- Page 1 In-Vehicle Monitor VDM-700HD V1.0 User Manual User Manual...
- Page 2 Disclaimer SINTRONES® Technology Corp. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. SINTRONES® Technology Corp. makes no representation or warranty regarding the content of this manual.
- Page 3 All the trademarks, registrations, and brands mentioned herein are used for identification purposes only and may be trademarks and registered trademarks of their respective owners. Safety Information Read the following precautions before setting up a SINTRONES® Product. Electrical safety ◼...
- Page 4 CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same or equivalent as recommended by SINTRONES® Technology Corp. Dispose of used battery according to the manufacturer's instructions. Technical Support Please do not hesitate to call or e-mail our customer service when you cannot fix the problems.
-
Page 5: Table Of Contents
TABLE OF CONTENTS PRODUCT INTRODUCTION......................6 Overview ............................6 Key Features ............................. 6 Specification ............................. 7 Power Consumption ......................... 9 Package Contents ..........................9 Ordering Information ........................9 Optional Accessory ........................... 9 SYSTEM I/O ............................ 11 Front Panel Information ......................... 11 I/O Information .......................... - Page 6 Chapter 1 Product Introduction User Manual...
-
Page 7: Product Introduction
1.0 PRODUCT INTRODUCTION 1.1 Overview VDM-700HD is a touch monitor designed with wide power input voltage range and operating temperature which are dedicated for In-Vehicle computing. An ideal operating terminal for fleet management and smart cockpit applications on commercial vehicles. -
Page 8: Specification
1 x DVI-D 29 pins Connector for DVI-D Single Link Video, Touch (USB 2.0), Multi-IO Line in, MIC out, and DC 9~48V Power input * SINTRONES custom pin definition for SINTRONES optional cable only Secondary Video Input 1 x HDMI... - Page 9 Operating: MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi- Shock trailers=15G (11ms) Certifications CE, FCC Class A, E13 Ordering Information Model Number VDM-700HD Description 16:9 7" 600nits In-Vehicle Monitor w/ P-CAP multi-touch State of Origin Made in Taiwan User Manual...
-
Page 10: Power Consumption
1.6 Ordering Information Model Name Description VDM-700HD 16:9 7" 600nits In-Vehicle Monitor w/ P-CAP multi-touch 1.7 Optional Accessory SINTRONES provides optional accessories as follows. Please get in touch with your dealer or us if you need any. Item Order No. Description Cable... - Page 11 Chapter 2 I/O and Connectors User Manual...
-
Page 12: System I/O
2.0 SYSTEM I/O 2.1 Front Panel Information Icon Mode Input Brightness Brightness Power Normal Menu Source Down On/Off Move Power OSD Menu Exit Exit/Return Move Up Confirm Down On/Off User Manual... -
Page 13: I/O Information
2.2 I/O Information User Manual... -
Page 14: Dimensions
2.3 Dimensions VDM-700HD Unit: mm Unit: mm User Manual... -
Page 15: I/O Connector Definition
2.4 I/O CONNECTOR DEFINITION 2.4.1 DVI Connector DVI 29 Pins Connector Type Connector Location Connector Drawing PIN# Interface PIN# Interface PIN 1 DVI_TX2_N (TMDS) PIN 16 DVI_HPD (Hot plug detect) PIN 2 DVI_TX2_P (TMDS) PIN 17 DVI_TX0_N (TMDS) PIN 3 PIN 18 DVI_TX0_P (TMDS) PIN 4...
