  • Page 1 IAD100T Advanced Configuration Manual Advanced Configuration Manual Gateway IAD100T Wuchuan Network Tech Co., Ltd www.5111soft.com...

  • Page 2: Table Of Contents

    IAD100T Advanced Configuration Manual Content 1. INSTALLATION ............................3 1.1 I ............................3 NSTALLATION 1.2 D ....................... 4 ISPLAY AND STATUS INDICATORS 1.3 O ........................... 4 BTAIN ADDRESS 2. WEB CONFIGURATION ..........................6 2.1 P ...................... 6 ROCEDURE OF EB CONFIGURATION 2.1.1 Login Web..............................

  • Page 3: Installation

    To ensure you can get the professional service with the product, you should read and understand this manual before you attempt to install or operate the IAD100T.Please keep it for your future reference. This manual is for the IAD100T gateway and includes the installation, basic functions and special futures.

  • Page 4: Display And Status Indicators

    IAD100T Advanced Configuration Manual For the LAN port, you can connect it to the PC Connect a phone cable between the PSTN and the PSTN port on the gateway as the lifeline. Use a RJ11 phone cable to connect between the phone and the PHONE port on the gateway.
  • Page 5 IAD100T Advanced Configuration Manual Select Internet protocol（TCP/IP）, click the third button except install and unistall. As the above picture shows, choose to get IP address with DNS server address automatically. After confirmed, the computer will get IP address automatically. Then input “cmd” and press “enter”, under the window line input “ipcofig/all”...

  • Page 6: Web Configuration

    IAD100T Advanced Configuration Manual In the picture we can the default IP address is 192.168.10.1, so the default LAN IP address is 192.168.10.1, then we can access by the following URL: http://192.168.10.1 to set. Note: If LAN haven’t DHCP server, we get LAN mouth purpose of IP hope PC can imprison through...

  • Page 7: Login Web

    IAD100T Advanced Configuration Manual 2.1.1 Login Web The IP gateway Web configuration menu can be accessed by the following URL: http://xxx.xxx.xxx.xxx/. If the web login port of the gateway is configured as non-80 standard port, the user need to input: http://xxx.xxx.xxx.xxx：xxxx/, otherwise the web will show that no server has been found.

  • Page 8: Network Config

    The Version number and issue date have been shown at the end of page: 2.2.2 Network WAN ——IAD100T gateway’s WAN port to connect the internet, we have three modes connection for ◆ users to choose, DHCP mode, STATIC mode and PPPOE mode.
  • Page 9 IAD100T Advanced Configuration Manual address. Note: If users log on via WAN and modify the IP mode, they need to enter a new address again. Config instructions: Display current active IP, netmask, MAC address and current gateway IP; , select WAN port getting IP mode; User can only select one mode.
  • Page 10 IAD100T Advanced Configuration Manual ◆ LAN ——User can make LAN configuration on this page, when bridge is selected, the LAN configuration will no longer go into effect. Configuration explanation: Bridge mode (transparent mode): Bridge mode will make the gateway no longer set IP address for LAN physical port, LAN and WAN will connect in the same network.

  • Page 11: Voip Config

    IAD100T Advanced Configuration Manual 2.3 VOIP config 2.3.1 SIP register User can configure specific SIP signaling protocol on this page. Config explanations: SIP register state; If register successfully, there will show Registered, otherwise Unregistered; Configure SIP register server address (IP address can also be a domain name) Configure SIP register server signal port.

  • Page 12: Iax2 Config

    IAD100T Advanced Configuration Manual usually this blank is empty no need to fill in. Configure local SIP signal port, default port is 5060(this port will go into effect immediately; the SIP call will use the modified port for communication after modification).
  • Page 13 IAD100T Advanced Configuration Manual IAX2 server address can be domain name IAX2 server port (register port of public server) Account name (user name of your SIP account) Account password (password of your IAX2account) Register phone number (phone number of your IAX account)

  • Page 14: Advanced Config

    IAD100T Advanced Configuration Manual 2.4 Advanced Config 2.4.1 DHCP config User can configure DHCP service in LAN port on this page. Configuration Explanation: Configure DNS Relay; The user to connect LAN gateway used directly as DNS server IP address, the default open. Click “Apply” go into effect.
  • Page 15 IAD100T Advanced Configuration Manual Note: If you want to revise “DHCP Lease table”, save configuration will go into effect. DHCP auto-update functions: 3 update modes(none; update firmware; update config file); none means don’t upgrade. Let’s take configuration files for an example. Please follow the operation steps below: As the picture shows: 1．...

