Operating Manual
Conveyor Toaster
TM-5H
Thank you for purchasing the SUNTEC products.
To ensure best results and use for a long time, it is
important that you read, understand and follow
these instructions in this manual carefully before
using.
This manual should be retained for future reference.
Safety Precautions
The following words and symbols, found in this
manual, alert you to hazards to the operator, service
personnel or the equipment. The words are defined
as follows; WARNING: This symbol refers to a
potential hazard which could result in serious injury
or death. CAUTION: This symbol refers to a potential
hazard or unsafe practice which may result in minor
or moderate injury or product or property damage.
However, indicated CAUTION may result in serious
condition by situation, it is important that you follow
the instruction in this manual carefully.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SUNTEC TM-5H
Summary of Contents for SUNTEC TM-5H
- Page 1 Operating Manual Conveyor Toaster TM-5H Thank you for purchasing the SUNTEC products. To ensure best results and use for a long time, it is important that you read, understand and follow these instructions in this manual carefully before using. This manual should be retained for future reference.
- Page 2 WARNING WARNING ！ The products which electric power is over It could result in fire 1.0kw must plag a by ignition. properly(grounded) indlvidual receptacle. Do not cover the product with a cloth It could result in fire. or plastic bag while you are using it.
- Page 3 WARNING WARNING ！ Never touch the plate or around while the It could result in burn.. product is working because there are very hot. Please note the There is fear of Hi a thickness and the fire in the upper part. length of bread.
-
Page 4: Before First Use
CAUTION CAUTION ！ It could result in Always keep cleaning obstruction of safety the workshop. or efficient work. Check the supply cord regularly. If it is It could result in damaged, it must be electric shock or replaced with a new ignition by short cord assembly available from the... -
Page 5: Parts Description
Parts Description Entrance Switch/ Pilot Lanp Thermostat Color Contrl Front Discharge Description：Electric Conveyor Toaster About the Switch/Thermostat Model：TM-5H One side Power：AC100V B U N S Electricity Both sides Power Save Mode Consumption：1480W B R E A D S T B Y Measurements：290(W)×420(D)×420(H) - Page 6 Set-up Set-up ・Install the legs. If unit is not level, use 9/16"(14mm) open-end wrench to adjust the foot of each leg until unit is level. ・Toast Feed Ramp The toast feed ramp is installed at the factory and can be used in tow positions.
-
Page 7: Power Save Mode
Operation Operation For model equipped with rocker switch For model equipped with rocker switch 1.Plug toaster into a properly grounded electrical outlet of the correct voltage, size and plug configuration. 2.Place the On/Off switch in the On position. 3.Turn the Color Control to the lightest position while the unit heats up. - Page 8 Safety Safety ・This product should not be cleaned with water. It's very dangerous. ・Wipe off the product with a dry cloth and always keep clean. ・If the plates don't work sufficiently, contact with your agency. To change the plates is at your cost. ・A warranty should be retained carefully, it's writtn a serial number of the product.
-
Page 12: After Service
・If it's under warranty, should attach the warranty with the product. ・When you order to repair, should attach a memo which is written a breakdown condition of the product. SUNTEC CO., LTD 2-8-12Mukojima, Sumida-ku, Tokyo 131-0033 Japan Telephon No.81-3-6746-9797 Facsimile No.81-3-6746-9669...
