USER'S MANUAL
7-INCHES TFT LCD TOUCH CREEN
USER'S MANUAL
VL1
V.AL5.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDM-705W and is the answer not in the manual?

Questions and answers

Related Manuals for Sintrones VDM-705W

Summary of Contents for Sintrones VDM-705W

  • Page 1 USER’S MANUAL 7-INCHES TFT LCD TOUCH CREEN USER’S MANUAL V.AL5.1...

  • Page 2: Table Of Contents

    INDEX CONTENT PAGE Features Specification Installation Video Control Keys Video Remote Controller Function Content of OSD Function 11~13 Content of VGA Function 14~16 Language Table of OSD Menu VGA Mode Support List Replacing Batteries Of Remote Controller Standard Package...

  • Page 3: Features

    1. Features: . Touch Screen, No need mouse for use . 16:9 Wide Screen . Slim Design . LED Backlight With Lower Power Consumption . High Brightness 500 nits . Three Video Inputs . One VGA Input . USB Interface .

  • Page 4: Specification

    2. Specification: 7-INCH TFT LCD COLOR VIDEO MONITOR Resolution 800 (H) x R.G.B. x 480 (V) Display Size 7-Inch TFT (16:9 Wide Screen) Active Area(mm) 152.4(W) x 91.44(H) Brightness (cd/m2) Contrast Ratio 350:1 Drive System Active Matrix Back Light Video Input Composite Video Signal 1 Vpp 75Ω...

  • Page 5: Installation 5~8

    3. Installation Step 1: Wire Connection 1. Yellow RCA Jack: Video 1 2. Black RCA Jack: Video 2 3. Blue RCA Jack: Video 3(For Reversing Camera, when you shift the reverse gear, the camera image will be shown on the screen automatically) 4.
  • Page 6 Step 2: a) Install the CD Disk of the software into your PC first b) Select the “TouchKit” function from your PC c) Select the Interface to be USB mode d) Select the Language what you want: English, Traditional Chinese, Simplified Chinese, Japanese, Spanish, French, German, Korean e) Select the “4 PTS CAL”...
  • Page 7 g) Draw test: when you finish the 4 Pts Cal correction, you can select the draw test and drawing on the screen for testing that if your screen can feel you touch. h) Advance: if you feel the 4 Pts Cal is not good enough for you, you can select the advance function for 25 Pts Cal correction.
  • Page 8 ***** NOTICE ***** 1) Please calibrate the Touchscreen with the Touchkit-utility after the Touchscreen drivers have been installed. If you do not calibrate the Touchscreen, it might not work properly and can be inaccurate. (Please Refer To The Step 2 Of the User Manual) ***** Hinweis ***** 1) Bitte kalibrieren Sie den Touchscreen im...

  • Page 9: Video Control Keys

    4.Video Control Keys: 1. IR Receiver: For Remote Controller Receive signal purpose. 2. POWER: power ON/OFF & Video 1, 2, VGA Mode selection. 3. Dimmer: Adjust the Dimmer Level (Bright/Normal/Dark/Auto) 4. MENU: Mean list and Up/Down function for selecting Mean. : Increase +) the rating of the function that you selected or hot key for volume rating increase.

  • Page 10: Video Remote Controller Function

    5. VIDEO Remote Controller Function: POWER: Power On/Off Function. : MUTE MENU: Show Function Menu List and make Selection. － : Decrease the rating of the function you selected. ＋ : Increase the rating of the function you selected. S: Adjust the screen aspect ratio at 16:9 or 4:3 mode AV: Video Selection.

  • Page 11: Content Of Osd Function 11~13

    6. Content of VIDEO OSD Function OSD MENU LIST BRIGHTNESS: Adjust the brightness of screen. Adjust area: 0~100 CONTRAST: Adjust the contrast of screen. Adjust area: 0~100 COLOR: Adjust the color of screen. Adjust area: 0~100...
  • Page 12 HUE: Adjust HUE function Adjust area: 0~100 H-POSITION: Adjust Horizontal Position Adjust area: 0~100 V-POSITION: Adjust Vertical Position Adjust area: 1~100 ZOOM: Adjust Ratio Position Adjust Type: 16:9 /4:3 RESET: EXIT: Save & back to main menu OPTION: For setting more functions (Please see next page)
  • Page 13 VIDEO OPTION Functions: Volume: Adjust volume from 0-100 Mute: Select Audio on/off Dimmer: Select Auto Dimmer/Bright/Dark/Normal Language: 5 language of OSD in English, Spanish, French, German, Italian. Default: Return all controls back to factory setting Exit: Exit to last menu mode...

  • Page 14: Content Of Vga Function 14~16

    7. Content of VGA Function VGA MENU LIST AUTO ADJUST: Adjust the screen vertical & horizontal position BRIGHTNESS: Adjust the brightness of screen. Adjust area: 0~100 CONTRAST: Adjust the contrast of screen. Adjust area: 0~100...
  • Page 15 PHASE: Press “＋” or “－“ button to adjust the Phase control. Phase adjustment may be required to optimize the display quality. CLOCK: Adjust the full screen by manual H-POSITION Adjust Horizontal Position Adjust area:0~100 V-POSITION: Adjust Vertical Position Adjust area: 1~100 ZOOM: Adjust Ratio Position Adjust Type: 16:9 /4:3...
  • Page 16 Option Menu List of VGA mode Volume: Adjust volume from 0-100 Mute: Select Audio on/off Dimmer: Select Auto Dimmer/Bright/Dark/Normal R_TEMP: Adjust RED Color Range from 0-100 G_TEMP: Adjust Green Color Range from 0-100 B_TEMP: Adjust Blue Color Range from 0-100 LANGUAGE: English, Spanish, French, German, Italian.

  • Page 17: Language Table Of Osd Menu

    8. Language Table of OSD Menu...

  • Page 18: Vga Mode Support List

    9. VGA Mode Support...

  • Page 19: Replacing Batteries Of Remote Controller

    10. Replacing Batteries Of Remote Controller (1) Always use new batteries when replacing the old set. (2) Do not attempt to charge, short-circuit, disassemble, hurt or burn used batteries. (3) Battery replacement is necessary when remote controller acts sporadically or stops on the remote controller (4) Do not drop, apply shock or stop on the remote controller...
