Santon A7/3 Installation And User Instructions

8. FAULT FINDING

SYMPTOM PROBABLE CAUSE ACTION
No hot water 1. Check power Check and replace as necessary.
2. Faulty cut out
3. Faulty thermostat
4. Faulty element
Water too hot 1. Thermostat set to Adjust thermostat.
/cold wrong temperature
2. Faulty thermostat Switch off, check and replace.
No water flow 1. Frozen Switch off electrical power and
allow to thaw at room temperature.
Do not switch on again until full water
flow restored and full checks made for
leaks and electrical safety.
2. No mains supply Check mains.
Continuous water Faulty valve/tap Check and replace.
flow
FIGURE 3 : DIMENSIONS
240
120
2 KEYHOLE
FIXING SLOTS
6mm WIDE
COLD WATER INLET VALVE
DIMENSION X Y
7 LITRE 356 349
10 LITRE 442 435
100

9. SPARE PARTS

In the unlikely event of your Water Heater developing a fault, the following spare parts are
avaliable:
Element plate assembly 1.2kW
Element plate assembly 3kW
Element plate assembly gasket (pk of ten)
Over temperature cut-out
Capillary thermostat
Control valve
Spout adaptor
Spout (12") complete with adaptor
Top cover moulding
Terminal cover

10. GUARANTEE

This product is guaranteed against faulty materials and manufacture for a period of 2 years from the
date of purchase provided that:
1. The unit has been installed in accordance with the Installation and User Instructions
and all relevant Codes of Practice and Regulations in force at the time of Installation, and
that all necessary controls and safety valves have been fitted correctly.
2. Any valves and controls are of the Santon recommended type and specification.
240
3. The unit has not been modified or tampered with in any way, and has been regularly
maintained as detailed in the Installation and User Instructions.
4. The unit has been used only for heating potable water.
The unit is not guaranteed against damage by frost, and the inner container with integral
immersion heater is not guaranteed against excessive scale build-up.
This Guarantee in no way affects the statutory rights of the consumer.
The policy of Santon is one of continuous product development and, as such, we reserve the right
to change specifications without notice.
FIXING HOLE

11. ENVIRONMENTAL INFORMATION

Santon products are manufactured from many recyclable materials.
At the end of their useful life they should be disposed of at a Local Authority Recycling Centre in
order to realise the full environmental benefits.
Insulation is by means of CFC-free polyurethane foam.
57
300
Hurricane Way,
Norwich,
Norfolk, NR6 6EA.
www.santon.co.uk
A member of Baxi Group Ltd.
95 606 934
95 606 763
95 611 708
95 612 688
95 612 667
95 605 857
95 604 677
95 604 678
95 614 272
95 614 273
Sales Tel: (01603) 420130
Sales Fax: (01603) 420149
Sales Email: sales@santon.co.uk
Service Tel: (01603) 420347
Service Fax: (01603) 420349
Service Email: service@santon.co.uk
Installation and User Instructions
Aquarius Oversink Vented Water Heaters
Models: A7/3, A7/1, A10/3, A10/1
Please read and understand these instructions before starting work.
Please leave this leaflet with the user following installation
PACK CONTENTS
Heater, Fixing screws and plugs,Spout, Valve
Installation and User Instructions.
WARNING
This water heater must only be installed by qualified persons.
36005792 Issue 2.
.