  • Page 16: Nat Config

    IAD100T Advanced Configuration Manual Server LAN addr are in the same network segment. Then delete current DHCP Server address lease table, save config and reboot the device; 5． Prepare the config files need to be updated. Naming rules of configuration files are in form of the device’s MAC address.

  • Page 17: Net Service Config

    After configuration click “Add” mapping table, click “Delete” to delete in mapping table. NAT configuration detail explanation: Gateway A (IAD100T) WAN port IP address is 192.168.1.110, gateway B WAN port IP address is 192.168.10.2, PC IP address is 192.168.1.111. Topological design as follows: Use NAT’s way to let PC visits gateway B configuration page:...

  • Page 18: Firewall Config

    IAD100T Advanced Configuration Manual Configuration Explanation: Configure Web browser port, the default is 80 port, if you want to enhance system safety, it is best to change it into non-80 standard port, after subit save configuration, please notice re-login the way should be http://xxx.xxx.xxx.xxx：xxxx/ Configure Telnet port, the default is 23.

  • Page 19: Qos Config

    IAD100T Advanced Configuration Manual Configuration Explanation: Shows the Input / Output rule. Choose Deny configuration / Permit configuration. Choose application Protocol Type The source address. Src address can be specific IP address or network address. The source address mask, set 255.255.255.255 as the specific Host computer, set 255.255.255.0 as the Src mask as the nextwork ID.

  • Page 20: Sip Advanced Config

    IAD100T Advanced Configuration Manual VLAN Enable Enable/disable VLAN Voice VLAN ID The gateway supports transmit voice data and non-voice data by VLAN. User need to input VLAN ID. Voice 802.1P Priority Config the priority of voice data transmit. Data VLAN ID Non-voice data’s VLAN ID...
  • Page 21 IAD100T Advanced Configuration Manual Configuration Explanation: Configure gateway receive number End with # Configure Fixedd Length receive number. For example, if user set 8 digital numbers, after input 8 digital numbers, the gateway will call it automatically. Configure dial time out, the units as seconds. Gateway default is 5 seconds, after 5 seconds if the user does not have dialed any number, gateway will send out the number which it received.

  • Page 22: Value-Added Call Service

    IAD100T Advanced Configuration Manual 2.4.8 Value-added Call Service On this page user can set hotline, call forward, call transfer, call-waiting, three way calls, and black list, out limit-list and so on . Configure hotline number. With this number of the port, this hotline number will be dialed automatically as soon as hook-off and user can’t dial any number.

  • Page 23: Mmi Config

    IAD100T Advanced Configuration Manual Black List: If user doesn’t want to answer a certain number, please add this number in the list, and then this number will be unable to get through the gateway. Limit List: If the number in Limit List, it will be unable to get through this number.
  • Page 24 IAD100T Advanced Configuration Manual Config gateway’s first codec; Configure G729 Payload Length according to requirement. Configure Input Volume. Configure Output Volume. Configure VAD (Voice Activity Detection). Select Signal Standard. When RFC2833 is selected by DTMF, user can config RTP for a whole number within 96-101.

  • Page 25: Vpn Config

    IAD100T Advanced Configuration Manual 2.4.11 VPN config IAD100T gateway supports L2TP VPN protocol. Before config VPN, make sure that your VPN server is enable and can work normally. VPN Server Addr: Input VPN server address. VPN User Name : Input L2TP user name...
  • Page 26 IAD100T Advanced Configuration Manual This is the option configuration item. Dial mode: SIP, Lifeline, three types of destination: ◆ Destination c onfigure as 0.0.0.0, it mean the phone call via SIP1 (VOIP-SIP) – SIP) ◆ Destination configure as 255.255.255.255, it means the phone call via SIP2 (Adcance ◆...
  • Page 27 IAD100T Advanced Configuration Manual 25118801# directly, the system will add 00086 automatically. 3) Delete number automatically, for example: gateway register two SIP account, user want to use SIP2 to make a call (Destination 255.255.255.255 as SIP2, default 0.0.0.0 as SIP1), if SIP1 account 90601748, SIP2 account 90601728, the receive number is 9050026.

