VAGABOND MINI™ LITHIUM Specifications
Battery Type
Battery Volts / Amp-Hours
Battery Watt-Hours (Energy)
Maximum Continuous Current
Full Charge Voltage
Cutoff Voltage
Maximum Continuous Output
Battery Charger Input and
Battery Charger Output
Charging Time
Inverter Fuse (Front Panel)
Total Weight and
Dimensions
Your VAGABOND MINI™ LITHIUM Arrives With
1. The Internal CU120 Vagabond Mini™ Lithium Inverter (in VM120 systems, for use with
standard Paul C. Buff™ flash units / power packs): The CU120 is a power inverter
made exclusively for the Vagabond Mini™ Lithium system. The unit converts the
power from the internal battery to a 120VAC, 60 Hz current-controlled, pure sine
wave power source, specifically engineered for powering Paul C. Buff™ units.
- or -
1. The Internal CU120-230V Vagabond Mini™ Lithium Inverter (in VM120-230V systems,
for use with 220V / 230V AlienBees™ and Einstein™ units): The 230V model of the
system contains the CU120-230V power inverter. The unit converts the power
from the internal battery to a 230 VAC, 50 Hz current-controlled, pure sine wave
power source, specifically engineered for powering Paul C. Buff™ units.
The converted power with both systems is similar to the power that you would
get from a standard power line when shooting in the studio with your flash units
/ power packs connected to an AC power outlet.
VM120 system:
two standard 120VAC
outlets on the CU120
inverter
In order to allow single or multiple flash units to operate from a small inverter,
the inverter must act as a 120VAC (or 230VAC) voltage generator when it is not
overloaded, but must revert to becoming a continuous current source when the
6
LiCoxNiyMnzO2 lithium battery
14.8V / 8.8AH
130 Watt-Hours
30ADC
16.6VDC
11VDC
120 Watts
95VAC to 250VAC, 50/60Hz input
16VDC, 3A output
3 to 4 hours to full charge (with VMC3A charger)
30A automotive-type fuse
3.5 pounds (with battery)
2.75" x 4.3" x 7.5" (without stand clamp)
VM120-230V system:
two Australian / Chinese
Type I 230VAC outlets on the
CU120-230V inverter
