14.11.2012

R70

Ethernet to CAN interface

Quick guide (1.1 EN)

R70 web interface / Recommended browsers

Windows:

Microsoft Internet Explorer 6.0 or higher,

Mozilla Firefox 2.0 or higher.

Mac OS:

Safari 1 or higher.

R70 Ethernet to CAN interface

Physical setup / IP address

Note: When Power over Ethernet (PoE) is available, the

external power supply is not required.

When the R70 is connected to a network with a DHCP server

present, a matching IP address is assigned to the interface

automatically.

In all other cases, the R70 must be adapted manually.

The R70 IP address is set to 192.168.1.70 by factory default

(see also the label sticker on the rear panel of the R70).

Page 1 Physical setup / IP address Note: When Power over Ethernet (PoE) is available, the external power supply is not required. When the R70 is connected to a network with a DHCP server present, a matching IP address is assigned to the interface automatically.
Page 2 Quick guide (1.1 EN) Direct connection LAN network with DHCP server To access the R70, manually assign an IP address to the PC on your The "Obtain an IP address automatically" function is enabled by network to the same subnet as the R70.
