
Ripmax Ltd.
24 Green Street
Enfield, U.K. EN3 7SJ

•
Main Rotor Diameter: ~ 340mm
•
Tail Rotor Diameter: ~ 56mm
•
Overall Length: ~ 425mm
•
Flying Weight: ~ 235gr (Including LiPO Battery)
•
Drive System: Two 180 Size Carbon-Brushed Motors
•
Servos: Two 7.6gr Micros
•
Battery: 7.4v 800mAH LiPO
•
Control System: 4-Ch Transmitter and 3-in-1 Receiver
M.A.S.H ARMY RESCUE CHOPPER FEATURES
•
Perfect for Beginners. Fun for Experts, Too
•
Comes Completely Built. Only Requires Very Basic Assembly
•
Hover Steadily Under Complete Control
•
Easier to Fly Than a Typical Helicopter
•
Fly Forward, Backward, Up, Down, Right and Left
•
Includes a Rechargeable LiPO Battery and AC Charger
•
Includes an Extra Set of Rotor Blades
•
Full-Size Controller with Adjustable Trims and Stick Length
•
Online Replacement Parts Support
Kit Product Number EF163125
