User's
Model 73201/02/03/04
Manual
Digital Multimeters
Store this manual in a safe
place for future reference.
IM 73201E
7th Edition Dec. 2011(YMI)
Disposing the Product
This Product complies with the WEEE Directive (2002/96/EC) marking
requirement.
The affixed product label (see below) indicates that you must not discard
this electrical/electronic product in domestic household waste.
Product Category
With reference to the equipment types in the WEEE directive Annex 1,
this product is classified as a "Monitoring and Control instrumentation"
product.
To return unwanted products within the EU area, contact your local
Yokogawa Europe B. V. office. Do not dispose in domestic household waste.
Yokogawa Meters & Instruments Corporation
International Sales Dept.
Tachihi Bld. No.2, 6-1-3, Sakaecho, Tachikawa-shi,Tokyo 190-8586 Japan
Phone: 81-42-534-1413, Facsimile: 81-42-534-1438
YOKOGAWA CORPORATION OF AMERICA (U.S.A.)
Phone: 1-800-888-6400 Facsimile: 1-770-254-0928
YOKOGAWA EUROPE B. V. (THE NETHERLANDS)
Euroweg 2, 3825 HD, Amersfoort, THE NETHERLANDS
Phone : 31-88-4641000 Facsimile : 31-88-4641111
YOKOGAWA AMERICA DO SUL LTDA. (BRAZIL)
Phone: 55-11-5681-2400 Facsimile: 55-11-5681-4434
YOKOGAWA ENGINEERING ASIA PTE. LTD. (SINGAPORE)
Phone: 65-6241-9933 Facsimile: 65-6241-2606
YOKOGAWA MEASURING INSTRUMENTS KOREA CORPORATION (KOREA)
Phone: 82-2-551-0660 to -0664 Facsimile: 82-2-551-0665
YOKOGAWA AUSTRALIA PTY. LTD. (AUSTRALIA)
Phone: 61-2-8870-1100 Facsimile: 61-2-8870-1111
YOKOGAWA INDIA LTD. (INDIA)
Phone: 91-80-4158-6000 Facsimile: 91-80-2852-1441
YOKOGAWA SHANGHAI TRADING CO., LTD. (CHINA)
Phone: 86-21-6239-6363 Facsimile: 86-21-6880-4987
YOKOGAWA MIDDLE EAST B. S. C (C) (BAHRAIN)
Phone: 973-17-358100 Facsimile: 973-17-336100
YOKOGAWA ELECTRIC CIS LTD. (RUSSIAN FEDERATION)
Phone: 7-495-737-7868 Facsimile: 7-495-737-7869
Safety Precautions
When operating the instrument, be sure to observe the cautionary notes
given below to ensure correct and safe use of the instrument. If you use
the instrument in any way other than as instructed in this manual,
the instrument's protective measures may be impaired. Yokogawa is by
no means liable for any damage resulting from use of the instrument in
contradiction to these cautionary notes.
Indicates a hazard that may result in the loss of life or
WARNING
serious injury of the user unless the described instruction
is abided by.
Indicates a hazard that may result in an injury to the user
CAUTION
and/or physical damage to the product or other equipment
unless the described instruction is abided by.
The instrument and this manual also use the following safety symbols:
Caution
This symbol indicates that the operator must refer to an explanation
in the instruction manual in order to avoid the risk of injury or death of
personnel or damage to the instrument.
Double Insulation
This symbol indicates double insulation.
Alternating current
This symbol indicates AC voltage/current.
Direct current
This symbol indicates DC voltage/current.
Fuse
This symbol indicates a fuse.
Earth TERMINAL
This symbol indicates ground.
WARNING
■ To avoid electric shock!
• Check the testing leads before use and do not use deteriorated or damaged
ones. Check the continuity of the testing leads.
• Do not use the instrument if there is any damage to the casing or when the
casing is removed.
• Disconnect the instrument from the circuit under test before opening the casing
to replace the batteries or for any other reason.
• Avoid using the instrument if it has been exposed to rain or moisture or if your
hands are wet.
■ To avoid electrical shock or fire!
Do not use the instrument in an atmosphere where any flammable or explosive
gas is present.
WARNING
■ To avoid damage to instrument or electric shock!
The restrictions on the maximum voltage level for which the 73201, 02, 03 and
04 multimeters can be used, depend on the measurement categories specified
by the safety standards. These category specifications are formulated to protect
operators against transient impulse voltages in power lines.
Measurement Category
Maximum Input Voltage
CAT. II
CAT. III
Measurement category
Description
For measurements performed on circuits
I
CAT. I
not directly connected to MAINS.
For measurements performed on circuits
II
CAT. II
directly connected to the low voltage installation.
For measurements performed
III
CAT. III
in the building installation.
For measurements performed at the
IV
CAT. IV
source of the low-voltage installation.
Category of Testing leads
With caps:
1000V 10A CAT.III / 600V 10A CAT.IV
Entrance
Without caps:
Cable
1000V 10A CAT.II / 600V 10A CAT.II
CAT. IV
CAUTION
• Do not use the multimeter near noise-emitting equipment or where there may
be a sudden temperature change. Otherwise, the instrument may produce an
unstable reading or errors.
• Do not wipe the instrument using any solvent (chemicals) such as benzine or
paint thinner. Otherwise, the front panel may be damaged or discolored.
When cleaning the instrument, use a dry cloth.
• Do not leave the multimeter exposed to direct sunlight or in a hot and humid
location such as the inside of a car, for any prolonged length of time.
