- Page 1 12843 Foothill Blvd., Suite D Sylmar, CA 91342 818 898 3380 voice 818 898 3360 fax Model 3000P-O PLAYLIST PLAYOUT SYSTEM Odetics Protocol USER MANUAL 3000P-O, Playlist Playout System...
-
Page 2: Table Of Contents
TO ABORT PLAYING A LIST OF CLIPS TO RECUE A CLIP TO EDIT A PLAYLIST SETUP MENU SPECIFICATIONS RS422 SERIAL CONNECTOR POWER CONNECTOR DNF CONTROLS LIMITED WARRANTY Manual Version..…........... 2.5 120704 Document ID........3000CL-O User Manual 3000P-O, Playlist Playout System... -
Page 3: Revision History
REVISION HISTORY 100803 Rev. 2.2 Company header information revised. 112103 Rev. 2.3 Added DNF Controls Limited Warranty. 020204 Rev. 2.4 Reformatted. Added Transferring Cue List section. 120704 Rev. 2.5 Removed Transferring Cue List section. 3000P-O, Playlist Playout System... -
Page 4: Description
Throughout this document VTR, DDR, VDR & Video Server will be referred to collectively as “Video Server.” Words surrounded by brackets, for example, [ENTER], are keys on the ST300. [XXX] + [XXX] means hold the two keys down simultaneously. XXX = Key name. 3000P-O, Playlist Playout System... -
Page 5: Installation
VTR4) on the rear of the ST300. Plug the other end of the cable into the 9-pin REMOTE connector on the Video Server. Plug the power supply into an outlet, 90 VAC to 240 VAC. Installation is complete. CONNECTION DIAGRAM 3000P-O, Playlist Playout System... -
Page 6: Video Server Setup
Enter the start time with the numeric keypad. Press [ENTER] to accept the default start time (00:00:00:00). To add additional clips to the Playlist, repeat steps 3 through 5. Press [ESC] to exit creating a Playlist. The EDIT LIST indicator goes out. 3000P-O, Playlist Playout System... -
Page 7: To Play A Single Clip
To position the pointer (*) use the up arrow [∧] or down arrow [∨]. Press [LIST TOP] to go the first CLIP in the PLAYLIST. Press [LIST END] to go the last CLIP in the PLAYLIST. 3000P-O, Playlist Playout System... - Page 8 The screen displays “ARE YOU SURE?” Press [ENTER] to delete the entire PLAYLIST. Press [ESC] to abort the delete. Press [ESC] to exit EDITING the PLAYLIST. The [LIST PLAY] function will continue while editing a playlist. 3000P-O, Playlist Playout System...
-
Page 9: Setup Menu
SET FACTORY DEFAULTS (This function is not implemented in VER 2.1 software). CLEAR CUE MEMORY Press [ENTER] to delete all entries in the PLAYLIST. Press [DEL] to abort clearing the PLAYLIST. ABOUT Displays Model, Version and Date Code of unit 3000P-O, Playlist Playout System... -
Page 10: Specifications
Receive A Transmit B Transmit Common Spare Receive Common Receive B Transmit A Frame Ground POWER CONNECTOR 9-Pin D-Type, Male (DB9M) Pin # +5v DC +5v DC Ground +12 VDC –12 VDC +5 VDC Ground Ground Ground 3000P-O, Playlist Playout System... -
Page 11: Dnf Controls Limited Warranty
DNF CONTROLS LIMITED WARRANTY DNF Controls warrants its product to be free from defects in material and workmanship for a period of one (1) year from the date of sale to the original purchaser from DNF Controls. In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support Department to afford the opportunity of identifying and fixing the problem without sending the unit in for repair.