  • Page 28: Configuration Management

    IAD100T Advanced Configuration Manual 2.6 Configuration Management 2.6.1 Save config Config Manage—>Save CconfigàSave Click “Save” the current configuration User afte modify the configuration must click “Save”, otherwise the configuration will be same as before reboot the gateway. 2.6.2 Clear config The system can restore factory default configuration on this page and the gateway will reboot.

  • Page 29: Backup Config

    IAD100T Advanced Configuration Manual 2.6.3 Backup config Right click to save the configuration files as .txt postfix. When you restore the device to factory settings, user can restore the files and configurations by WEB update. 2.7 Update 2.7.1 Update via WEB User can select the update documents on hard disk of the computer to update the system.

  • Page 30: Update Via Ftp

    IAD100T Advanced Configuration Manual Click “Brower”, find the documents(.dlf or .txt) to upgrade, and then click “Update”, waiting for update finish. 2.7.2 Update via FTP On this page, user can update system and import/export files by FTP or TFTP mode.

  • Page 31: Auto Update

    IAD100T Advanced Configuration Manual Configure upload and download system update document or system layout file name. It should be noted that system file take .z as suffix, configuration files take .cfg as suffix. Select config files export/ config files import/application update type.
  • Page 32 IAD100T Advanced Configuration Manual 192.168.2.10 Server Address FTP server address ouyang Username FTP user name Password password auto.txt config File name config file name need encrypt key when config Encrypt Key import the encrypt config files. Porotocol select protocol Hour...

  • Page 33: System Management

    IAD100T Advanced Configuration Manual Auto Image Protocol: 2 3. After revised configuration file and needs to be updated version of FTP server on the same directory, after reboot the gateway will import config.txt configuration file detected earlier and the AUTOUPDATE CONFIG MODULE module, we have made under changes to download the new Image.

  • Page 34: Reboot

    IAD100T Advanced Configuration Manual password. Click “Submit” to go into effect, “Return” to cancel configuration. Click “Delete” to delete the select account from the drop-down menu. Click “Modify” to modify the chosen account, neet to select first, click “modify” again will go into effect.

  • Page 35: Restore To Factory Settings

    IAD100T Advanced Configuration Manual Input #*100# Gateway works at IP mode Input #*101# Gateway works at DHCP mode Input #*102# Gateway works at PPPOE mode Input #*103# Gateway works at Bridge mode Input #*104# Gateway works at Router mode Input #*111#...

  • Page 36: Faq

    255.255.255.0 ◆ Close computer firewall ◆ Running tfpd32.exe (can be download in www.5111soft.com) ◆ Computer use telnet Remote Login gateways, IAD100T LAN IP default address login 192.168.10.1. The procedure to enter safety mode: Wuchuan Network Tech Co., Ltd www.5111soft.com...
  • Page 37 (exclude the network configuration all other configuration) and remove system configuration file (network configuration). Gateway dead, option 3 can remove all configurations, IAD100T resume factory value; if you forget the password can be resumed operation in this way.
  • Page 38 IAD100T Advanced Configuration Manual Option 3, IAD100T restore factory value Option 1, will be prompted to request input TFTP server IP address, input IP gateways can be connected to the computer (the server computer to open the tftp). Press Enter after the success into the following interfaces: At this point gateway will be prompted to request input telent recovery program name, and then enter the coming update document, such as the importation of application.dlf, Enter the following menu will appear.
  • Page 39 IAD100T Advanced Configuration Manual As picture, we chose D, start the download. We can see that the phrase downlading tips, please waiting ---------- show and re-start the download menu, download the application has been successful. After the success of update, please enter 4 to quit the safe mode.
  • Page 40 IAD100T Advanced Configuration Manual If you still have questions, please link to our website ( www.5111soft.com) for more info or contact our technical engirneer for further support. Wuchuan Network Tech Co., Ltd www.5111soft.com...
