Please completely read and understand the entire manual before using, assembling and/or
disassembling your remote controlled car.
1/16TH SCALE 4WD ELECTRIC POWERED TRUGGY/MONSTER TRUCK
TRUGGY
NAME
LENGTH
265mm
TREMOR SG
270mm
TREMOR ST
Notification: This data is subject to change without notice.
The Redcat Racing Tremor 1/16h Scale series are Ready to Run and include a Li-Ion 7.4V, 800mAH battery
pack, charger.and charger adapter. Please use the included charger to charge your Li-Ion battery pack.
These vehicles feature a 3-in-1 unit (ESC/receiver/5 wire servo) and a 2.4GHz radio system, which are
considered entry-level hobby grade products and suitable for R/C beginners. Ball bearings and brass
bushings are installed throughout the vehicles.
Many optional parts are available to upgrade your vehicle. Please refer to the part lists or visit
www.redcatracing.com. If you perform a drive train upgrade, you must replace the entire system
(such as motor, ESC, receiver, ball bearings) so that all components are properly matched. Any malfunction
incurred by custom modification or incorrect operation of your vehicle will void your warranty.
This product is not a toy. It is not intended for persons under 14 years of age, unless closely
supervised by an adult.
This manual is subject to change without notice.
WIDTH
HEIGHT
205mm
110mm
215mm
135mm
INSTRUCTION MANUAL
WHEELBASE WHEEL SIZE GEAR RATIO
70mm(Dia.)
175mm
40mm(Width)
80mm(Dia.)
175mm
45mm(Width)
MONSTER TRUCK
MOTOR &
BATTERY
1: 11.44
RC 380 Motor,
Li-ion Battery
Pack (7.4V,
1: 11.44
800mAH)
Advertisement
Table of Contents
Related Manuals for REDCAT Tremor SG
Summary of Contents for REDCAT Tremor SG
- Page 1 Notification: This data is subject to change without notice. The Redcat Racing Tremor 1/16h Scale series are Ready to Run and include a Li-Ion 7.4V, 800mAH battery pack, charger.and charger adapter. Please use the included charger to charge your Li-Ion battery pack.
-
Page 2: General Information
Never attempt to re-assemble any electronic components. These have been carefully calibrated at the factory. Only use Redcat Racing manufactured parts to upgrade your car. If you perform a drive train upgrade, replace the entire system (Such as motor, ESC/receiver unit and the like) so that all components are properly matched. -
Page 3: Safety Information
SAFETY INFORMATION We want you to enjoy your R/C vehicle and to operate it with care. Failure to operate your vehicle in a safe and responsible manner may result in injury to yourself and others and may cause damage to property. Read and understand all instructions carefully before use and assembly/disassembly. - Page 4 FAMILIARIZING YOURSELF WITH YOUR 2.4GHz RADIO SYSTEM Your car is equipped with the new 2.4GHz radio system. Please read and understand all instructions below before operating. A: Steering Wheel 1: Steering Trim 4: Power Switch 7: Throttle Reverse B: Trigger 2: Steering Reverse 5: Steering Dual Rate 8: Green Indicator...
- Page 5 TO BIND THE RECEIVER TO THE RADIO CONTROLLER Before running, make sure that the radio controller is bound with the receiver, which has been done at factory. If the model is not responding to the controller, it is possible that the controller and receiver are not bound, and you must perform the binding procedure following the instructions below.
- Page 6 CHECK STEERING PERFORMANCE Ensure good steering performance. CENTRE TURN LEFT TURN RIGHT 1) To keep the car running in a 2) Turn the control wheel left to 3) Turn the control wheel right to straight line , do not move the allow your vehicle to turn left.