IM3E-2011.7
Components
1) Function Switch
Turns off the power or selects the measurement mode.
OFF:
Turns off the power.
V:
AC voltage measurement
V:
DC voltage measurement
Ω/
:
Resistance measurement and continuity check (73202/03)
Ω :
Resistance measurement (73201/04)
:
Continuity check (73201/04)
:
Diode test
:
Capacitor check (73202/03)
µA:
DC/AC current measurement in micro-amperes
mA:
DC/AC current measurement in milli-amperes
A:
DC/AC current measurement in amperes
2) SELECT key (73202/03) or
This function is not supported on the 73204 multimeter.
This key is enabled only if the multimeter is in one of the following
measurement modes.
• Ω/
:
In this mode, the key selects between the resistance
measurem ent and continuity test.
•
:
In this mode, the key adjusts the stray capacitance of the
testing leads and the multimeter itself to zero.
(The display shows the
• µA/mA/A: In this mode, the key selects between the DC and AC modes.
* The 73201 multimeter comes with the / key instead of the SELECT
key. This key is used only to select between the DC and AC modes in the
current measurement mode.
3) RANGE key * This function is not supported on the 73204 multimeter.
Allows the operator to select the measuring range manually (the display
shows the
symbol).
R • H
To return to the normal auto-ranging mode, hold down this key for at
least one second until the display shows "AUTO."
4) AUTO-H key
Set up AUTO HOLD function. (the display shows the
600 V
300 V
Remarks
5) Display View with All Elements Turned On
Appliances, portable
Symbol and Unit
equipment, etc.
Lit when in DC-mode measurement
Distribution board,
circuit breaker, etc.
Lit when in AC-mode measurement
Overhead wire, cable
Polarity indicator lit when the polarity is negative
systems, etc.
Lit when in diode test
Lit when in continuity check
AUTO HOLD indicator
Internal Wiring
A • H
Distribution
CAT. III
Manual range indicator
CAT. II
R • H
board
AUTO
Auto range indicator
T
AUTO POWER OFF indicator
AUTO POWER OFF
CAT. I
Outlet
nF, µF
Unit for capacitance measurement
Fixed Equipment,
etc.
Equipment
Unit for voltage measurement
mV, V
µA, mA, A
Unit for current measurement
Ω, kΩ, ΜΩ
Unit for resistance measurement
Lit when stray capacitance is adjusted to zero
CAL
+ –
Lit when the batteries are low
Measuring Instructions
CAUTION
To avoid damage to Instrument or equipment.
• Before starting measurement, check to which mode the function switch is set
and make sure the testing leads are plugged into the terminals for the desired
mode of measurement.
• Temporarily remove the testing leads from the device under test before
operating the function switch.
• AC Voltage Measurement (
V
/
(73201/02/03)
4/10
/
key (73201)*
Black testing lead
Red testing lead
• DC Voltage Measurement (
V
symbol.)
CAL
/
4/10
Black testing lead
Red testing lead
NOTE
Do not mistake the following for a malfunction!
If the 400 mV range is selected and the testing leads are left open-circuited,
symbol).
the multimeter may give a certain reading. This does not affect your measurement.
A • H
<5> Display
• Resistance Measurement (Ω)
CAUTION
<2> SELECT key (73202/03)
or (
/
= key (73201)
To avoid damage to instrument!
<3> RANGE key
Turn off the power to the circuit under test before starting measurement in order
*(2) and (3) are not supported on the
to prevent any excessive voltage from being applied to the multimeter.
73204 multimeter.
<4> AUTO.H key
/
4/10
<1> Function switch
Black testing lead
Red testing lead
Input terminal
• Continuity Check (
CAUTION
To avoid damage to instrument!
Turn off the power to the circuit under test before starting measurement in order
to prevent any excessive voltage from being applied to the multimeter.
Description
/
4/10
Black testing lead
Red testing lead
V)
a) Set the function switch from the OFF position to the
V position.
b) Plug the black testing lead into the COM input termi
-
nal and the red testing lead into the V•Ω•
input
terminal.
c) Connect the testing leads to the circuit under test
and then read the multimeter when it stabilizes.
d) When measurement is complete, set the function switch
back to the OFF position and turn off the multimeter.
V)
a) Set the function switch from the OFF position to the
V position.
b) Plug the black testing lead into the COM input terminal
and the red testing lead into the V•Ω•
input terminal.
c) Connect the testing leads to the circuit under test
and then read the multimeter when it stabilizes.
d) When measurement is complete, set the function switch
back to the OFF position and turn off the multimeter.
a) Place the function switch in the Ω position (73201/04)
or Ω/
position (73202/03).
b) Plug the black testing lead into the COM input terminal
and the red testing lead into the V•Ω•
input terminal.
c) Connect the testing leads to the circuit under test and
then read the multimeter when it stabilizes.
d) When measurement is complete, place the function
switch in the OFF position and turn off the multimeter.
)
a) If the model is 73201 or 04, place the function switch
in the
position.
If the model is 73202 or 03, place the function switch
in the Ω /
position, and then press the SELECT key.
(The
symbol appears on the display.)
b) Plug the black testing lead into the COM input terminal
and the red testing lead into the V•Ω•
input terminal.
c) Connect the testing leads to the circuit under check.
If the circuit is continuous (no more than approximately
50 Ω), the buzzer sounds.
d) When the test is complete, place the function switch in
the OFF position and turn off the multimeter.
