Summary of Contents for d&b audiotechnik R70
- Page 1 Ethernet to CAN interface Manual (1.4 EN)
- Page 2 General information R70 Ethernet to CAN interface Manual Version 1.4 EN, 04/2009, D2402.EN .01 Copyright © 2009 by d&b audiotechnik GmbH; all rights reserved. d&b audiotechnik GmbH Eugen-Adolff-Strasse 134, D-71522 Backnang, Germany Telephone: +49-7191-9669-0, Fax: +49-7191-95 00 00 E-mail: docadmin@dbaudio.com, Internet: www.dbaudio.com...
-
Page 3: Table Of Contents
3.5. LAN network without DHCP server...........14 3.6. R70 Web interface.................15 3.6.1. Device Info..................15 3.6.2. LAN and CAN Parameters............15 4. R70 accessories and anti-theft protection (LOCK)..17 4.1. Mounting clamp..................17 4.1.1. Attaching the mounting clamp..........17 4.2. Anti-theft protection – LOCK...............17 4.3. Dimension drawings................18 5. -
Page 4: R70 Ethernet To Can Interface
LAN connector. The R70 contains a web interface for configuration using a standard web browser. Up to five R70 interfaces in TCP/IP mode may be connected to a PC and simultaneously operated by the R1 software. -
Page 5: Scope Of Supply
Europe, UK, USA, and Australia Z6116 RJ 45 M Terminator [3] CD-ROM [4] containing the R70 manuals and additional documentation (TI 312). Additionally, the AcrobatReader® in its current version is provided to allow the documents to be displayed and printed. -
Page 6: Technical Specification
Dimensions (height x width x depth).....115x110x35 mm [4.5" x 4.3" x 1.4"] Weight......................230 g (0.5 lb) 114 [4.5"] 35 [1.4"] Fig. 1: Dimensions in mm [inch] Additional accessories Z6123 Bopla mounting clamp upright.............wall mounting ....................top hat rail mounting (TS 35) Page 6 of 20 R70 Ethernet to CAN interface, Manual... -
Page 7: R70 Hardware
GmbH R70 Hardware 2. R70 Hardware The hardware of the R70 Ethernet to CAN interface is housed in a rugged aluminium enclosure including connectors, controls, and indicators. Left Right panel panel panel 2.1. Connectors 2.1.1. Power supply [DC IN] The device can be powered by Ethernet (PoE, IEEE 802.3af) or by an... -
Page 8: Can-Bus Connectors [2]
RJ 45 [2] Signal Remark CAN high bus line (active high) CAN_H CAN low bus line (active low) CAN_L 1..45..8 CAN ground Shell Table 2: RJ 45 (CAN-Bus) pin assignment Page 8 of 20 R70 Ethernet to CAN interface, Manual... -
Page 9: Controls And Indicators
Bus segment. Please refer to the technical information TI 312 d&b Remote network for more detailed information. The R70 interface has a built-in switchable terminator which can be activated when only one of its CAN connectors is used (refer to the wiring examples given in the following section). - Page 10 TERMINATE RJ 45 M Terminating connector d&b R70 Ethernet to CAN interface Fig. 5: d&b Remote network (CAN-Bus), wiring example 1 with terminated R70 interface at the "beginning" of the CAN- Bus segment. CAN-Bus PC running MUTE LEVEL PUSH MENU...
-
Page 11: Indicators (Status Leds)
GmbH R70 Hardware 2.2.2. Indicators (Status LEDs) The R70 interface is equipped with four LEDs for visual status control of the device. The function of each LED is described in the table below: LED (Col. [Pos.]) Status: Description... -
Page 12: R70 Operation And Configuration
Subnet mask: 255.255.255.0 Apply the changes by clicking OK and close the network properties dialog. To display the web interface of the R70, enter the IP address of the R70 in the address bar of your web browser. Page 12 of 20... -
Page 13: Lan Network With Dhcp Server
TCP Port 30000 (adjustable). The "Obtain an IP address automatically" function is enabled by default. Connect the R70 to your network and an IP address is assigned by the DHCP server. Start the respective d&b software (e.g. R1 - Edit mode) and select "CAN"... -
Page 14: Lan Network Without Dhcp Server
GmbH 3.5. LAN network without DHCP server When the R70 is connected to a network without DHCP server, the R70 must be adapted to the local network. To do so, first proceed as described in the previous section (Direct connection) to gain access to the R70. -
Page 15: R70 Web Interface
GmbH R70 operation and configuration 3.6. R70 Web interface The R70 does not require its own drivers for use with a computer. All configurations can be set using a standard web browser with JavaScript enabled. Recommended web browsers: Windows Microsoft Internet Explorer 6.0 or higher... - Page 16 GmbH LAN Parameters In the "LAN Parameters" tab, the settings of the R70 can be modified to the on site conditions of the local area network. When more than one R70 is used, each one must have a unique IP address and host name.
-
Page 17: R70 Accessories And Anti-Theft Protection (Lock)
The two clamp halves have different lengths. For this reason, we recommend you to align the clamp or the R70 in such a way that the short clamp half is located on the top panel of the device (see graphic opposite). -
Page 18: Dimension Drawings
R70 accessories and anti-theft protection (LOCK) d&b audiotechnik GmbH 4.3. Dimension drawings 4.4 [0.2"] 54 [2.1"] Fig. 7: Z6123 Bopla mounting clamp upright, dimensions in mm [inch] Fig. 8: Wall mounting with dimensions in mm [inch] Fig. 9: Top hat rail mounting with dimensions in mm [inch]... -
Page 19: Manufacturer's Declarations
5.1. EU declaration of conformity (CE symbol) This declaration applies to the: R70 Ethernet to CAN interface, Z6124.000 manufactured by d&b audiotechnik GmbH. All products of this type starting from variant Z6124.000 are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications. - Page 20 d&b audiotechnik GmbH, Eugen-Adolff-Str. 134, D-71522 Backnang, Germany, Phone +49-7191-9669-0, Fax +49-7191-95 00 00...
