Page 1: User Guide
IAD100T User Guide IAD100T GATEWAY User Guide Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 2: Table Of Contents
IAD100T User Guide Contents 1. Introduction …………………………………………………………………….……………..3 1.1 Appearance and interface of IAD100T…………………………………………………………3 1.2 IAD100T Supported protocol…………………………………………………………………..4 1.3 IAD100T Network Features………………………………………………………………….…4 1.4 IAD100T Advanced Functions………………………………………………………………….5 1.5 Configuration, management and maintains…………………………………………..…………5 2. Installation………………………………………………………………………………………..6 2.1 Standard Package …………………………………………………………………….…………6 2.2 Installation……………………………………………………………………………………….6 2.3 Display and status indicators…………………………………………………………………….6 3. -
Page 3: Introduction
To ensure you can get the professional service with the product, you should read and understand this manual before you attempt to install or operate the IAD100T.Please keep it for your future reference. This manual is for the IAD100T gateway and includes the installation, basic functions and special futures. -
Page 4: Iad100T Supported Protocol
IAD100T User Guide Interfaces IAD100T gateway has 4 ports: two RJ45 ports and two RJ11 ports. The following table provides the hardware specifications for the IAD100T: Items Specification Power Adaptor Input Voltage 100-240V AC Specification Output Voltage 12V DC Interfaces... -
Page 5: Iad100T Advanced Functions
IAD100T User Guide ◆ Support SIP application, including SIP Call forward/transfer/holding/waiting. ◆ Support L2TP protocol 1.3 IAD100T Network Features: ◆ Support two models: Bridge and Router, and integrates the router functions of these two ports. ◆ Support basic NAT and NAPT ◆... -
Page 6: Installation
◆ One universal power adapter (different model per area); One user manual and one Lifeline accessory Warning: The IAD100T series gateway, the power follows UL standard. This product can only use the power adapter that shipped with the packaging. Damage to the gateway cause by using unsupported power adapter would not be covered by manufacture’s warranty. -
Page 7: Display And Status Indicators
DNS server address automatically, after confirmed. The computer will get IP address automatically. Then input “cmd” and press “enter”, under the window line input “ipcofig/all” can look over default gateway, LAN IP for network. Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 8: Configuration With The Web
The web configuration interface mainly consists of the configuration menu on the left and configuration interface on the right, enter the corresponding configuration interface to configure by selecting the menu, please see as below: Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 9: User Login And Verification
(default IP is 192.168.10.1) in the IE browser to login the system by WEB, user can select the login mode according to the real situation. Administrator account: the default user name and password both are “admin”; this user can configure the system. Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 10: Network Configuration
LAN IP is 192.168.10.1); If your LAN router does not have open DHCP server function. You need configure the WAN port to the static IP address. When configuring static IP, the static IP must be in the same IP segment with the IP of LAN router. Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 11: Sip Server Configuration
Gateway SIP registers status indictor. The character ‘Registered” will show after you register successful, otherwise the character “Unregistered” will show. Set the SIP register server address, it can be the IP address or the domain name. Set the SIP register server port. Wuchuan Network Tech Co., Ltd www.5111soft.com... - Page 12 Configured enable/disable register. Successfully register when you select “Enable”. Support SIP prack function or not. Advise to use default configuration, the configure should guide by the professional technician. Support Signal Encrypt function or not Wuchuan Network Tech Co., Ltd www.5111soft.com...
-
Page 13: Iax2 Protocol Configuration
Local IAX monitor port (signal port of local) If the IAX supports the voice mail number, but your username of the voice mail is letters which you can not input with gateway, then use the number to replace your username. Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 14: Save And Clear The Configuration
“Flash” again and turn back the calling with A, at last press”*” to complete the three way call. Note: The SIP server must be support when using the call transfer and three way call, and make Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 15: Config Via Phone Keyboard
◆ WAN defaults to get IP address through the DHCP mode, if it’s switched to Static mode, the IP address is 192.168.1.179, and the LAN IP address is 192.168.10.1, the DHCP service and NAT service for LAN Wuchuan Network Tech Co., Ltd www.5111soft.com... -
Page 16: Faq
7.5 Why does it encounter busy tone when pick up phone? Our new edition IAD100T gateway add line ditection function, when not any account is registered or without connecting with PSTN line, gateway will suggest a busy tone prompt to warn that users cannot make calls normally. - Page 17 If you meet any problem when you using our product, please visit our website www.5111soft.com the technological FAQ page to find out the answer which you need, if not, please send your request by mail or telephone to our technical support department for help, thanks. Wuchuan Network Tech Co., Ltd www.5111soft.com...