-
Page 7: Battery Installation
TO TUNE THE STEERING DUAL RATE CONTROL DIAL Decrease Increase STEERING D/R This dial adjusts the overall travel of the steering servo. Push the dial forward for maximum steering. Pull the dial back to reduce the steering level. - Set the Steering Dual Rate Control Dial to Minimum first. To set the desired steering level increase it again whilst decelerating your vehicle. -
Page 8: Charging The Battery Pack
CHARGING THE BATTERY PACK To be connected to the charging Charger Adapter socket. Charger (9V, 600mA) To be connected Li-ion Battery To be connected Pack -Use only the specified charger (9V,600mA) to charge the Li-Ion battery pack. - You must use the charger adapter during charging. Connect one side to the charger and the other side to the battery pack. -
Page 9: Troubleshooting
MAINTAINING YOUR CAR After running your car, perform the following procedures regularly to maintain your car's performance. Inspect your car for any obvious damage. Check the gears for wear, debris or broken/slipping teeth. Check the wheels and tighten the wheel screws properly. Check for loose screws in the chassis. -
Page 10: Part List
PART LIST-1 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16810 ITEM NO.: 16003 ITEM NO.:16004 ITEM NO.: 16005 2PCS 4PCS 4PCS 4PCS Steering Bush+ Steering Post Suspension Hinge Pins-Outside Suspension Hinge Pins-Inside Shock Coils +E-clip(2mm/4mm) ITEM NO.: 16006 ITEM NO.: 16007 ITEM NO.: 16008 ITEM NO.: H011 2PCS... - Page 11 PART LIST-2 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16048 ITEM NO.: 16049 ITEM NO.: 16050 ITEM NO.: 16051 Male connector applied Female connector applied Li-ion Battery Pack (7.4V, Motor RC 380 (25000rmp) 5-Wire Servo ( 19g) 3-in-1 Unit (7.4V, 25A) 800mAH) ITEM NO.: H021 ITEM NO.: P011...
- Page 12 2.5*5mm ITEM NO.: 17003 ITEM NO.: 17002 ITEM NO.:17001 ITEM NO.: 17004 Tremor ST truck Body (Blue) Tremor ST truck Body (Red) Tremor SG truggy Body (Blue) Tremor SG truggy Body (Green) The images may vary from the received items.
-
Page 13: Optional Parts
OPTIONAL PARTS 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16800 ITEM NO.: E710 ITEM NO.: 16802 ITEM NO.:16803 Alum.Capped Oil Filled Shocks. Independent 2.4GHz Receiver + Ball Joints (Fr./Rr.) Brushless Motor Brushless ESC ITEM NO.: 16804 ITEM NO.: 16805 ITEM NO.: 16806 ITEM NO.: E775 The pannel and the... - Page 14 UNITS ASSEMBLY VIEW SHOCK ASSEMBLY 16005 16024 FINISHED 16024 SERVO INSTALLATION 16018 16051 88021 16025 S149 FINISHED DIFF. ASSEMBLY (Front) 16026 16804 H030 16020 S011 16811 （6.3*12.5*0.2mm) 16020 16020 16092 16020 16020 16811 （6.3*12.5*0.2mm) 16020 16804 16026 FINISHED...
- Page 15 DIFF. ASSEMBLY (Rear) 16026 16804 H030 16020 S011 16811 （6.3*12.5*0.2mm) 16020 16092 16020 16020 16020 16811 （6.3*12.5*0.2mm) 16020 16804 16026 FINISHED 16007 Steering Assembly View 88021 16025 16025 E-Clip(4mm) is applied here after the kit is assembled. 16810 16025 16025 16810 E-Clip(2mm) is applied here after the kit is...
- Page 16 SLIPPER CLUTCH SET ASSEMBLY 16093 16093 16091 16093 16093 16092 16094 16094 16094 16094 16090 H030 H030 16094(Shim) 4* 8*0.5 16094 (O-ring) 5* 3*1 TIPS: Use needle-nose pliers to adjust the slipper clutch set as shown in the picture. Place the car with its four wheels landing on the ground.
- Page 17 16043 EXPLODED VIEW 16072 1-16TH SCALE 4WD ELECTRIC 16042W(16042K) OFF ROAD TRUGGY S013 16023 S062 16037 S062 S013 S029 S062 16027 16033 S062 16030 16008 16026 16006 S029 S138 16003 16022 16034 16072 16043 16004 16092 S020 S091 H030 S029 S013 H030 S091...
- Page 18 16045 EXPLODED VIEW 16072 1-16TH SCALE 4WD ELECTRIC 16042W(16042K) OFF ROAD MONSTER TRUCK S013 16023 S062 16037 S062 S013 S029 S062 16027 16033 S062 16030 16008 16026 16006 S029 S138 16003 16022 16072 16034 16045 16004 16092 S020 S091 H030 S029 S013 H030...
- Page 19 Please completely read and understand the entire manual before using, assembling and/or disassembling your remote controlled car. This product is not a toy. It is not suitable for users under 14 years old unless supervised by an adult. Never attempt to re-assemble any electronic components. These have been carefully calibrated at the factory.
