- Page 1 12843 Foothill Blvd., Suite D Sylmar, CA 91342 818 898 3380 voice 818 898 3360 fax www.dnfcontrols.com Model No. 2044CL-O-EVS (& 2044CL-O-T) 300 CLIP INSTANT ACCESS SYSTEM Odetics Protocol For EVS Video Servers ANUAL 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
-
Page 2: Table Of Contents
ADVANCED FEATURES . . . SHOTBOX SHOTKEY MAPPING TO SHOTLIST LOCATIONS SHOTBOX CONTROL SWITCHES CREATING A CLIP ON THE ST400 CAPTURE VIEW SHOTKEY ASSIGNMENTS ON THE SHOTBOX CREATE CUE POINT LABELS ON THE ST400 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... - Page 3 REFERENCE . . . SETUP MENU FUNCTION TABLE SPECIFICATIONS ST400 ST420 (SHOTBOX) TROUBLESHOOTING ST420 TROUBLESHOOTING KEY LAYOUT DNF CONTROLS LIMITED WARRANTY Manual Version..…....….....…....1.2 063005 Document ID..……..2044CL-O-EVS_User_Manual.doc 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
-
Page 4: Revision History
REVISION HISTORY 082504 1.0 Original document. 120104 1.1 Updated ST420 Troubleshooting section. 063005 1.2 Added Video Reference instructions. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 5: Getting Started
The 2044CL provides instant access to fill clip and key clip combinations with the press of one key. The 2044CL-O-EVS supports Odetics Broadcast protocol and requires that the Video Server be controllable under Odetics Broadcast Protocol. DEFINITIONS Throughout this document, DDR, VDR &... -
Page 6: System Installation
Attached House Video Reference cable to Ref. Video connector on the rear of the ST400. Video Reference must be connected for frame accurate playout of ganged channels, and for Capture function. Installation is complete. CONNECTION DIAGRAM 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 7: Video Server Setup
Manually enter a Clip ID using the ST400 numeric keypad or Shotbox “QWERTY” keyboard, or PC keyboard. Press [LOAD] to load the entered CLIP ID for playout. Repeat steps a - c to load clips on desired VTRs. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 8: Learn A Clip Or Clip Combination
Select the desired BANK by pressing BANK [1], [2], [3], [4], [5], [6], [7], [8], [9] or [0]. Press the desired Shotkey to complete the learn process. The learned CLIP ID is displayed on the Shotkey. Press [ESC] at anytime to escape without LEARNing. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 9: Recall A Clip Or Clip Combination
Press [RECUE]. If an IN Point is marked (the IN indicator is on), the clip will RECUE to the IN Point. If the IN point is not marked, the clip will RECUE to the start of the clip. Press [CUE OUT] to cue to the marked OUT point. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 10: Learn From The St400
Press [SHIFT] + [LEARN] to initiate the LEARN. The display will show: “Select VTRs to learn:--------” Select the VTRs to learn by pressing VTR keys [1], [2], [3], [4], [5], and/or [6]. Press [LEARN] to complete the learn process. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 11: Bvw Protocol
Press [MARK] to complete the LEARN. Press [ESC] to exit without LEARNING. The ST300 will: LEARN (save) the VTR number (1,2,3,4) and current IN & OUT time to the selected Cue Point. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 12: Recall From The St400
The CLEAR softkey will be displayed on the bottom of the display. Press the [CLEAR] softkey to clear the cue point. The cue point will be cleared and the display will return to the normal screen. Press [ESC] to escape without clearing. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 13: Loop Clip
Press [SHIFT] +[OUT]. Manually enter the OUT time on the numeric keypad. Press [ENTER]. Press [RECUE]. The clip will cue to the IN point. Press [PLAY]. The clip will play from its current time to the OUT point, then stop. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 14: Timecode Search
The cuepoints in BVW mode consist only of IN point, OUT point and Gang information. The following functions are not available in BVW mode: View Clip ID Recue Clip Loop Clip Capture Create Clip All other functions work as described in the manual. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 15: Advanced Features
The clip will be created with the entered CLIP ID. If the selected CLIP ID already exists, a warning message will be displayed. To load the existing clip, press [ENTER]. Press [ESC] to exit without loading the existing clip. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 16: Capture
The SOURCE VTR will preroll to its IN point, then play. The video server will start recording at the SOURCE’s IN point and stop recording at the SOURCE’s OUT point. The created clip will be loaded on the destination channel. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 17: View Shotkey Assignments
[ENTER] on the PC keyboard. [NEXT CUE] or [LAST CUE]. NOTE: Labels are saved in non-volatile memory in the ST400, not in the Shotbox. They are not saved in the video server. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 18: Reference
STATIC: The Preset Speed register is NOT updated when exiting SLOMO mode. It is only changed by [SHIFT] + [SLOMO] (PRESET SLOMO). Press [SPD-RNG] softkey to toggle between SLOMO speed ranges: 1x OR 0 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... - Page 19 Select BVW to control video server like a VTR. In this mode, the clip must have already been loaded. TIMECODE Select [NOT SUPPORTED] to have TC search on the GVG servers, or [SUPPORTED] for other servers. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
- Page 20 Clears all cue points in all banks. Follow the prompts on the display. CLR – LBL Clears all labels associated with cue points. Does not clear cue points. Follow the prompts on the display. BACK Return to prior menu item. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
-
Page 21: Function Table
SLO-MO SPEED [SHIFT] + [SLOMO] For WHEEL ONLY: Press [SHIFT] + [SLOMO] to preset the PRESET slo-mo speed. Turn the Wheel to select desired speed. Press [ESC] or any transport key to exit. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... - Page 22 RECUE If the IN point is marked, cue to the IN point. If IN point is not [RECUE] marked, cue to the beginning of the clip. (Under BVW protocol, no action occurs.) 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
-
Page 23: Specifications
Receive B Transmit B Transmit A Transmit Common Frame Ground Spare POWER CONNECTOR 9-Pin D-Type, Female (DB9M) Pin # +5v DC +5 VDC +5v DC Ground Ground Ground +12 VDC Ground –12 VDC 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... - Page 24 GPO 5 – No function GPO 6 – No function GPO 7 – No function No Connection Ground No Connection PLAY No Connection STOP No Connection RECUE No Connection NEXT CUE Ground 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol...
-
Page 25: Power Connector
Transmit B Receive B Receive A Receive Common Frame Ground Spare POWER CONNECTOR 9-Pin D-Type, Male Pin # +5v DC No Connection +5v DC Ground Ground Ground No Connection Ground No Connection 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 26: Troubleshooting
The ST420 displays: “ST300/400 SELECT” [ST300 V2.X] [ST300 V3.X] [ST400 V4.X – V5.20] [ST400 V5.30 and up] Press a key that corresponds to the version of the ST400 that you are using. 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 27: Key Layout
26. KEY LAYOUT 2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol... -
Page 28: Dnf Controls Limited Warranty
This warranty will be considered null and void if accident, misuse, abuse, improper line voltage, fire, water, lightning or other acts of God damaged the product. All repair parts are to be supplied by DNF Controls, either directly or through its authorized dealer network. Similarly, any repair work not performed by either DNF Controls or its authorized dealer may void the warranty.
